DESCRIPTION OF THE DEVICE
Backlight key
PERFORM A MEASUREMENT
Turn on the device by pressing on « On/Off/Esc ».
➢
The device displays its name « VT110 » or « VT115 » then the measured values.
Put the probe to the required location.
➢
The device displays the measurements of velocity or airflow and of temperature.
Sensitive element
(temperature)
Protective tube of the
sensitive element (1)
Red point :
landmark
VT110 : Standard hotwire probe
Before any device usage with the standard or telescopic hotwire probe standard, please lower the protective tube (1)
●
of the sensitive element.
Always use the hotwire probe with the red point in front of the flow.
●
Always use the telescopic hotwire probe with the white point in front of the flow.
●
Hotwire thermo-anemometer
Select key
Sensitive element (velocity)
Airflow direction
Bottom of the
hotwire probe
VT110 - VT115
Sensitive element
(temperature)
OK key
On/Off/Esc key
Hold/min/max key
Sensitive element (velocity)
Airflow direction
Tube de protection de
l'élément sensible (1)
White point :
Bottom of the telescopic
landmark
VT115 : Telescopic hotwire probe
hotwire probe
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kimo VT110
Summary of Contents for Kimo VT110
- Page 1 PERFORM A MEASUREMENT Turn on the device by pressing on « On/Off/Esc ». ➢ The device displays its name « VT110 » or « VT115 » then the measured values. Put the probe to the required location. ➢ The device displays the measurements of velocity or airflow and of temperature.
- Page 2 PERFORM AN AVERAGE IN VELOCITY During a measurement : Press on « OK », « Start » displays on screen. ➢ Press again on « OK », the average calculation is launched, « End » displays on screen and « AVG » blinks. ➢ Press on « OK » to end the average calculation, the average displays. ➢...
- Page 3 ADJUST THE DEVICE Device drop-down menu ● SEL. SEL. SEL. SEL. MODE UNIT UNIT AUTO Select Select Select Select °C Km/h SEL. P_ATM Select 1009 Select the measuring unit in velocity : The device is on and in velocity mode. Press on « Select ». ➢...
- Page 4 ➢ Change the old batterers by AAA LR03 1.5 V batteries. ➢ Replace the front. ➢ Once returned to KIMO, required waste collection will be assured in the respect of the environment in accordance to 2002/96/CE guidelines relating to WEEE...
