CONTENTS VERZEICHNIS 日本語作業マニュアル CONTENU SPIS TREŚCI What’s in the box? Basic Operation Was ist in der Box? Grundlegende Operation 付属品を確認する 基本的な使い方 Qu'y a-t-il dans la boîte? Opération de base Co znajdziemy w pudełku? Podstawowe funkcje Camera Overview Specifications Die Übersicht über Kamera Spezifikationen 各部の名称とはたらき...
1. Whatʼs in the box? A. VANTRUE B. Suction Cup Mount C. Rear Camera ® (0.98 ft) N4 Dash Cam D. Car Charger with E. Type-C USB Data F. Rear Camera Built-in Type-C Cable (3ft) Cable (20 ft) Cable (11.4 ft) G. User Manual H.
2. Camera Overview VTN40AXXXX Name Description Button Enter/exit setup menu; Long press to enter Parking Mode; Manually locks the currently recording video clip following emergency or to preserve important videos. - 2 -...
Page 7
Confirms the action; Stop/Start the video Button recording. Button Move selector up; Microphone on/off; Slow forward when playing back videos. Move selector down; Switch the Front, cabin Button and rear camera window display;Fast forward when playing back videos. Button Power ON/OFF; IR LED Light Switch. Type-C USB / Type-C USB port for charging or transferring data;...
Page 8
LED Indicator Blue light is visible on the Camera is plugged into supply. Indicator light [11] Blue light blinks on the Camera is recording. Indicator light [11] Screen overview Loop Recording Time Night mode off G-Sensor OFF G-Sensor ON Night mode auto on/off Night mode on GPS Signal Connecting GPS Signal Locked...
Please use a genuine Micro SD memory card from 32GB to 512GB with a speed rating of U3 or higher. We recommend use Vantrue Micro SD Card (not include). Please insert the SD card when dash cam is off. Carefully insert the memory card into the camera’s card slot until it clicks.
Page 10
REMINDER: The microSD card should be formatted once a month to maximize the lifetime of the memory card. Please do not take the card out when the camera is recording in case that the important video files missing. Please don't use Sandisk or Transcend SD card on this dash cam. 3.2 Installing the camera onto your windshield Attach the Suction Mount to the camera’s Mount Connector, pushing it in until it clicks.
Page 11
Carefully route the power cable around the windscreen and tuck it under the trim. Connect the External Camera to the Rear Cam Port on the device through the rear camera cable, carefully route the cable and tuck it under the trim. - 7 -...
Page 12
With the Type-C USB Cable, connect the supplied Car Charger to the Front Camera Mount Base. 8. Insert the Car Charger into your vehicle’s cigarette lighter port. Vehicle’s Cigarette Lighter Port 9. Start the car. 10. The camera will auto power on and start recording. - 8 -...
4. Basic Operation 4.1 Power ON/OFF Once the car starts on, the camera will automatically turn on and start recording. A. Manually Long press the button to power it OFF. B. Automatically The camera will power off if the charger cable is disconnected or if the vehicle is turned off.
Page 14
4.2 Menu Settings After powering ON the camera, press the button to enter the setup process. (If the camera is recording video, press the button to stop recording before pressing the button.) A. Record Setup Press the button to enter the settings, and use the buttons to navigate the different options.
Page 15
On and Off. • G-Sensor Set: Press button to select the sensitivity options: 1,2,3,4,5,OFF. • Audio Recording: Press button and button to toggle it OFF/ON. • Parking Mode: Press button to change the options: Collision Detection, Collision + Motion Detection, Motion Detection, Low Bitrates Recording, OFF.
Page 16
B. System Setup • Language: Press button to select between English, Simplified Chinese, Japanese, Deutsch, Italian, Spanish, French and Russian. • Format memory Card: Press , navigate button and select format to format the micro SD card. • Format Reminder Setup: Press the button to select the reminder options: 15 Days, 1 Month and Off.
Page 17
• Speed Unit: Press button to select either KM/H or MP/H. Press the button to exit and complete the setup. C. Files Review and delete videos stored in the file folders. • Event: Critical event videos detected by G-Sensor activity or manually locked by user.
Page 18
2. GPS automatic time correction must select the correct time zone, otherwise, the time will be inaccurate after GPS positioning. GPS Automatic Update Manually Set Date / Time Date Style 4.4 Switch Recording Mode/Resolution By default (Front+ Cabin+ Rear RECORDING mode), 1440P+1080P+1080P resolution will show on the screen, the 3 cameras will simultaneously capture road front, inside cabin, and rear at 1440P+1080P+1080P (30fps).
Page 19
30FPS; 1080P+720P 30FPS; 720P+1080P 30FPS; 720P+720P 30FPS. Front+Rear Mode: 2160P+1080P 30FPS; 1440P+1080P 30FPS; 1080P+1080P 30FPS; 1080P+720P 30FPS; 720P+1080P 30FPS; 720P+720P 30FPS. Single Front Cam Mode: 3840x2160P 30FPS; 2592x1520P 30FPS; 2560x1440P 30FPS; 1920x1080P 30FPS; 1280x720P 30FPS. To finish setup, just press the button to exit.
Page 20
4.5 Switch the Front, cabin and rear camera window display In three way or two-way recording mode, you can press the button to switch display so the rear/inside camera shows bigger on the lcd. 1440P+1080P+1080P 1440P+1080P+1080P 1440P+1080P+1080P 01-01-2021 01-01-2021 01-01-2021 Rear Camera Bigger Inside Camera Bigger Front Camera Bigger...
Page 21
The loop recording video file name format is “Year_Date_Time_A.MP4”. For example: “2021-01-01-060101-A.MP4”. The suffix A indicates front cam recorded files, while the suffix B refers to cabin cam recorded files and the suffix C indicates the External cam recorded files. Standard files are stored in the “Video/Normal”...
Page 22
4.8 Event Recording Critical event detection is triggered by the G-Sensor (Gravity Sensor) and will auto-detect vehicle impacts and collisions. This will cause the camera to protect the current video clip from being overwritten by locking it and saving the footage in the “Video/Event” folder. The user can also manually lock the current video recording session by pressing the Button.
Page 23
4.9 Voice Recording By default, the voice recording is ON. It can be turned OFF using either of the following methods: • Go to “Record Setup” > “Audio Recording”, press button and select OFF; • While recording video, press the button to toggle voice recording OFF/ON.
