PCA-6013 PICMG 1.0 Full-sized Intel® Atom N455/
D525 Processor Card with VGA/Dual Gigabit LAN
Startup Manual

Packing List

Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 PCA-6013 Intel® Atom N455/D525 processor-based
single board computer
• 1 PCA-6013 Startup Manual
• 1 CD with driver utility and manual (in PDF format)
• 1 Ultra ATA 66/100 IDE cables
• 1 Serial ATA HDD data cable
• 1 Serial ATA HDD power cable
• 1 Printer & COM port cable kit
• 1 Y cable for PS/2 keyboard
and PS/2 mouse
• 1 USB cable with 4 ports
• 1 Jumper pack
• Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1:
For detailed contents of PCA-6013, please refer
to information on the enclosed CD-ROM (in PDF
format). Acrobat Reader is required to view any
PDF file.
Note2:
Acrobat Reader can be downloaded at:
http://get.adobe.com/tw/reader/ (Acrobat is a
trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/
This manual is for the PCA-6013 series Rev. A1
Part No. 2006601311
p/n: 1701400452
p/n: 1700003194
p/n: 1700022749-11
p/n: 1701260305
p/n: 1700060202
p/n: 1700008461-11
p/n: 9689000068
2nd Edition
June 2015

Specifications

Standard SBC functions

• CPU: Soldered-down (BGA type) Intel® Atom™ 1.8 GHz
D525 dual-core CPU or 1.66 GHz N455 fanless CPU
• BIOS: AMI® SPI 16 Mb Flash memory BIOS
• Chipset: Intel® ICH8M I/O control hub
• System memory: Single Channel; One 204-pin SODIMM
socket accepts up to 3 GB DDR3 800 SDRAM for D525
and up to 2GB DDR3 800 for N455.
• IDE interface: One channel, supports two IDE devices.
The IDE port may be altered to a Type II CF socket.
• SATA interface: Supports three SATA2 HDDs (300 MB/s)
• Serial ports: Two serial RS-232 ports
• Parallel port: One EPP/ECP parallel port
• Keyboard/mouse connector: One standard PS/2 key-
board/mouse connector and one external 6-pin header.
• Watchdog timer: 255 level timer intervals
• USB (2.0): 8 Universal Serial Bus ports on board for VG
SKU; 8 ports on board and 1 port on I/O bracket for G2
SKU.

VGA Interface

• Controller: Embedded Gen3.5+ GFX Core technology
• Display memory: Shared with 224 MB system memory
• Video Output:
- VGA: Supports up to SXGA 1400 x 1050 @ 60 Hz for
Atom™N455, up to 2048 x 1536 @ 60 Hz for Atom™
D525
- Optional LVDS: Supports 18-bit single channel and up to
WXGA 1366 x 768 or 1280 x 800

Ethernet Interface

• Chipset: LAN1:Intel® 82567V; LAN2:Intel® 82583V
• Connection: Onboard RJ-45 connector

Mechanical and Environmental

• Dimensions (L x W): 338 x 122 mm (13.3" x 4.8")
• Power supply voltage: +5 V, +12 V
• Power requirements:
Configuration 1:
- CPU: Intel® Atom™ D525 CPU 1.8 GHz
- Memory: 1 DDR3 800MHz 2GB DIMM and 1GB on board
- Test program: Intel Max power 100% + BurnIn Test 4.0 +5 V
@ 3 A, +12 V @ 0.44 A, +3.3 V @ 0 A,
+5 VSB @ 0.15 A, -12 V @ 0 A, -5 V @ 0 A
Configuration 2:
- CPU: Intel® Atom™ N455 CPU 1.66 GHz
- Memory: 1 DDR3 800MHz 1GB DIMM and 1GB on board
- Test program: Intel Max power 100% + BurnIn Test 4.0
+5 V @ 2.1 A, +12 V @ 0.16 A, +3.3 V @ 0 A,
+5 VSB @ 0.13 A, -12 V @ 0 A, -5 V @ 0 A
• Operating temperature: 0 ~ 60° C
• Weight: 0.5 kg (net weight)
PCA-6013 Startup Manual 1
