Proline Promag L 400 HART
Parameters
Volume flow unit
Volume unit
Conductivity unit
Temperature unit
Mass flow unit
Mass unit
Endress+Hauser
10.5.1

Setting the system units

In the System units submenu the units of all the measured values can be set.
Navigation
"Setup" menu → System units
System units
Parameter overview with brief description
Description
Select volume flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select volume unit.
Result
The selected unit is taken from: Volume
flow unit parameter
Select conductivity unit.
Result
The selected unit applies for:
• Current output
• Frequency output
• Switch output
• Simulation process variable
Select temperature unit.
Result
The selected unit applies for:
• Output
• Reference temperature
• Simulation process variable
Select mass flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select mass unit.
Result
The selected unit is taken from: Mass flow
unit parameter
→ Volume flow unit
Volume unit
Conductivity unit
Temperature unit
Mass flow unit
Mass unit
Density unit
Selection
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Commissioning
Factory setting
Country-specific:
• l/h
• gal/min (us)
Country-specific:
• l
• gal (us)
µS/cm
Country-specific:
• °C (Celsius)
• °F (Fahrenheit)
Country-specific:
• kg/h
• lb/min
Country-specific:
• kg
• lb
