- Page 1 LM-TV04H Video Wall Controller USER MANUAL...
- Page 2 I. View of Video Wall Controller With following features: ▼ Split and splicing TV, monitors, video walls easily and conveniently ▼ No need computer and software control ▼ Plug & play type ▼ Screen (180°Rotation of splicing monitor images) ▼ Display by 1x2, 1x3, 1x4, 2x2, and so on (option) ▼...
- Page 3 Please read the definitions of each interface as follows: 1. GND Protective Ground (White Screw) 2. DC12V Input 3. IR IR Remote control 4. LED Light x1 (Play HDMI source, such as DVB-T media player 5. HDMI Input source, DVD player source, computer source, etc.) x1 (Play DVI source, support 480P, 576P, 720P, 6.
-
Page 4: I-I Hardware Description
I-I HARDWARE DESCRIPTION... - Page 5 II. Remote Controller Owing to our products are supplied from China market firstly, thence, the remote controller silk print in Chinese, please read the texts one by one as follows:...
- Page 6 III. OSD Menu The OSD language is English original. Source Menu Press “ 信 号 ” source menu on the remote controller or the “INPUT” button on the controller. The input sources selections include ATV mode, PC-RGB mode, HDMI mode, DVI mode, AV (CVBS) mode and USB mode.
- Page 7 B. Picture Menu C. Option Menu...
- Page 8 USB Menu Press USB button on the controller, enter USB mode, press the menu on “菜单” the remote controller, you can find the USB menu details as follows: IV. Video Wall Connection and Setup:...
- Page 10 Connection: Connect all sources equipment with the controller and 4pcs video wall monitors as the above picture. Setup: 2x2 Video Wall, there are 4 screens, the row numbers are 2 and the column numbers are 2; the screen id is from No.1 to No.4, the details as follows: Finally you will get the big 2x2 video wall by press the “SPLIT/NO”...
- Page 11 1 Piece video wall controller support multiple 7 types display formats as follows: 1x3 Video Wall Setup: The row number is “1”; the column number is “3”, the 3pcs screens ids as following picture: And the menu setup as following picture A.:...
- Page 12 3x1 Video Wall Setup: The row number is “3”; the column number is “1”, the menu setup as the above picture “B”, and the 3pcs screens ids as picture “C”. ow number is “M”; the column number is “N”. And MxN video wall setup: the r V.
- Page 13 2x3 Video Wall 2x4 Video Wall 3PCS video wall controllers get video wall pictures as follows: 3 x3 Video Wall 3x4 Video Wall 4x3 Video Wall...
- Page 14 1. Series connection and menu setup: Get the 3x3 Video Wall (made by 9pcs screens) by 3pcs controllers’ series connections. These 3pcs controllers menu setup as follows: Controller 2 Controller 1 A. Controller 3: The 3x3 Video Wall series connection diagram as follows:...
- Page 15 2. Parallel connection and menu setup: connect with the DVD player, the 1x4 HDMI Splitter and 3pcs controllers by parallel connection to get 3x4 Video...
- Page 16 Wall as follows: These 3pcs controllers menu setup as follows: Controller 1 Controller 2...
- Page 17 Controller 3 180 Degree images rotations setup: Sometimes, user prefer to flipped 180 degree of upper TVs (1. & 2.) Or monitors get the thinner bezel gap for better viewing images as the picture “C”, meanwhile, the image of the upper TVs (1. & 2.) would be the same as picture “E”...
- Page 18 Thence, press the “down” key to select “Screen”, and “enter” key, finally will get the right images of the TVs (1. & 2.) from picture “E” to picture “F”. VI. Specifications AV/CVBS Input PAL/NTSC/SECAM CVBS signal (1.0Vp-p +/-5%) HDMI Input 480p,576p,720p,1080i,1080p DVII Input 480p,576p,720p,1080i,1080p...
- Page 19 USB Mode Enter USB mode HDMI Mode Enter HDMI mode and DVI mode Input Sources selection Split function (4 images display separate) Split/No Splicing function (one image on the entire video wall) Working Voltage DC 12V Power Power ≤ 1W supply Consumption Comb Filter...