Page 24
4.10 Parking Mode (Constant Power Supply Needed) Parking Mode operates as a sentry function under different situations. To activate Parking Mode, go to “Record Setup” > “Parking Mode” , press button and select the following options: Collision Detection, Collision Detection + Motion Detection, Motion Detection, Low Bitrates Recording, OFF.
Page 25
“Collision Detection” to change it for your need. 1440P+1080P+1080P 01-01-2021 4.10.2 Collision Detection + Motion Detection Triggered When the Collision Detection + Motion Detection has been turned on, this is represented by an Collision Detection + Motion Detection icon at the bottom right corner of the screen.
Page 26
NOTE: In Collision Detection + Motion Detection mode, if the dash cam is turned off manully, it will turn on and record once it detects any vibration. 4.10.3 Motion Detection Triggered When the Motion Detection has been turned on, this is represented by an Motion Detection icon at the bottom right corner of the screen.
Page 27
4.10.4 Low Bitrates Recording When the Low Bitrates Recording has been turned on, this is represented by an Low Bitrates Recording icon at the bottom right corner of the screen. If no movement is detected after 5 minutes of recording, there will be an orange P icon appears in the center of the screen which means Parking Mode is activated.
Page 28
1440P+ 80P+1080P 01-01-2021 In Parking Mode, the camera will exit Parking Mode if it detects any vibration, and enter the Normal Video Mode. In Parking Mode, if you set the Auto LCD OFF to Auto, the camera's LCD will light off after 1 minutes but recording will continue with blue light blinks on the Indicator light.
Page 29
6. You can include GPS tracking and vehicle speed on the video footage, go to “Record Setup” > “Stamp” > “GPS Location Stamp” and “Speed Stamp” to set. You can review recorded video using the VANTRUE GPS Viewer ® (available for download on www.vantrue.net).
Page 30
4.13 Viewing Video on the Camera Press button and go to “Files”, press button to navigate to > “Normal” or > “Event” file folders to view and playback videos on the camera display. Use the buttons to select the file and press button to playback/pause. During playing back, press to slow forward and press to fast forward.
Page 31
4.14 Delete Videos on the Dash Cam Delete Normal Files Go to Normal file, choose a video on the dash cam, press the button, then press the button to select “Delete ” section, press button to select Delete. Delete Event Files Go to Event file, choose a video on the dash cam, press the button, then press the button to select “Delete ” section, press button to select Delete. 4.15 Auto LCD Off This feature avoids any chance of the screen being a distraction in the vehicle, especially at night when the illumination from the LED screen can be a nuisance or even a hazard to the driver.
Page 32
The camera will restart once the upgrade has been completed. Always stay up-to-date The latest firmware version is always available at the official VANTRUE website (www.vantrue.net). We strongly recommend registering your product (www.vantrue.net/register) to receive a notification email when a new firmware update is available.
5. Specifications The specifications of this product may change without prior notice due to product improvements. Model Channels 3 Channel 2.45" IPS LCD, 480x272 Lens Front: F1.4, 155 degree wide angle lens Cabin: F2.0, 165 degree wide angle lens External Camera: F1.8, 160 degree wide angle lens Languages English/Japanese/Spanish/French/Italian/ 简体中文(Simplified Chinese)/ Deutsch /Russian Video Front+Cabin+Rear Mode: 1440P+1080P+1080P resolution...
Page 34
External memory Micro SD card (U3 or higher, up to 512GB) Shutter Type Electronic USB Port Type-C Battery type super-capacitor Working voltage 5V 1.5A Working currency 800mA(Typical value) / DC 5V Working Temperature 14 -158°F (-10°C to 70°C) Working Environment 14-122°F (-10°C to 50°C)...
6. Warranty & Support Warranty The VANTRUE OnDash N4 Dash Cam comes with a full 12 months ® warranty. If you register your product on our official site (www.vantrue.net/register), you can extend the warranty to 18 months. Support If you have any questions regarding your product, please do not hesitate to contact us via Amazon or drop us an email at support@vantrue.net. Queries are typically answered within 12-24 hours.
1. Was ist in der Box? A. VANTRUE® B. Saugnapfhalterung C. Rückkamera N4 Dashcam (0.5Meter) D. Auto-Ladegerät mit E. USB-C Daten Kabel F. Rückkamera Kabel USB-C Kabel (1Meter) (6Meter) (3.5Meter) G. Benutzerhandbuch H. Kurzanleitung I. Aufkleber der Rückkamera - 32 -...
2. Die Übersicht über Kamera VTN40AXXXX Num. Name Beschreibung Taste Einstellung-Menü aufrufen / beenden; Lange drücken, um den Parkmodus aufzurufen, während die Kamera aufzeichnet; Manuell sperrt den aktuell Videoclip nach Ereignis Ordner, um wichtige Videos zu speichern; - 33 -...
Page 38
Taste Stoppt / startet die Videoaufnahme; Bestätigt die Einstellung. Aufwärtsauswahl; Mikrofon AN/AUS; Langsamer Taste Vorlauf bei der Wiedergabe von Videos Taste Abwärtsauswahl; um zwischen Frontkamera-, Kabinen- und Rückkamera-Blickwinkel zu wechseln; Schneller Vorlauf bei der Wiedergabe von Videos Taste Power An/ Aus wenn lange drücken; Infrarot Licht An / Aus wenn kurz drücken USB-C / USB-C-Anschluss zum Laden oder Übertragen...
Page 39
Frontkamera für Überwachung der Fahrspuren. Frontkamera Rückkamera Zur Videoaufnahme von hinteren Straßenereignissen. LED Anzeige Blaues Licht ist auf der LED Leuchte immer An die Stromversorgung sichtbar [10] angeschlossen Blaues Licht blinkt auf der LED Leuchte [10] In der Aufnahme Bildschirmübersicht Daueraufnahme Zeit Infrarot LED Aus G-Sensor AUS G-Sensor AN Infrarot LED Autom Infrarot LED An GPS-Signal durchsuchen GPS Signal sperren MIk AN MIk AUS Video Auflösung...
Bitte verwenden Sie eine echte microSD-Speicherkarte von 32GB bis 512GB mit einer Geschwindigkeitsklasse von U3 oder höher. Wir empfehlen Vantrue Micro SD-Karte (nicht im Lieferumfang enthalten). Setzen Sie die Speicherkarte in der Kamera ein, wenn die Kamera aus ist, bis sie einrastet.
