BodyCraft LT100 spacewalker Owner's Manual

Hide thumbs Also See for LT100 spacewalker:

Advertisement

Quick Links

OWNER'S
MANUAL
BODYCRAFT
7699 Green Meadows Dr., Lewis Center, Ohio 43035
Tel: 800.990.5556
www.bodycraft.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT100 spacewalker and is the answer not in the manual?

Questions and answers

Teresa franklin
January 28, 2025

My space Walker will not come on

User image 67985a1a529fe
1 comments:
Mr. Anderson
February 10, 2025

Your BodyCraft LT100 Spacewalker may not turn on due to the following reasons:

1. Circuit Breaker Tripped – If the running belt stops unexpectedly and the console does not function, the circuit breaker may have tripped. To reset:
- Turn off the main power switch.
- Wait a few minutes.
- Ensure the safety key is properly positioned on the console.
- Push the reset breaker button and turn the treadmill back on.

2. Safety Key Not Attached – The treadmill will not operate unless the safety key is properly attached to the console.

3. Power Issues – Ensure the treadmill is plugged into a suitable power source and that the power switch is turned on.

If the console remains blank after following these steps, contact customer support.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for BodyCraft LT100 spacewalker

  • Page 1 OWNER’S MANUAL BODYCRAFT 7699 Green Meadows Dr., Lewis Center, Ohio 43035 Tel: 800.990.5556 www.bodycraft.com...
  • Page 2 “S AFETY NSTRUCTION” WARNING: To reduce the risk of serious injury, read the following safety instructions before using the item. Exercise can present a health risk. Consult a physician before beginning any exercise program with this equipment. This is especially important if you are over the age of 35, have never exercised before, are pregnant, or suffer from any illness If you feel faint or dizzy, immediately discontinue use of this equipment.
  • Page 3: Unfolding Instructions

    “ ” NFOLDING NSTRUCTIONS A. Gently press the button (A) located on the right upper side of Right Rear EndCap (21) as shown. The Deck (2) will start to descend. Keep holding the Deck (2) with two hands until hearing a “click” sound to make sure the deck has fully descended to the floor.
  • Page 4: Power Cord Storage

    “ ” OWER PERATION NSTRUCTIONS A. Open the Storage Door (13) by simply sliding it upward. B. Unwrap the Power Cord (61) from the unit’s storage compartment. Storage Before plugging the Power Cord (61) into the electrical outlet, Compartment make sure that the supply voltage matches the voltage information stated on the label (on front of the item).
  • Page 5 “ ” OVING READMILL NSTRUCTIONS A. Turn the power switch off. B. Unplug the power cord. C. Fold the treadmill and make sure the lock is secured. D. Make sure the motor is on the bottom side. Simply roll the treadmill with two transportation wheels to the desired location.
  • Page 6 “ ” ALKING DJUSTMENT NSTRUCTIONS A. Open the Storage Door (13). B. Allen Wrench (35) is attached on back of the Storage Door (13). To adjust the belt, please take a look at the following steps. CENTERING THE BELT: If the walking belt is off center to the LEFT: 1.
  • Page 7 “ ” ALKING DJUSTMENT NSTRUCTIONS CENTERING THE BELT: If the walking belt is off center to the RIGHT: 1. If the belt is slightly off center, first runs the treadmill without anyone on it at 6 kph (4 mph) for 12 minutes to see whether the treadmill could automatically center the running belt.
  • Page 8: Operation

    ” AFETY PERATION NSTRUCTIONS The Safety Key (36) is designed to cut the power off for emergency. In an emergency, disengage the Safety Key (36) from the console to stop the treadmill. a. This treadmill will not start unless the Safety Key (36) is inserted into position A.
  • Page 9: Parts Drawing

    “ RODUCT ARTS RAWING...
  • Page 10 “ ” NO. Item Name Q'ty NO. Item Name Q'ty Main Frame 36 Safety Key Running Deck Frame 37 Screw (M2.6×8mm) Upper Console Table Cover 38 Screw (M4×12mm) Console 39 Screw, Pan Head (M4×20mm) NonSlip Strip 40 Screw, Flat Head (M4×20mm) Bottom Console Table Cover 41 Screw (M5×18mm) Shock Absorption Strip (35mm)
  • Page 11 NO. Item Name Q'ty 79 E Ring 80 Screw (M3 x6mm) 81 Nylon Washer (8x16x1.0t) 82 Screw (M6xp1.0x10mm) 83 Washer (6x20x2.0t)
