Page 2: Table Of Contents
Contents Notes ............- 1 - Product Introduction ......... - 2 - Production Instruction ........- 2 - Product Feature ..........- 2 - Product Structure ........- 3 - Technical Parameters ........ - 9 - OSD Menu tree .......... - 10 - Product Installation ........ -
Page 3: Notes
1080P XVI Camera Series XV2100(V0.02) Notes Read this manual carefully before use. 1)To reduce the risk of electric shock, do not open the machine and maintain by yourself, please consult a professional service person. 2)To prevent fire or shock hazard, use the power after safety certification, the input voltage, current, voltage polarity and operating temperature must meet the requirements of this camera. -
Page 4: Product Introduction
1080P XVI Camera Series XV2100(V0.02) Product Introduction 2.1 Production Instruction This series of cameras are adopted CMOS image sensor with high performance, which provides mega pixel resolution and supports HD video. Moreover, it supports monitoring signals coaxial transmission. Transmission distance can reach more than 300M based on 75-3 coaxial cable. -
Page 5: Product Structure
1080P XVI Camera Series XV2100(V0.02) Product Structure The followings are the dimensions of some products. No further notice for the upgraded version. Photo 3-2 Indoor IR Dome Camera 20mm 43mm Photo 3-3 Indoor Mini Camera... - Page 6 1080P XVI Camera Series XV2100(V0.02) 83.8mm 205mm Photo 3-4 Indoor BOX Camera 93.2 Photo 3-5 Outdoor IR Dome Camera Photo 3-6 Outdoor IR Dome Camera...
- Page 7 1080P XVI Camera Series XV2100(V0.02) Photo 3-7 Outdoor Vari-focal Dome Camera Photo 3-8 Outdoor Vari-focal Dome Camera Photo 3-9 Outdoor Vari-focal Dome Camera...
- Page 8 1080P XVI Camera Series XV2100(V0.02) 173.6 69.9 Photo 3-10 Outdoor IR Bullet Camera 68.7mm 154mm Photo 3-11 Outdoor IR Bullet Camera Photo 3-12 Outdoor IR Bullet Camera...
- Page 9 1080P XVI Camera Series XV2100(V0.02) 72mm 217mm Photo 3-13 Outdoor IR Bullet Camera 283.7 mm(Adjustable) 75.5 Photo 3-14 Outdoor IR Bullet Camera Photo 3-15 Outdoor IR Bullet Camera...
- Page 10 1080P XVI Camera Series XV2100(V0.02) Photo 3-16 Outdoor Vari-focal Bullet Camera Photo 3-17 Outdoor Vari-focal Bullet Camera 327mm 111.8mm Photo 3-18 Outdoor Vari-focal Bullet Camera...
-
Page 11: Technical Parameters
1080P XVI Camera Series XV2100(V0.02) Technical Parameters Resolution HD-Analog: 1920 1080p(1080p/30fps) 1280 720p(720p/60fps) Analog:960H Image Sensor 1/2.9” 2.0M SONY IMX323LQJ-C Exmor CMOS Total Pixels 1945(H) 1109(V) Effective Pixels 1945(H) 1097 (V) Scanning System Progressive Press and hold for 5 seconds the "menu" button to switch Video Output output format among AHD CVI and TVI Press the button once to activate the OSD, which can also... -
Page 12: Osd Menu Tree
1080P XVI Camera Series XV2100(V0.02) OSD Menu tree NORMAL DEBLUR 0~20 0~20 PRESET KELVIN R-GAIN B-GAIN NIGHT ONLY 0~20 0~20 0~20 SMART-IR LVL 0~20 0~20 0~20 GAMMA 0.45 0.5 0.55 0.6 0.65... - Page 13 1080P XVI Camera Series XV2100(V0.02) LEVEL 1080P 720P HD-CbCr YUV SD-CbCr 25/30 50/60 PAL NTSC FULL COMP USER OFFSET 0~20 V0.0.2 0~255 COMM ADJ LANGUAGE ENG CHN ZOOM DIS OFF ON 0~15 0~60 0~40 0~40 0~40 SPECIAL 0~20 0~20 0~20 0~20 0~60 0~40...
-
Page 14: Product Installation
1080P XVI Camera Series XV2100(V0.02) Product Installation 6.1 Note 1) Make sure the unit is powered off before installation. 2) Check power supply voltage consistent with the electric voltage to prevent voltage unworthy, resulting in damage to the device. 3) Do not use in the environment beyond the boundaries of the temperature, and maintain good ventilation to prevent the rain in order to reduce the risk of fire or electric shock. - Page 15 1080P XVI Camera Series XV2100(V0.02) bracket or base. If the wooden wall, use self-tapping screws to mount. 3. Mounting the camera a. Dome Camera Adjust the lens position and make it aim at the monitoring points and present a clear picture, manually fix lens location and adjust the hemisphere cover.
-
Page 16: Connection
1080P XVI Camera Series XV2100(V0.02) 6.4 Connection Connection as show in the figure below... -
Page 17: Appendix: Faq