Page 41
Nehmen Sie die Karte nicht heraus, wenn die Kamera aufzeichnet, ansonsten wichtige Videodateien fehlen. Bitte verwenden Sie keine Sandisk- oder Transcend-SD-Karte für diese Dashcam. 3.2 Installieren Sie die Kamera auf Ihrer Windschutzscheibe Verbinden Sie die Saughalterung mit der Montagesockel der Kamera und drücken Sie sie hinein, bis sie einrastet.
Page 42
Verlegen Sie das Stromkabel um die Verkleidung Ihres Fahrzeugs und stecken Sie es unter die Blende. Schließen Sie die Rückkamera über das Rückkamera-Kabel an den Anschluss der Frontkamera an, verlegen Sie das Kabel sorgfältig und stecken Sie es unter die Blende. - 38 -...
Page 43
7. Schließen Sie das mitgelieferte Auto-Ladegerät an die Frontkamera- Halterung an. 8. Stecken Sie das Auto-Ladegerät in den Zigarettenanzünder Ihres Fahrzeugs. Zigarettenanzünder Starten Sie das Auto Die Kamera schaltet sich automatisch ein und beginnt mit der Aufnahme. - 39 -...
4. Grundlegende Operation 4.1 Power Ein/Ausschalten Sobald das Fahrzeug startet, schaltet sich die Kamera automatisch ein und beginnt mit der Aufnahme. Es gibt zwei Möglichkeiten, die Kamera auszuschalten: A. Manuell Drücken Sie lange Taste, um die Kamera auszuschalten. B. Automatisch Die Kamera wird ausgeschaltet, wenn das Ladekabel abgezogen oder das Fahrzeug ausgeschaltet wird.
Page 45
4.2 Einstellungen im Menü Nach dem Einschalten drücken Sie Taste, um in die Menü-Einstellung zu gelangen. (Wenn die Kamera Video aufnimmt, drücken Taste, um die Aufnahme zu stoppen und drücken Sie dann Taste.) Dateiverwaltung Video Einstellung System Einstellung A.Video Einstellung Drücken Sie Taste, um die Einstellung zu bestätigen, und drücken Sie oder...
Page 46
• Infrarot LED: Drücken Sie die Taste oder , um sie auszu- wählen: Autom, An und Aus. • G-Sensor: Drücken Sie Taste, um 1,2,3,4,5 und Aus zu wählen. Je höher die Zahl, desto höher die Empfindlichkeit. • Audio Rekord: Drücken Sie Taste, um AUS/AN umzuschalten.
Page 47
B. System Einstellung Sprache: Drücken Sie Taste, um zwischen Englisch, Chine- • sisch, Deutsch, Japanisch, Spanisch, Französisch, Italienisch und Russisch zu wählen. • Formatierung: Drücken Sie anschließend Format, um die microSD- Karte zu formatieren. Formaterinnerung:Drücken Sie • Tasten und , um die Erinnerung- soptionen auszuwählen: 15 Tage, 1 Monat und Aus.
Page 48
• Geschwindigkeitseinheit: Drücken Sie Taste, um KM / H oder MPH zu wählen. C. Dateiverwaltung Überprüfen und löschen Sie Videos im Ordner. Ereignis: Notfallvideos (vom G-Sensor erkannt und manuell • gesperrt) werden gespeichert. Normal: Normale Aufnahme von Videos werden gespeichert. •...
Page 49
4.3 Zeit & Datum Einstellung Öffnen Sie „System Einstellung“ > „Zeit/Datum“, um das Zeiteinstellungs- menü aufzurufen. Zeit &Datum: Es gibt zwei Möglichkeiten, Uhrzeit und Datum einzustellen: 1. Automatische GPS-Aktualisierung; 2 Manuelle Einstellung von Datum/Uhrzeit. Die automatische GPS-Aktualisierung ist standardmäßig aktiviert. -GPS aktualisiert automatisch das Datum und die Uhrzeit basierend auf Ihrer Zeitzone, daher müssen Sie zuerst die richtige Zeitzone auswählen;...
Page 50
4.4 Wechseln Sie den Aufnahme-Modus und Videoauflösung Standardmäßig (Front + Kabine + Rück). Die Auflösung von 1440P + 1080P + 1080P wird auf dem Bildschirm angezeigt. Die Kameras erfassen die Vorder- und Hinterstraße sowie die Kabine mit 1440P + 1080P + 1080P (30 fps). 1440P+1080P+1080P 01-01-2021 Es kann mit folgenden Schritten in den Front + Kabine, Front + Rück oder...
Page 52
4.5 Wechseln Sie den Blickwinkel der Front-, Rückkamera und interne Kamera Im Drei- oder Zwei-Kanal-Aufnahmemodus können Sie die Anzeige der Frontkamera, Kabinekamera und Rückkamera umschalten, indem Sie während der Aufnahme Taste drücken. 1440P+1080P+1080P 1440P+1080P+1080P 1440P+1080P+1080P 01-01-2021 01-01-2021 01-01-2021 Rückkamera(größer) Kabinekamera(größer) Frontkamera(größer) 4.6 Zirkulationsaufnahme Nach der Installation der Speicherkarte beginnt die Kamera standard-...
Page 53
Standardmäßig ist die Zirkulation-Aufnahmezeit 3 Minuten. Bitte gehen Sie zu „Video Einstellung" > „Zirkulationsaufnahme", um auf 1 Minute, 3 Minuten oder 5 Minuten für Ihren Bedarf zu wechseln. Das Zirkulationsaufnahme wird nach dem Format „Jahr_ Datum_ Zeit_ A.MP4" .(zum Beispiel 2021-01-01-060101-A.MP4". Das Suffix A steht für die Dateien von der Vorderen Kamera.
Page 54
Bitte beachten Sie: Wenn IR leuchtet, werden die Videoaufnahmen der Kabine in schwarz und weiß gedreht. 4.8 NotfallRekord Erkennung kritischer Ereignisse wird durch den G-Sensor (Schwerkraftsensor) ausgelöst, erkennt mögliche Unfallkollisionen automatisch, sperrt die aktuelle Aufzeichnung und speichert das Material im Ereignis-Ordner, so dass es nicht überschrieben wird, wenn die Karte voll ist .
