ZooZ 700 Series User Manual

USER MANUAL
SMART PLUG
ZEN04
FEATURES
Reliable Z-Wave™ control of
Ÿ
lamps and small appliances
Energy monitoring to help you
Ÿ
manage power use
Quick set-up: just plug it into a
Ÿ
grounded receptacle
Extra small, doesn't block the
Ÿ
other outlet
The latest S2 security and Z-Wave
Ÿ
Plus™ technology
Supports OTA firmware updates
Ÿ
ETL listed for safety standards
Ÿ
SPECIFICATIONS
Model Number: Z
Ÿ
Power: 120 VAC 60 Hz
Ÿ
Maximum Load: 15 A resistive,
Ÿ
150 W LED bulbs, 1000 W
incandescent, 1/3 hp motor
Operating Temperature: 32° –
Ÿ
104° F
Dimensions: 2.6" x 1.5" x 1.14"
Ÿ
Range: Up to 300 feet line of sight
Ÿ
Installation and Use: Indoor only
Ÿ
CAUTION
This is an electrical device. Please
use caution when installing and
operating the Smart Plug.
Remote control of appliances
may result in unintentional or
automated activation of power.
Do NOT use this Z-Wave device
to control electric heaters or
other appliances which produce
the risk of fire, burns, or electrical
shock when unattended.
INSTALLATION
Plug the Smart Plug into any
standard grounded 110 V
receptacle. Do NOT connect any
devices to the plug at this point.
Click the Z-Wave™ button to see if
the LED indicator comes on and
off. If the LED indicator doesn't
light up at all, please try a different
receptacle.
If it's still off, please get in touch
with our support team:
ask@getzooz.com
BEFORE YOU PLUG
ANYTHING IN
Make sure the load you are
about to connect does NOT
exceed 15 A in power. This Smart
Plug can hold up to 15 A in total.
Connecting heavy duty
equipment to this Smart Plug
will DAMAGE the device and
may cause the connected
appliance to malfunction. Do
NOT plug washers, dryers,
refrigerators, or motors over 1/3
hp to this Smart Plug.
WARNING
This product should be installed indoors
Ÿ
upon completion of any building
renovations.
Prior to installation, the device should be
Ÿ
stored in a dry, dust-and-mold-proof
place.
Do not install the Smart Plug in a place
Ÿ
with direct sun exposure, high
temperature, or humidity.
Keep away from chemicals, water, and
Ÿ
dust.
Ensure the device is never close to any
Ÿ
heat source or open flame to prevent fire.
Ensure the device is connected to an
Ÿ
electric power source that does not
exceed the maximum load power.
No part of the device may be replaced or
Ÿ
repaired by the user.
PAGE 1
www.getzooz.com
EN04
™
Z-WAVE
1. ADD DEVICE to your hub
Initiate inclusion (pairing) in the
app (or web interface). Not sure
how? ask@getzooz.com
2. ACTIVATE the plug
While the hub is looking for new
devices, click the Z-Wave™
button 3 times as quickly as
possible. The LED indicator will
start flashing blue to confirm
inclusion mode and turn green for
1 second once inclusion is
completed.
Choose your hub and scan the QR
code with your phone's camera.
Then click on the link to access the
step-by-step pairing instructions.
SmartThings
Hubitat
Home Assistant
NEED SOME HELP?
ask@getzooz.com
www.support.getzooz.com
TROUBLESHOOTING
The plug won't add to your
system? Try this:
1. Initiate EXCLUSION in your hub
and click the Z-Wave button 3
times as quickly as possible. Then
try adding it again a er it
successfully excludes (this works
as a reset and can be tried even if
the plug was never connected to
your hub in the past).
2. Click the Z-Wave button quicker
when adding it.
3. Bring the plug closer to your hub,
it may be out of range.
4. Double-check if the device is
powered.
5. Get troubleshooting tips specific
to your hub at
www.support.getzooz.com
EXCLUSION (REMOVE DEVICE)
1. Bring the plug within direct
range of your Z-Wave hub.
2. Put the Z-Wave hub into
exclusion mode (not sure how to
do that? ask@getzooz.com).
3. Click the Z-Wave button 3
times as quickly as possible.
4. Your hub will confirm exclusion
and the plug will disappear from
your controller's device list.
CONTROL
™
Z-WAVE™
BUTTON
™
™
™
™
™
PAGE 2
