DESCRIPTION OF THE DEVICE
Backlight key
PERFOM A MEASUREMENT
Turn on the device by pressing on « On/Off/Esc».
➢
The device displays its name « AQ110 ».
When it turns on, the device performs a pre-heating phase. This phase lasts 10 seconds. The count of this pre-heating time
displays on screen.
The measure probe must be left to the open-air during this pre-heating phase.
Put the probe to the required location.
➢
The device displays the CO
FREEZE THE MEASUREMENT
During the measurement :
Press on « Hold/min/max » to freeze the measurement.
➢
« Hold » appears on the screen and the measurements are frozen.
Press on « On/Off/Esc » to exit the hold function.
➢
The device returns to the measurements display.
OK key
Select key
and temperature measurements.
2
Air Quality
AQ 110
On/Off/Esc key
Hold/min/max key
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kimo AQ 110
Summary of Contents for Kimo AQ 110
- Page 1 Air Quality AQ 110 DESCRIPTION OF THE DEVICE OK key Backlight key On/Off/Esc key Select key Hold/min/max key PERFOM A MEASUREMENT Turn on the device by pressing on « On/Off/Esc». ➢ The device displays its name « AQ110 ». When it turns on, the device performs a pre-heating phase. This phase lasts 10 seconds. The count of this pre-heating time displays on screen.
- Page 2 DISPLAY THE MINIMUM AND THE MAXIMUM Once the measurement is frozen : Press on « Hol/min/max ». ➢ The device displays the maximum value of CO measured since the last questioning at the top of the screen and the minimum ² value of CO measured since the last questioning at the bottom of the screen.
- Page 3 Activate or deactivate the keys beep The device is on and displays the measurement. Press on « Select » until « BEEP » blinks on screen. ➢ Press on « OK ». ➢ « OFF » or « ON » blinks on screen. Press on « Select » to activate the keys beep « ON » or deactivate it « OFF ». ➢...
- Page 4 Once returned to KIMO, required waste collection will be assured in the respect of the environment in accordance to 2002/96/CE guidelines relating to WEEE...