Page 55
Audio Rekord Standardmäßig ist die Audioaufnahme AN. Sie können es auf zwei Arten ausschalten: • Gehen Sie zur „Video Einstellung" > „Audio Rekord" und drücken Sie Taste, wählen Sie Aus; • Wenn die Kamera Videos aufnimmt, drücken Sie Taste, um Audio ein- / auszuschalten.
Page 56
Beachten Sie: Um sicherzustellen, dass die Kamera im Parkmodus funktioniert, lassen Sie sie über ein Powerbank mit Strom versorgen oder verbinden Sie sie direkt mit der Autobatteriemithilfe des Hardwire Kits . Wir empfehlen, die Kamera nicht zu lange ununterbrochen laufen zu lassen. Die N4-Arbeitsumgebungstemperatur beträgt -10°C bis 50°C.
Page 57
4.10.2 Kollisionserkennung + Bewegungserkennung Wenn die Kollisionserkennung + Bewegungserkennung eingeschaltet wurde, wird dies durch ein Symbol für Kollisionserkennung + Bewegung- serkennung in der unteren rechten Ecke des Bildschirms dargestellt. 1440P+1080P+1080P 01-01-2021 Wenn nach 5 Minuten keine Bewegung festgestellt wird, wird in der Mitte des Bildschirms ein orangefarbenes P angezeigt, was bedeutet, dass die Kamera in den Parkmodus gelangt.
Page 58
4.10.3 Bewegungserkennung ausgelöst Wenn die Bewegungserkennung aktiviert wurde, wird dies durch ein Bewegungserkennungssymbol in der unteren rechten Ecke des Bildschirms dargestellt. Wenn nach 5 Minuten Aufnahme keine Bewe- gung festgestellt wird, wird in der Mitte des Bildschirms ein orangefarben- es P-Symbol angezeigt, was bedeutet, dass der Parkmodus aktiviert ist.
Page 59
4.10.4 Niedrige-Bitrate Modus Wenn Niedrige-Bitrate Modus aktiviert wurde, wird dies durch ein Symbol in der unteren rechten Ecke des Bildschirms dargestellt. Wenn nach 5 Minuten Aufnahme keine Bewegung festgestellt wird, wird in der Mitte des Bildschirms ein orangefarbenes P-Symbol angezeigt, was bedeutet, dass der Parkmodus aktiviert ist.
Page 60
Im Parkmodus verlässt die Kamera den Parkmodus, wenn sie Vibrationen erkennt (z. B. das Öffnen und Schließen der Tür oder das Bewegen des Fahrzeugs aus dem Stand oder andere Aufprallvibrationen können ausgelöst werden), und wechselt in den normalen Videomodus. Wenn Sie die Bildschirmschoner Einstellung auf Autom einstellen, im Parkmodus erlischt die LCD-Anzeige der Kamera nach 1 Minuten.
Page 61
4.12 Anschluss eines externen GPS-Empfängers (optionales Zubehör) Um die GPS-Funktion der Kamera zu verwenden, kaufen Sie bitte eine externe GPS-halterung. Sie kann auf Amazon gekauft werden. Installieren Sie die externe GPS-Halterung anstelle der Originalhalter- ung an der Kamera. Stecken Sie den USB-C-Stecker in der GPS-Halterung und laden für sie auf.
Page 62
7. Sie können das Video auf VANTRUE GPS Viewer (zum Download auf www. vantrue.net.) Ansehen. 4.13 Video auf der Kamera ansehen Drücken Sie MENÜ und gehen Sie zu „Dateiverwaltung" > „Normal" oder „Ereignis", um Videos auf dem Kameradisplay abzuspielen. Wählen Sie oder Taste die Datei aus und drücken Sie , um die Wiedergabe / Pause zu starten.
Page 63
4.14 Videos löschen Videos in Normal Ordner: Gehen zum Normal Ordner, wählen Sie das zu löschende Video aus und drücken Sie Taste Markieren Sie ,, Löschen Sie diese Datei”, anschließend drücken Sie und ,,Löschen''. Videos im Ereignis Ordner: Gehen zum Ereignis Ordner, wählen Sie das zu löschende Video aus und drücken Sie Taste.
Page 64
Firmware-Aktualisierungsdateien enthält. Nach dem Upgrade wird die Kamera automatisch neu gestartet. Immer auf dem Neusten bleiben Die neueste Firmware-Version ist immer auf der offiziellen VANTRUE-Web- site (www.vantrue.net) verfügbar. Wir empfehlen dringend, Ihr Produkt zu registrieren (www.vantrue.net/register), um eine Benachrichtigungs- Email zu erhalten, wenn ein neues Firmware-Update verfügbar ist.
5. Spezifikationen Die Spezifikationen dieses Produkts können sich ohne vorherige Ankündi- gung aufgrund von Produktverbesserungen ändern. Model Prozessor Front: 5M CMOS Sensor Kabine: 2M CMOS Sensor Rück: 2M CMOS Sensor Kanal 3 Kanale Bildschirm 2.45" IPS LCD, 480x272 Linse Front: F1.4, 155 Grad Weitwinkelobjektiv Kabine: F2.0, 165 Grad Weitwinkelobjektiv Rück: F1.8, 160 Grad Weitwinkelobjektiv Sprache...
Page 66
Videodateiformat Audio Eingebautes Mikrofon und Lautsprecher Memorizer Micro SD Karte (U3 oder höher, max. 512GB) Verschluss Elektronik USB-C USB Anschluss Batterie Typ Super-Kondensator Betriebsspannung 5V 2A Arbeitsstrom 800mA(Typischer Wert)/ DC 5V Arbeitstemperatur 14 zu 158°F (-10°C zu 70°C) Arbeitsumgebung- 14-122°F (-10°C to 50°C) stemperatur Lager Temperature -4 zu 176°F (-20°C zu 80°C)...
6. Garantie und Unterstützung Garantie Die VANTRUE OnDash N4 Dashcam wird mit 12 Monaten Garantie ® geliefert. Wenn Sie Ihr Produkt auf unserer offiziellen Website (www.vantrue.net/ register) registrieren, können Sie die Garantie auf 18 Monate verlängern. Unterstützung Wenn Sie Fragen zu Ihrem Produkt haben, zögern Sie nicht, uns über Amazon zu kontaktieren oder senden uns eine E-Mail an support@vantrue.net.
