- Page 1 4K Video Wall Controller For 2 Displays LM-TV02-4K2K User manual...
- Page 2 Catalog .Installation Instructions …………… 2 .Product Introduction ………………… 3 .Machine Installed …………………… 4 .Remote control settings ………………… 6 .Chapter button settings ………………… 7 .FAQ ………………………………………… 8...
- Page 3 . Installation Instructions For your safety and equipment, please be sure to read the safety instructions carefully before using this equipment. If you are in doubt, please read the manual. It has a detailed description of the device operation. If you still have any questions, please contact us and we will give you a satisfactory reply as soon as possible.
- Page 4 . Product Introduction 2.1 Overview : LM-TV02-4K2K is a high-performance UHD Ultra HD 4K two displays mosaic, its main function is to 1x2 Tiled display unit displays a 3840x1080@60HZ Super high definition images. Products using advanced image processing technology, the input signal can support HDMI2.0, that is 3840x2160@60HZ, will not appear, even when playing fast animation no delay,no dropped frames.
- Page 5 2.3 Specification Name Spec HDMI input Interface HDMI A type（HDMI2.0 support HDCP2.2） Resolution Up to 3840*2160@60Hz mobile signal input Interface HDMI A type（HDMI1.4 support HDCP2.0 and mobile signal） Resolution Up to 3840*2160@30Hz DP input Interface DP1.2 Resolution Up to 3840*2160@60Hz Audio output Fit for output video HDMI output...
- Page 6 2 Display unit through HDMI Line connect 2 OUTPUT ports are connected as shown in the following figure: HDMI (On the right HDMI Display unit on the left side Interface, as demonstrated ------ output Right display unit ---HDMI (On the left HDMI output Interface, as demonstrated in) 3.2.3 Input signal connections Product support 1 channel HDMI 、...
- Page 7 After the submenu becomes green, change the product parameters or attributes by remote control or key, press the return key to save the settings and exit the menu. 4.2 signal source selection LM-TV02-4K2K signal source menu options are: automatic selection, D0: DP, D1:HDMI, D2:mobile signal...
- Page 8 4.2.1 automatic selection: Through the remote submenu "source" set to "automatic selection", in the original equipment without access to other signal source, can automatically identify the inserted signal source and the signal source is automatically displayed in the splicing unit. 4.2.2 manual selection: The utility model can be used for a single signal source or a plurality of signal sources and is connected with the equipment at the same time.
- Page 9 . FAQ 6.1 question: indicator light does not light? Answer: please confirm whether the power supply is ok. 6.2 question: what is the meaning of the red light and the green light? Answer: red light on behalf of the machine with electricity but no signal source, the green light on behalf of the normal operation of the machine and the channel has a signal source input.
