OnDash N3
User Manual
取扱説明書
Touch-Screen Mirror Dual Dash Cam
ミラー型ドライブレコーダー

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OnDash N3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vantrue OnDash N3

  • Page 1 ® OnDash N3 User Manual 取扱説明書 Touch-Screen Mirror Dual Dash Cam ミラー型ドライブレコーダー...
  • Page 2: Table Of Contents

    1. Camera Ocerview スクリーンの概要 2. Main Screen Configurations 画面構成 3. Setup システム設定 4. Recording Interface Configurations 録画画面 5. Video Playback 再生 6. Dash Cam Installation ドライブレコーダーの取り付け 7. Rear View Camera Installation リアカメラの取り付け 8. Specifications 製品仕様 9. Warranty & Support 保証とサポート...
  • Page 3: Camera Ocerview

    Camera Overview Recording LED indicator (When camera records, blue LED light blinks.) Gesture Sensor. Turn Off/On Screen Lock the emergency video Move selector up; Front/rear view switch Move selector down; Microphone on/off hotkey. Press and hold for 3 seconds to POWER ON/OFF; Short press to turn on/off LLL (low light level) night vision.
  • Page 4 ① Mini USB port: to power the camera and charge the battery inside. ② AV in: connector of the rear view camera. ③ Memory card slot: microSD card slot. ④ GPS port: to connect to the external GPS module (optional). ⑤...
  • Page 5: Main Screen Configurations

    Main Screen Configurations ® Rec On Playback Video Lock Video 15:28 Audio Off Camera Setup 2017- 07- 01 Saturday Camera is recording recording has stopped. Touch to switch to the recording screen. Touch to start/stop recording. Touch to enter the video playback mode (if the camera is recording, press OK button or touch the “Stop Recording”...
  • Page 6: Setup

    Touch to turn on/off Touch to snapshot. voice recording. Touch to go to the Setup menu. (if the camera is recording, press OK button or touch the “Stop Recording” to stop recording first, then go to the Setup mode.) Setup Record Setup Resolution: By default, front camera is 1080P and rear cam is VGA.
  • Page 7: Recording Interface Configurations

    Gesture Control: Default is Off. Can be turned ON. Beep Sound: Set to On by default. Can be turned Off. Language: Default is English,Simplified Chinese,Russian,Japanese are available. Frequency: Default is 50Hz. Can be toggled between 50Hz/60Hz. Screen Saver: Default is 30 Secs,Select the duration in minutes:30 Secs, 1min,3 min or OFF(to disable it).
  • Page 8: Video Playback

    Video Playback Return Front_20170421_144938.MOV 1/73 lock Delete Previous Next Play / Pause Return Rear_20170421_144938.MOV 1/73 lock Delete Previous Next Play / Pause Stop the recording first, then touch to enter the Playback Mode. The front camera recording files are named as “Front_Date_Time”. The rear view camera recording files are named as “Rear_Date_Time”.
  • Page 9: Dash Cam Installation

    Dash Cam Installation Bandage using guide step1 step2...
  • Page 10: Rear View Camera Installation

    Rear View Camera Installation Solution A: install the rear view camera on the top of the car license plate. Solution B: install the rear view camera on the top of the rear windshield glass.
  • Page 11: Specifications