Page 68
1. 付属品を確認する A. N4ドライブレコ B. 吸盤マウント C. リアカメラ(0.3 m) ーダー本体 D. デュアルUSBポート付 E. Type-C USBデータ F. リアカメラケーブル きのType-Cシガーソ ーケーブル(1m) (6 m) ケットケーブル(3.5m) G. 取扱説明書 H. クイックスタート I. 両面テープ ガイド - 64 -...
1. Qu'y a-t-il dans la boîte? A. Caméra Dashcam B. Suction Cup Mount C. Caméra arrière (0,98 pi) VANTRUE ® D. Chargeur de voiture E. Câble de données F. Câble de la caméra arrière (20 pieds) avec câble de type USB de type C Cintégré (11,4 pi) (3 pieds) G.
2. Vue d'ensemble de la caméra VTN40AXXXX Description Bouton Entrer / quitter le menu de Paramètres; Appuyez longuement pour entrer en mode parking; Verrouille manuellement le clip vidéo en cours d'enregistrement après une urgence ou pour conserver les vidéos importantes. - 95 -...
Page 100
Confirme l'action; Arrêtez / démarrez l'enregis- Bouton trement vidéo. Déplacer le sélecteur vers le haut; Microphone Bouton activé / désactivé; Avance lente lors de la lecture de vidéos. Bouton Déplacer le sélecteur vers le bas; Commu-tation de l'affichage de window/écran de la caméra avant, cabine et arrière ;...
Page 101
Se connecte au support à ventouse. 15 Connecteur de montage 16 Haut-parleur Fournit du son pendant la lecture vidéo. 17 Caméra frontale Caméra frontale pour l'enregistrement vidéo d'événements sur route. 18 Caméra externe Caméra externe pour l'enregistrement vidéo d'événements sur la route arrière. Indicateur LED La lumière bleue est visible La caméra est branchée sur l'alimentation.
Veuillez utiliser une véritable carte mémoire Micro SD de 32 Go à 512 Go avec un indice de vitesse de U3 ou plus. Nous vous recommandons d'utiliser la carte Micro SD Vantrue (non incluse). Veuillez insérer la carte SD lorsque la caméra de Dashcam est éteinte. Insérez avec précaution la carte mémoire dans le slot pour carte de la dashcam jusqu'à...
Page 103
RAPPEL: La carte microSD doit être formatée une fois par mois pour maximiser la durée de vie de la carte mémoire. Veuillez ne pas retirer la carte lorsque la caméra est en train d'enregistrer au cas où les fichiers vidéo importants manqueraient. Veuillez ne pas utiliser la carte SD Sandisk ou Transcend sur cette caméra dashcam.
Page 104
Faites passer soigneusement le câble d'alimentation autour du pare- brise et placez-le sous la garniture Connectez la caméra externe au port de came arrière via le câble de la caméra arrière, acheminez soigneusement le câble et placez-le sous la garniture. - 100 -...
Page 105
Avec le câble USB de type C, connectez le chargeur de voiture fourni à la base de montage de la caméra avant. 8. Insérez le chargeur de voiture dans le port allume-cigare de votre véhicule. port allume-cigare du véhicule 9. Démarrez la voiture. 10.
4. Opération de base 4.1 Mise sous / hors tension Une fois que la voiture démarre, la caméra s'allume automatiquement et commence l'enregistrement. A. Manuellement Appuyez longuement sur le bouton pour l'éteindre. B. Automatiquement La Dash cam s'éteint si le câble du chargeur est débranché ou si le véhicule est éteint.
Page 107
4.2 Paramètres de Menu Après avoir allumé la caméra, appuyez sur le bouton pour entrer dans le processus de paramètres. (Si la caméra enregistre une vidéo, appuyez sur le bouton pour arrêter l'enregistrement avant d'appuyer sur le bouton Paramètres de Paramètres Fichiers l'enregistrement...
Page 108
• LED IR: Appuyez sur le bouton pour sélectionner la section: Auto, Active et Désactive. • Set de capteurs G: Appuyez sur le bouton pour sélectionner les options de sensibilité: 1,2,3,4,5, OFF/ Désactive. • Enregistrement audio: Appuyez sur le bouton et sur le bouton pour l'activer / désactiver.
Page 109
• Laps de temps: Appuyez sur le bouton pour sélec- tionner les options: 1FPS, 5FPS et OFF B. Paramètres du système • Langue: Appuyez sur le bouton pour choisir entre l'anglais, le chinois simplifié, le japonais, l'allemand, l'italien, l'espagnol, le français et le russe. •...
Page 110
• Unité de vitesse: Appuyez sur et sur le bouton poursélec- tionner soit KM / H ou MP / H. Appuyez sur le bouton pour quitter et terminer le paramètre. C. Fichiers Examiner et supprimer les vidéos stockées dans les dossiers de fichiers. •...
Page 111
Mise à jour automatique du GPS Régler manuellement la date/l'heure Style de date 4.4 Changer de mode / résolution d'enregistrement Par défaut (mode d'enregistrement avant + cabine + arrière), la résolu- tion 1440P + 1080P + 1080P s'affiche à l'écran, les 3 caméras captureront simultanément l'avant de la route, l'intérieur de la cabine et l'arrière à 1440P + 1080P + 1080P (30fps).
Page 112
Mode avant + arrière: 2160P+1080P 30FPS; 1440P+1080P 30FPS; 1080P+1080P 30FPS; 1080P+720P 30FPS; 720P+1080P 30FPS; 720P+720P 30FPS. Mode de came avant simple: 3840x2160P 30FPS; 2592x1520P 30FPS; 2560x1440P 30FPS; 1920x1080P 30FPS; 1280x720P 30FPS. Pour terminer les paramètres, appuyez simplement sur le bouton pour quitter.
Page 113
4.5 Basculer l'affichage de l'écran/window de la caméra avant, cabine et arrière En mode d'enregistrement à trois ou à deux voies, vous pouvez appuyer sur le bouton pour changer d'affichage afin que la caméra arrière / intérieure soit plus grande sur l'écran LCD. 1440P+1080P+1080P 1440P+1080P+1080P 1440P+1080P+1080P...
