DESCRIPTION OF THE DEVICE

PERFORM A MEASUREMENT

Turn on the device by pressing on « On/Off/Esc ».
The device displays its name « LV130 ».
Put the probe to the required location.
The device displays the velocity and temperature measurements.

FREEZE THE MEASUREMENT

During the measurement :
Press once on « Hold/min/max ».
« Hold » appears on screen and the measurement is frozen.
Press on « On/Off/Esc » to exit the hold function.
The device returns to the measurement display.
Van probe thermo-anemometer
Backlight key
Select key
LV 130
OK key
On/Off/Esc key
Hold/min/max key

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LV 130 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kimo LV 130

  • Page 1 Van probe thermo-anemometer LV 130 DESCRIPTION OF THE DEVICE OK key On/Off/Esc key Backlight key Hold/min/max key Select key PERFORM A MEASUREMENT Turn on the device by pressing on « On/Off/Esc ». ➢ The device displays its name « LV130 ». Put the probe to the required location.
  • Page 2 DISPLAY THE MINIMUM AND THE MAXIMUM Once the measurement is frozen : Press once on « Hold/min/max ». ➢ The device displays the maximum value of velocity or airflow measured since the last questioning at the top of the screen and the minimum ➢...
  • Page 3 Select the measuring unit in velocity : The device is on and in velocity mode. Press on « Select » until « UNIT » blinks on screen with the velocity unit displayed below. ➢ Press on « OK ». ➢ The unit currently used blinks on screen. Press on « Select »...
  • Page 4 Remove the front part at the back of the device. ➢ Change the old batteries by AAA LR03 1.5V batteries. ➢ Replace the front part. Once returned to KIMO, required waste collection will be assured in the respect of the environment in accordance to 2002/96/CE guidelines relating to WEEE...
