USER MANUAL
Z-WAVE MINI SENSOR
ZSE09
Z-Wave Plus Certified Device
WELL DONE!
You have picked the finest solution for your smart home, congratulations!
Now it's time to enjoy these great features of your new Mini Sensor:
- Accurate motion and light level detection
- Wireless notifications and low battery alerts (when included to a Z-Wave gateway controller)
- Custom automation scenarios based on both light and motion triggers (advanced
configuration required)
- Adjustable sensitivity levels for motion detection to fit your needs
- Ultra small and simple design
- Z-Wave Plus with improved 500 chip for faster and safer wireless communication
- Flexible and quick installation
SPECIFICATIONS
Model Number: ZSE09
Z-Wave Signal Frequency: 908.42 MHz
Power: 1 CR123A battery (included)
Power Consumption: 0.15W
Operating Temperature: 32 – 104 F
Motion detection: Up to 20 feet
Range: Up to 100 feet line of sight
Installation and Use: Indoor only
Dimensions: 1.9" x 1.8"
Weight: ½ oz
Z-WAVE COMMAND CLASSES
This device requires the following command classes to be supported and recognized by your
Z-Wave controller:
Advertisement
Table of Contents
Related Manuals for ZooZ ZSE09
Summary of Contents for ZooZ ZSE09
- Page 1 - Ultra small and simple design - Z-Wave Plus with improved 500 chip for faster and safer wireless communication - Flexible and quick installation SPECIFICATIONS Model Number: ZSE09 Z-Wave Signal Frequency: 908.42 MHz Power: 1 CR123A battery (included) Power Consumption: 0.15W Operating Temperature: 32 –...
- Page 2 COMMAND_CLASS_ZWAVEPLUS_INFO (V2) COMMAND_CLASS_VERSION (V2) COMMAND_CLASS_MANUFACTURER_SPECIFIC (V2) COMMAND_CLASS_DEVICE_RESET_LOCALLY (V1) COMMAND_CLASS_POWERLEVEL (V1) COMMAND_CLASS_BATTERY (V1) COMMAND_CLASS_ASSOCIATION (V2) COMMAND_CLASS_ASSOCIATION_GRP_INFO (V1) COMMAND_CLASS_WAKE_UP (V2) COMMAND_CLASS_NOTIFICATION (V4) NOTIFICATION_REPORT NOTIFICATION_TYPE_HOME_SECURITY NOTIFICATION_EVENT_HOME_SECURITY_MOTION_DETECTION_UNKNOWN_LOCATION NOTIFICATION_EVENT_HOME_SECURITY_NO_EVENT COMMAND_CLASS_SENSOR_BINARY (V2) SENSOR_BINARY_REPORT SENSOR_MOTION COMMAND_CLASS_CONFIGURATION (V1) COMMAND_CLASS_SENSOR_MULTILEVEL (V7) BEFORE YOU RETURN IT Let us know if you are having any issues installing or operating the device. Our fast and friendly tech support is here to help, every day of the year: ask@getzooz.com Get more helpful tips at getzooz.com INSTALLATION...
- Page 3 6. A new motion and light sensor will appear on your controller's device list Troubleshooting Tips If you are unable to include the Z-Wave Mini Sensor to your controller, please try one of the following: - Bring the Mini Sensor closer to your Z-Wave controller - Once in inclusion mode, press and release the Z-Wave button quickly 6-7 TIMES to ensure the command has gone through - Put your controller into EXCLUSION mode.
- Page 4 Group 2 for control command communication to associated Z-Wave devices in the network. Use parameters 2, 3, 5, and 8 to configure this group’s settings. Supported command classes: BASIC_SET Group 3 for notifications to Z-Wave devices associated in this group. Supported command classes: NOTIFICATION_REPORT_V4 Group 4 for notifications to Z-Wave devices associated in this group.
- Page 5 Values: 5 – 600 (seconds). 30 (seconds) – default setting. Size: 2 byte dec. Trigger Action Parameter 3: You can choose if your Mini Sensor turns an associated device on or off when sending the BASIC SET command. Use value 0 to turn the associated device OFF and value 255 to turn it ON.
- Page 6 How to read the LED indicator? Slow blink = Mini Sensor is powered on and NOT included to Z-Wave network Fast blink = Mini Sensor is in inclusion mode Fast flash = Mini Sensor is powered on and included to Z-Wave network Single flash = Mini Sensor indicates motion detection;...
- Page 7 See full list of Zooz distributors here: getzooz.com/buy During the Warranty Period, Zooz will repair or replace, at no charge, products or parts of a product that prove defective because of improper material or workmanship, under normal use and recommended maintenance.
- Page 8 CLAIMS OF ANY KIND ARISING IN CONNECTION WITH THIS AGREEMENT OR THE SALE OR USE OF PRODUCTS SHALL BE DEEMED WAIVED UNLESS MADE IN WRITING WITHIN THIRTY (30) DAYS FROM ZOOZ'S DELIVERY, OR THE DATE FIXED FOR DELIVERY IN THE EVENT OF NONDELIVERY.