Page 114
Par défaut, la durée d'enregistrement en boucle est de 3 minutes. Veuillez aller à «Paramètres de l'enregistrement»> «Enregistrement en boucle» pour le changer en 1 min, 3 min ou 5 min selon vos besoins. Le format du nom du fichier vidéo d'enregistrement en boucle est «Anné_- Date_- heur_A.MP4».
Page 115
Remarque: si les lumières infrarouges sont allumées, les séquences vidéo de la cabine se transforment en noir et blanc. 4.8 Enregistrement d'événements La détection d'événement critique est déclenchée par le capteur G (capteur de gravité) et détecte automatiquement les impacts et les collisions du véhicule.
Page 116
de lecture / écriture, la carte microSD doit être formatée au moins une fois par mois. 4.9 Enregistrement vocal Par défaut, l'enregistrement vocal est activé. Il peut être désactivé en utilisant l'une des méthodes suivantes: • Allez dans «Paramètres de l'enregistrement»> «Enregistrement audio», appuyez sur le bouton et sélectionnez OFF;...
Page 117
4.10 Mode de stationnement (alimentation constante nécessaire) Le mode parking fonctionne comme une fonction de sentinelle dans différentes situations. Pour activer le mode parking, allez dans «Paramètres de l'enregistrement»> «Mode Parking», appuyez sur le bouton et sélectionnez es options suivantes: détection de collision, détection de collision + mouvement, détection de mouvement, enregistrement à...
Page 118
La sensibilité de détection de collision est réglable avec 3 réglages: faible, moyen et élevé. Veuillez aller à «Paramètres de l'enregis- trement»> «Mode Parking»> «Collision Detection» pour le modifier selon vos besoins. 1440P+1080P+1080P 01-01-2021 4.10.2 Détection de collision + mouvement déclenchée Lorsque la détection de collision + détection de mouvement a été...
Page 119
1440P+1080P+1080P 01-01-2021 REMARQUE: en mode Détection de collision + Détection de mouvement, si la caméra dash cam est désactivée manuellement, elle s'allumera et enregistre- ra une fois qu'elle détectera une vibration. 4.10.3 Détection de mouvement Lorsque la détection de mouvement a été activée, cela est représenté par une icône de détection de mouvement dans le coin inférieur droit de l'écran.
Page 120
REMARQUE: En mode de détection de mouvement, si la caméra est désactivée manuellement, elle ne s'allumera pas et n'enregistrera pas même si elle détecte des vibrations. Dans le laps de temps, la caméra dashcam ne peut pas entrer en mode de détection de mouvement. 4.10.4 Enregistrement à...
Page 121
En Laps de temps, la caméra ne peut pas entrer en mode d'enregis- trement à bas débit. Pour activer manuellement le mode parking, maintenez le bouton enfoncé jusqu'à ce que l'icône P apparaisse à l'écran. 1440P+1080P+1080P 01-01-2021 En mode parking, la caméra sortira du mode parking si elle détecte des vibrations et entrera en mode vidéo normal.
Page 122
1440P+1080P+1080P 01-01-2021 4.12 Connexion d'un récepteur GPS externe (accessoire en option) Si Laps de temps est sélectionné, la dashcam prendra des photos statiques à la fréquence d'images d'enregistrement définie 1FPS,5FPS, OFF pour créer un montage vidéo. Par exemple, si vous définissez Laps de temps 1FPS, la dashcam prendra une photo Installez le support GPS externe sur la caméra au lieu du support d'origine.
Page 123
à «Paramètre de l'enregistrement»> «Timbre»> «Timbre de localisation GPS» et «Timbre de vitesse» pour régler. Vous pouvez consulter la vidéo enregistrée à l'aide de la visionneuse GPS VANTRUE (disponible en téléchargement sur www.vantrue.net ). ® 4.13 Visionner la vidéo sur la caméra Appuyez sur le bouton et allez à...
Page 124
Afficher sur un ordinateur Connectez la caméra à votre ordinateur à l'aide du câble USB Type-C fourni. «Connexion USB» et «démarre» s'afficheront sur l'écran de la caméra, veuillez naviguer vers «Connexion USB» et appuyez sur le bouton pour transférer les données. En fonction du système d'exploitation de votre ordinateur(OS), l'appar- eil apparaîtra sous la forme d'un lecteur amovible ou d'un volume amovible.
Page 125
4.15 Arrêt automatique de l'écran LCD Cette fonctionnalité évite tout risque que l'écran soit une distrac tion dans le véhicule, en particulier la nuit lorsque l'éclairage de l'écran LED peut être une nuisance voire un danger pour le conducteur. Si vous réglez la fonction Auto LCD Off sur 3 minutes, l'écran LCD de la dashcam s'éteindra au bout de 3 minutes, mais l'enregistrement se poursuivra avec un voyant bleu clignotant sur le voyant.
Page 126
Restez toujours à jour La dernière version du firmware est toujours disponible sur le site officiel de VANTRUE (www.vantrue.net). Nous vous recommandons vivement d'enregistrer votre produit (www.vantrue.net/register) pour recevoir un e-mail de notification lorsqu'une nouvelle mise à jour du micrologiciel est disponible.
5. Spécifications Les spécifications de ce produit peuvent changer sans préavis en raison des améliorations apportées au produit. Model Capteur Avant: Capteur CMOS 5M d'image Cabine: Capteur CMOS 2M Arrière: Capteur CMOS 2M Canaux/ Voie 3 canaux 2,45 pouces IPS LCD, 480 x 272 Lentille Avant: objectif grand angle F1.4, 155 degrés Cabine: F2.0, objectif grand angle de 165 degrés...
Page 128
Mode avant: 3840x2160P 30FPS ; 2592x1520P 30FPS; 2560x1440P 30FPS; 1920x1080P 30FPS; 1280x720P 30FPS Format de fichier vidéo L'audio Microphone et haut-parleur intégrés Mémoire Carte Micro SD (U3 ou supérieur, jusqu'à 512 Go) externe Type Électronique d'obturateur Port USB Type-C Type de batterie Super-condensateur Tension de travail 5V 2A...
La caméra de tableau de bord VANTRUE OnDash N4 est livrée avec ® une garantie complète de 12 mois. Si vous enregistrez votre produit sur notre site officiel(www. vantrue.net/ register), vous pouvez étendre la garantie à 18 mois. Support Si vous avez des questions concernant votre produit, n'hésitez pas à nous ...
