Manage Power for a Device Connected to an Outlet on a PDU

See power_cycle, power_off and power_on on page 12 for how an administrator or any authorized
user can manage power on PDU outlets when the PDU is connected to a port that is enabled and
configured with the Power Profile.

Port Configuration Examples

The following examples show how an administrator can configure a port when a device console is
connected, assign the CAS profile, configure a port that is connected to a PDU and assign the
Power Profile.
To set up a console access service (CAS) port:
1. Log onto the CLI as an administrator.
--:- units cli->
2. Enter
cd
--:- units cli-> cd appliance_settings/ports/physical_ports/
serial_ports/1
3. Enter
show
--:- 1 cli-> show
1
port_settings/
--:- 1 cli->
4. Type then press
cd
--:- 1 cli-> cd<Tab><Tab>
port_settings/
5. Enter
cd port_settings
--:- 1 cli-> cd port_settings
6. Type set
--:- port_settings cli-> set<Tab><Tab>
communication_settings/
7. Type set port_settings
--:- port_settings cli-> set port_settings/<Tab>
rj45_pin-out
serial_profile
2 13:09:04 2007 on :0
followed by the parameters shown to select the port (port 1 is used as an example).
to view the status and serial profile of port 1.
to view the port_settings option.
Tab Tab
to navigate to the Port_Settings level to configure port 1.
then press Tab Tab to view the set options.
then press
status
Chapter 2: Port Access and Configuration Examples
port_settings/
Tab to view the options for the Port_Settings level.
