Cirrus Logic CRD4297-1 AMR Product Data Book page 26

Item Qty Reference
30 1 R49 8.2K
31 1 U1 MC33078D
32 1 U2 MC1458
33 1 U3 CS4297
34 1 U4 MC78L05
35 1 Y1 24.576 MHz
DO NOT POPULATE
Item Qty Reference
1 1 C63 0.01uF
2 1 C62 1000pF
3 1 R50 47
4 3 R2,R45,R48 0
5 1 Y2 24.576 MHz
6 1 U5 MC78L05ACD VREG
Value Type PCB-Footprint
RES RES_1206
OP AMP SO8
SO8 SO8
CODEC QFP48_7X7
VREG TO-92
PAR RES, FUND XTL_CA-301
Value Type PCB-Footprint
CAP CSN_0805
CAP SMT_0805
RES RES_0805
RES RES_0805
XTALHC49PAD
SO8
Mnfr Part Number
Philips 9C12063A820J RES,8.2k,SM1206,5%,1/4W
MOTOROLA MC33078D IC, SO, SOIC8, 33078, DUAL OP AMP
MOTOROLA MC1458 DUAL HEADPHONE AMP
CRYSTAL CS4279 IC, SO, AC '97 2.0 SERIAL CODEC w/ SRC
SEMICOND.
MOTOROLA MC78L05AC 5V POS.VOLT.REG., 100ma
EPSON CA-301_24.576M-C XTL, 24.576MHz, FUND, PAR RES
Mnfr Part Number
KEMET C0805C103K5RAC CERM CAP, .01uF, 10%, 50V,X7R
KEMET C0805C102J5GAC CERM CAP, 1000pF, 5%, 50V,COG
PHILIPS 9C08052A47R0J RES, SO, 0805, 47, 5%, 1/10W, METAL FILM
PHILIPS 9C08052A0R00J RES, SO, 0805, 0, 5%, 1/10W, METAL FILM
EPSON CRYSTAL, 24.576MHz, H49-US TYPE, Fund
Mode Par Res
MOTOROLA MC78L05ACD 5V POS. VOLT. REG., 100ma
Description
Description