1. Co znajduje się w pudełku? A. VANTRUE B. Uchwyt mocujący C. Tylna kamera ® Dash Cam (30cm) D. Ładowarka E. Kabel typ-C USB F. Kabel do tylnej samochodowa (90cm) kamery (6m) Typ-C z kablem (347,5cm) G. Instrukcja obsługi H. Przewodnik I.
2. Opis kamery VTN40AXXXX Nazwa Opis Przycisk Wejście/wyjście z menu ustawień; Dłuższe przytrzymanie tryb parkingowy; Ręcznie blokuje aktualnie nagrywany klip wideo po nagłym wypadku lub w celu zachowania ważnych filmów. - 127 -...
Page 132
Przycisk Potwierdź akcję; Stop/Start nagrywanie video Przycisk Przesuń w górę; Mikrofon wł / wył; Powoli przewijaj do przodu podczas odtwarzania. Przesuń w dół; Przełącz wyświetlanie okna Przycisk kamery przedniej, kabiny i tylnej ; Przewijanie do przodu podczas odtwarzania filmów. Przycisk Zasilanie Wł./Wył.;...
Page 133
LED Indicator Ładowanie kamery. Niebieskie światło jest widoczne na lampce kontrolnej [10] Niebieskie światło miga na Kamera nagrywa. wskaźniku [10] Opis ekranu Czas nagrywania pętli ITryb nocny wył G-Sensor Wył G-Sensor Wł Tryb nocny wł/wył Tryb nocny wł GPS Szukanie Sygnału GPS zablokowany MIC wł MIC wył Rozdz. Video 1440P+1080P+1080P Włożona karta pamięci Nagrywanie jazdy Brak karty pamięci Prędkość (KMH / MPH) Czas nagrywania bieżący klip blokada plików Time lapse Wł Nagrywanie Detekcja kolizji wł Bieżąca data (MM/DD/YY) Detekcja kolizji i czas (24H) Detekcja ruchu włączona Low Bitrates Recording ON Nagrywanie lowbitrate WŁ. - 129 -...
3.1 Instalacja karty pamięci (zalecamy VANTRUE microSD) Należy używać oryginalnej karty pamięci Micro SD o pojemności od 32GB do 512GB o prędkości U3 lub wyższej. Zalecamy stosowanie karty Vantrue Micro SD Card (brak w zestawie). Włóż kartę SD, gdy kamera samocho- dowa się...
Page 135
UWAGA: Karta microSD powinna być sformatowana raz w miesiącu, aby zmaksy- malizować żywotność karty pamięci. Nie wyjmuj karty, gdy kamera nagrywa. Nie używaj karty Sandisk ani Transcend SD w tej kamerze samochodowej. 3.2 Instalowanie kamery na przedniej szybie Przymocuj uchwyt ssący do złącza mocowania kamery, wciskając go, aż...
Page 136
Ostrożnie poprowadź kabel zasilający wokół przedniej szyby i wsuń go pod poszyciem. Podłącz kamerę tylną do portu tylnej kamery w urządzeniu za pomocą kabla kamery tylnej. Ostrożnie poprowadź kabel i wsuń go pod listwę. UWAGA: Kamera tylna ani moduł przedni nie nadaje się do mocowania na zewnątrz pojazdu.
Page 137
Za pomocą kabla USB typu C podłącz dostarczoną ładowarkę samochodową do podstawy montażowej przedniej kamery 8. Włóż ładowarkę samochodową do gniazda zapalniczki w samochodzie. Gniazdo zapalniczki samochodowej 9. Uruchom samochód. 10. Kamera włączy się automatycznie i rozpocznie nagrywanie. - 133 -...
4. Podstawowe funkcje 4.1 Zasialanie WŁ/WYŁ. Po uruchomieniu samochodu kamera włączy się automatycznie i rozpocznie nagrywanie. A. Manualnie Długie wciśnięcie wyłączy kamerę. B. Automatycznie Kamera wyłączy się, jeśli kabel ładowarki zostanie odłączony lub pojazd zostanie wyłączony. UWAGA: Urządzenie ma dwa porty USB dostępne do zasilania - w kamerze lub za pomocą...
Page 139
4.2 Ustawenia menu Po włączeniu zasilanie wciśnij przycisk aby wejść do ustawień. Jeśli kamera jest w trybie nagrywania wciśnij aby zatrzymać nagrywanie, a potem aby wejść w opcje. Nagrywanie Ustawienia systemu Pliki A. Opcje nagrywania Nacisńij żeby wejść w ustawienia i wciśnij guzik lub, żeby wybrać...
Page 141
• GPS: Wciśnij aby włączyć / wyłączyć. • Prędkość: Wciśnij aby wybrać pomiędzy KM/H oraz MP/H. Wciśnij aby wyjść i zapisać ustawienia C. Nagrania Przejrzyj i usuń filmy zapisane w folderach. • Chronione: Krytyczne zdarzenia wykryte przez aktywność G-Sensor lub ręcznie zablokowane przez użytkownika. • Normalne: Standardowe nagrania. • Wszystkie: Wszystkie nagrania jakie zostały zarejestrowane. Chronione Normalne Wszystkie - 14 - 4.3 Ustaw datę/godzinę Otwórz interfejs menu i przejdź...
Page 142
Notatka: Aby ręcznie ustawić datę/godzinę, należy wyłączyć automatyczną korektę czasu GPS, aby ustawić. Automatyczna korekta czasu GPS musi wybrać prawidłową strefę czasową, w przeciwnym razie czas będzie niedokładny po pozycjonowa- niu GPS. Automatyczna aktualizacja GPS Ręcznie ustaw datę i czas Format daty 4.4 Przełącz tryb nagrywania / rozdzielczość Domyślne tryb (Przód+ Wnętrze+ Tył ), 1440P+1080P+1080P rozdzielczość pokazana na ekranie, 3 kamery rejestrują obraz w 1440P+1080P+1080P (30fps). 1440P+1080P+1080P 01-01-2021 Można przełączyć tryb pomiędzy przód + kabina, przód + tył lub przód, wykonując ...