    Specifications The specifications of this product may change without prior notice due to product improvements. Model Processor NOVATEK NT96655 Display 5 inch IPS Screen Front: 170° wide viewing angle, full 6 layer glass lens with F/1.8 wide aperture. Lens Rear: 140° wide viewing angle, F/2.0 wide aperture lens.
  • Page 13 スク リーンの概要 録画LEDインジケータ(録画中、 青色のLEDが点滅しています。 ) ジェスチャーセンサ スクリーンのオン/オフをします 緊急録画をロックします 表示内容を上に移動します; 再生中−巻き戻し; 録画中、 マイクのオン/オフをします。 表示内容を下に移動します; 再生中−早送り; スナップショッ トボタン。 電源ボタンを長押しで電源のオン/オフをします; LLL微光級夜間モードのオン/オフをします。 録画停止中にMボタンを押してメニューモードへ; 録画中、 Mボタンを押してビデオをロックします。 録画の開始/停止 ; 確認ボタン...
  • Page 14 ① ミニUSBポート:ドラレコに給電します/内蔵のバッテリーに充電します。 ② AVポート:リアカメラと接続します。 ③ メモリカード挿入口: microSDHC カードを挿入します。 ④ GPSポート: 別売りのGPS 受信機を接続します。 ⑤ リセッ トボタン: 初期設定に戻します。 ⑥ 多角度で調整可能レンズ。...
  • Page 15 画面構成 ® 録画 オン 再生モード ロック ビデオ 15:28 録音 オン カメラ 設定 2017- 07- 01 土曜日 録画中 録画停止中 タッチして、 録画画面に切り替えます。 録画の開始/停止 ビデオの再生モードに入力します。 (録画中、 「 OKボタン」 を押して、 或い は、 「 録画 オフ」 をタッチして、 録画を停止します、 それから、 「 再生」 をタ ッチして再生モードに入力します。 ) 上書きされないように、 録画しているビデオをロックします。...
  • Page 16 録音のオン/オフ タッチして、 写真が撮れます。 設置画面に入力します (録画中、 「 OKボタン」 を押して、 或いは、 「 録画 オフ」 をタッチして、 録画を停止します、 しれから、 「 システム設定」 をタ ッチして設置画面に入力します。 ) システム設定 録画設定 解像度:フロントカメラの初期設定は1080Pです、 リアカメラのVGAです。 フロント カメラの選択可能な解像度は1080P FHD, 720P, WVGA, VGAです。 ループ録画: 初期設定は3分です。 一つビデオの録画時間を設定することができ ます。 選択可能な設定:オフ、 3 分、 5 分、 10 分です。 夜間モード...
  • Page 17 ジェスチャーセンサー : 初期設定はオフです。 オン/オフが選択できます。 ビープ音: 初期設定はオンです。 オン/オフが選択できます。 言語:言語設定の初期値は英語です。 英語、 中国語、 日本語、 ロシアの4種の言語が 選択できます。 周波数: 初期設定は50Hzです。 光源周波数は50 Hz/60 Hzを選択できます。 スク リーンセーバー(モニター点灯時間設定): 初期設定は30秒です。 起動時の画面 表示時間を変更できます。 録画中、 設定時間経過後カメラのモニターは自動的 にオフになります。 選択項目は30秒、 1分、 3分、 オフがあります。 ファーマッ ト: microSD メモリーカードのフォーマッ トを行います。 全てのファイル に保存されたデータはなくなります。 初期設定:全ての設定をお買い上げ時の状態に戻します。 バージョン: ファームウェアのバージョンを確認できます。 注釈: *駐車モードを開き、...
  • Page 18 再生 戻る Front_20170421_144938.MOV 1/73 ロック 削除 前 次 再生/一時停止 戻る Front_20170421_144938.MOV 1/73 ロック 削除 前 次 再生/一時停止 録画を停止してから、 「 再生」 ボタンをタッチして再生モードに入力します。 フロントカメラで録画したファイルの名前はFront_Date_Timeです。 リアカメラで録画したファイルの名前はRear_Date_Timeです。 緊急録画したビデオの名前はSOS_Date_Timeです。...
  • Page 19 ドライブレコーダーの取り付け ベルトの使用ガイド...
  • Page 20 リアカメラの取り付け 解決方法 A: ナンバープレートの上部にリアカメラを取り付けます。 解決方法B: リアガラスの上部にリアカメラを取り付けます。...
  • Page 21 製品仕様 本製品の仕様及び外観は、 改良のため予告なく変更することがあります。 予めご了承 ください。 型番 プロセッサー NOVATEK NT96655 液晶サイズ 5 インチ IPSスクリーン フロント: 広角170度大口径F/1.8の光学6G多層ガラス レンズ レンズ リア: 広角140度大口径F/2.0レンズ 言語 英語、 中国語、 日本語 H.264 圧縮技術; フロントカメラ: 1920*1080P30, 1280*720P30 Video リアカメラ: VGA 640*480P 画像 JPEG; 12M オーデ ィオ MIC /スピーカーが内蔵しています。 Class10 以上の16GB−64GB(FAT32)のmicroSD メモ メモリース...
  • Page 22: Warranty & Support

    保証について Warranty ® The VANTRUE OnDash N3 Touch Screen Mirror Dual Dash Cam comes with a full 12 months warranty. If you register your product on our official site (www.vantrue.net/register), you can extend the warranty to 18 months. VANTRUE OnDash N3 タッチスクリーンミラー型ドライブレコーダーは12ヶ...
