PRO120
PRO120
SETTINGS
PRO120
MAIN MENU
CHARGE
POWER SUPPLY
SETTINGS
SELECT
SETTINGS
DISPLAY
LANGUAGE
WARNING BUZZER
FACTORY RESET
BACK SELECT
LANGUAGE
ENGLISH
DEUTSCH
NEDERLANDS
FRANҪAIS
BACK SELECT
WARNING BUZZER
OFF
ON
BACK SELECT
Acoustic signal when error
occurs
FACTORY RESET
YES
INFO
BACK SELECT
50016574B CTEK PRO 120A, Manual, Print file_016.indd 3
PRO120
Press to scroll up in menu and to increase values
Press to scroll down in menu or to decrease values
Press to activate selected program or setting
Press to step back or stop in menu
DISPLAY
MODE STANDARD
CONTRAST ADVANCED
BACKLIGHT
BACK SELECT BACK
CONTRAST BACKLIGHT
60% 40%
BACK SELECT BACK
PRO120
INFO
LOCK THE BUTTONS
PRO120
PRO120
Lock the buttons if charger used in public
MMI ver: 11.06
or unattended.
Module ver: 9.09
Press and hold the
to lock/unlock the buttons.
BACK
DISPLAY MODE
SELECT
SELECT
buttons for 2s
RECOMMENDED CURRENT
12V
Current Battery size Min
5A 10Ah
10A 20Ah
20A 40Ah
40A 80Ah
60A 120Ah
80A 160Ah
100A 200Ah
120A 240Ah
• Using a higher current than the recommendation may result in batteries not
being completely charged.
• Using a lower current than the recommendation will prolong the charging
time.
• The currents shown are the maximum recommended current for battery
charging. If a parallel consumer is connected then the current setting could
be increased.

READY TO USE

The table shows the estimated time to charge a battery from empty to 80%.
BATTERY SIZE
10Ah 40Ah 150Ah 900Ah 1800Ah 3600Ah
2h 7h 24h
5A
10A 4h 12h
40A 3h 18h
80A 2h 9h
6h
120A
Battery size Max
150Ah
300Ah
600Ah
1200Ah
1800Ah
2400Ah
3000Ah
3600Ah
18h
12h 24h
EN • 5
