Clean Document Pad & Scanner Glass:
Document
Scanner
3. Wait for cleaned areas to dry completely.
4. Gently close the document cover.
C
ALIBRATING THE
Calibrate the scanner if colors appear in areas that should be white, or colors of the
scanned image and the original vary a lot. This allows you to adjust and compensate
for variations that can occur in the optical component over time by its nature.
The following describes how to calibrate the scanner:
1. Click Finder > Applications > Plustek > Your scanner model name >
Calibration Wizard.
2. Click on the Start button to begin the calibration process.
3. After the calibration is complete, click OK.
A
LIGNING THE
In most cases, the scanner doesn't need to be aligned but there are instances
when the alignment might be required. You need to align the scanner only if parts of
the scanned document are missing from any of its edges. For example, the heading of
a document might be missing from the top edge after the document has been scanned.
1. Place the document onto the scanner glass headfirst and face-down. Align the
top left corner of the document with the arrow on the reference mark.
2. Right-click the icon
pop-up menu that opens.
3. The Scanner Utility window opens. Find the Initial Scanning Position
Alignment section and select Flatbed Reflective as the source.
4. Click the Scan button. Part of the document image will be displayed in the
Alignment Window.
Pad
Glass
S
CANNER
S
CANNER
in the Dock, and then choose Scanner Utility in the
17
