Introduction; General Description - Upright X26 Ultra Narrow Operator's Manual

I
NTRODUCTION
This manual covers the X26 Ultra Narrow Aerial Work Platform. This manual must be stored on the
machine at all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G D
ENERAL ESCRIPTION
W A R N I N G
!
DO NOT use the machine if all guardrails are
not properly in place and secured.
1. Platform Controls
2. Manual Case
3. Platform Extension
4. Platform
5. Elevating Assembly
6. Chassis
7. Batteries
8. Charger Outlet Plug
9. Chassis Controls
10. Emergency Lowering Valve Knob
11. Hydraulic Fluid Reservoir
114100-020 X26 Ultra Narrow - Operator Manual
!
2
5
6
7
Power Module
3
Rear

Introduction

Figure 1: X 26 Ultra Narrow
1
8
Control Module
11
10
4
9