Page 144
4.5 Przełączania pomiędzy przód, wnętrze, tył W trybie nagrywania trzy- lub dwukierunkowego naciśnij aby kamera tylna / wewnętrzna wyświetlała się na ekranie LCD w większym rozmiarze. 1440P+1080P+1080P 1440P+1080P+1080P 1440P+1080P+1080P 01-01-2021 01-01-2021 01-01-2021 Tylna kamera większy obraz Wewnętrzna kamera Przednia kamera większy obraz większy obraz 4.6 Nagrywanie w pętli...
Page 145
Format nazwy pliku wideo nagrania w pętli to ,, Rok_data-czas A.mp4".- Na przykład: 2021_08_01_060101_A.MP4. Liczba xA oznacza pliki nagrane kamerą przednią, podczas gdy x B x B odnosi się do plików nagranych kamerą wewnętrzną, a x C oznacza pliki nagrane kamerą tylną. Standar- dowe pliki są...
Page 146
4.8 Nagrywanie zdarzeń krytycznych - tryb chronione Wykrywanie zdarzeń krytycznych jest uruchamiane przez czujnik G (czujnik grawitacji) i automatycznie wykrywa uderzenia i zderzenia pojazdu. Spowoduje to, że kamera zabezpieczy bieżący klip wideo przed nadpisani- em, blokując go i zapisując materiał w folderze Wideo / Chronione. Użytkownik może także manualnie zabezpieczyć...
Page 147
4.9 Nagrywanie dźwięku Domyślnie nagrywanie głosu jest WŁĄCZONE. Można go WYŁĄCZYĆ za pomocą jednej z następujących metod: • Idź do “Ustawienia nagrywania > “Nagrywanie audio/dźwięku”, wciśnij OK i wybierz wyłącz. • Podczas nagrywania wciśnij i ustaw nagrywanie audio wył/ wł. Po wyłączeniu nagrywania głosu ikona MIC u góry ekranu zmieni kolor na biały z czerwoną...
Page 148
UWAGA: Aby kamera mogła działać w trybie parkowania, należy ją zasilać za pomocą mobilnego banku energii lub podłączyć ją za pomocą przewodów do akumulatora. Nie zalecamy używanie trybu parkingo- wego przez zbyt długi okres czasu. Temperatura środowiska pracy N4 wynosi 14-122°F (-10°C do 50°C). Zalecamy korzystanie z trybu wykrywania kolizji w tym zakresie temperatur.
Page 149
4.10.2 Wykrywanie kolizji + Detekcja ruchu uruchomiona Po włączeniu Wykrywania kolizji + Wykrywania ruchu jest to pokazane przez ikonę Wykrywanie kolizji + Wykrywanie ruchu w prawym dolnym rogu ekranu. 1440P+1080P+1080P 01-01-2021 Jeśli po 5 minutach nagrywania nie zostanie wykryty żaden ruch, na środku ekranu pojawi się...
Page 150
W trybie parkowania kamera wyjdzie z trybu parkowania, jeśli wykryjejak- iekolwiek wibracje (takie jak otwarcie i zamknięcie drzwi, odsuwanie samochodu od spoczynku lub inne wibracje uderzeniowe) i przejdzie do normalnego trybu wideo. Jeśli w trybie parkowania ustawisz opcję Auto LCD WYŁ na 3 minuty, ekran LCD kamery zaświeci się po 3 minutach, ale nagrywanie będzie kontynuowane, a kontrolka będzie migać...
Page 151
Możesz dołączyć śledzenie GPS i prędkoś ć pojazdu do materiału wideo, przejdź do Ustawienia zapisu> Stempel> Stempel lokalizacji GPS i Stempel prędkoś ci aby ustawić. Możesz przeglądać nagrane filmy za pomocą przeglądarki GPS VANTRUE - dostępnej do pobrania na www.vantrue.net. ® - 147 -...
Page 152
4.13 Przeglądanie video na kamerze Wcisnij potem “Nagrania ”, wcisnij przejdź do> “Normalne” lub > “Chronione” - przeglądaj nagrania które zarejestrowała kamera. Potem przycisk lub aby wybrac plik i wciśnij przycisk żeby odtwarzać zatrzymać . Podczas ogladania aby zwolnić oglądanie lub aby przyspieszyć.
Page 153
4.14 Kasowanie plików Delete Normal Files Kasowanie normalnych plików Przejdz do danego pliku ktory chcesz usunac i wcisnij potem potwierdz i wybierz ,,Skasuj", potem potwierdz aby usunac plik. Kasowanie plików chronionych Przejdź do pliku który chcesz skasować i wcisnij potem potwierdź klikajac “Skasuj”...
Page 154
Kamera uruchomi się ponownie po zakończeniu aktualizacji. Zawsze bądź na bieżąco! Najnowsze oprogramowanie zawsze jest dostępne na stronie www.vantrue.net. Zalecamy rejestrację produktu na www.vantrue.net/ register aby otrzymywać infomarcje o nowych aktualizacjach. Instrukcję aktualizacji oprogramowania znajdziesz także na www.vantrue.pl 4.17 Temperatura pracy urządzenia...
5. Specyfikacja techniczna Specyfikacje tego produktu mogą ulec zmianie bez uprzedzenia z powodu ulepszeń produktu. Model Sensor Przód: 5M CMOS Sensor Wnętrze: 2M CMOS Sensor Tył : 2M CMOS Sensor Liczba kanałów 3 kanały 2.45" IPS LCD, 480x272 Obiektyw Przód: F1.4, 155 st. obiektyw szerokokątny Wnętrze: F2.0, 165 st.
Page 156
Audio Wbudowany mikrofon oraz głośnik Pamięć Micro SD card (U3 lub wyższa do 512GB) zewnętrzna Typ migawki Elektroniczna Typ-C USB Port Rodzaj baterii superkondensator Napięcie robocze 5V 1.5A Napięcie zasilania 800mA(Typischer Wert)/ DC 5V Temperatura 14 -158°F (-10°C to 70°C) pracy urządzenia Temperatura -4 to 176°...
6. Gwarancja & wsparcie Gwarancja Każda kamera VANTRUE OnDash N4 posiada 12 miesiecy gwarancji. ® Wsparcie Jeśli masz jakiekolwiek pytania dotyczące produktu skontaktuj się z nami biuro@vantrue.pl lub support@vantrue.net Twoja opinia ma znaczenie VANTRUE jest niezmiennie zaangażowany w ciągłe doskonalenie swoich ® produktów.
