AUTO ADAPTIVE
analyzes the
battery and selects optimal current for
the size of the battery. Auto Adaptive
shall not be used when charging lithium
batteries.
WARNING!
Do not charge Lithium
batteries (LiFePO4) with any of the Lead
Acid battery programs or vice versa.
LITHIUM Batteries with
DISCHARGE Protection
Some Lithium batteries have an internal
discharge protection that disconnects the
battery cells from the battery termi-
nals to avoid it becoming too deeply
discharged. If this is the case the charger
will start a wake up function to reconnect
the cells. If the battery voltage after the
wake up is below 8V, the charging pro-
cess will not start. This is because of the
inherent danger of charging to deeply
discharged Lithium batteries.
LOCK THE BUTTONS
Lock the buttons if charger used in public
or unattended.
Press and hold the buttons for 2s
to lock/unlock the buttons.
POWER SUPPLY
Use the showroom mode when using the
PRO120 to supply power to the car when
a battery is not connected. Spark protec-
tion is disabled when showroom mode is
chosen. When using supply mode with a
battery present, use the workshop mode.
4 • EN
50016574B CTEK PRO 120A, Manual, Print file_016.indd 2
PRO120
PRO120
CHARGE
Use to charge or
PRO120
maintain batteries
MAIN MENU
CHARGE
POWER SUPPLY
SETTINGS
SELECT
CHEMISTRY CHARGE
AUTO ADAPTIVE AUTO ADAPTIVE
LEAD ACID START
LITHIUM
BACK SELECT BACK SELECT
LEAD ACID CHARGE
NORMAL LEAD ACID
AGM NORMAL
CA/CA 60A
START
BACK SELECT BACK SELECT
Choose CHARGE OPTIONS
or START
LITHIUM CHARGE
LiFePO4 LITHIUM
LiFePO4
60A
START
BACK SELECT BACK SELECT
Choose CHARGE OPTIONS
or START
CONNECT BATTERY!
Standard display mode
Select in settings
CHARGE
12.4V
45.0A
STOP
PRO120
Press to scroll up in menu and to increase values
Press to scroll down in menu or to decrease values
Press to activate selected program or setting
Press to step back or stop in menu
CHARGE OPTIONS BATTERY SIZE
BATTERY SIZE
MAX CURRENT
BACK SELECT BACK
Choose BATTERY SIZE Lead Acid: 10–3600Ah
or MAX CURRENT
Lithium: 15–1200Ah
CHARGE OPTIONS MAX CURRENT
BATTERY SIZE
MAX CURRENT
BACK SELECT BACK
Choose BATTERY SIZE
or MAX CURRENT
CHARGE
CONNECT
BATTERY!
STOP
Advanced display mode
Select in settings
CHARGE
12.4V 45.0A
0:30h 23Ah
STOP
POWER SUPPLY
MAIN MENU
CHARGE
POWER SUPPLY
SETTINGS
SELECT
POWER SUPPLY
13.6V
60A
WORKSHOP
START
BACK SELECT
POWER SUPPLY
WORKSHOP
SHOWROOM
75Ah
SELECT BACK SELECT
CONNECT BATTERY!
60A
SELECT
STOP
5–120A
Standard display mode
Select in settings
WORKSHOP
MAX
13.6V
25.7A
STOP
POWER SUPPLY
Use the showroom mode when using the
PRO120 to supply power to the car when
a battery is not connected. Spark protec-
tion is disabled when showroom mode is
chosen. When using supply mode with a
battery present, use the workshop mode.
Use to supply vehicles with
power when removing
batteries, reprogramming
or diagnosing
VOLTAGE
13.6V
BACK SELECT
12.6–14.8V
MAX CURRENT
60A
BACK SELECT
5–120A
WORKSHOP
CONNECT
BATTERY!
Advanced display mode
Select in settings
WORKSHOP
13.6V 25.7A
0:30h 23Ah
STOP
