INSTRUCTION MANUAL
Ver 1.0
Night Scout TVI
XIRAT216JUN22

Advertisement

Table of Contents
loading

Related Manuals for Rugged CCTV Night Scout TVI

Summary of Contents for Rugged CCTV Night Scout TVI

  • Page 1 INSTRUCTION MANUAL Ver 1.0 Night Scout TVI XIRAT216JUN22...
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN THE COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage"...
  • Page 3 NOTICE Important Safety Guide 1. Read, heed and follow all the Instructions Read all the safety and operating instructions before using the product. 2. Keep this manual Keep this manual for reference in future. 3. Attachments / Accessories Use only the attachments or accessories specified by the manufacturer. 4.
  • Page 4 NOTICE Caution  Operating  Before using, make sure that the power supply and others are properly installed.  While operating, if any abnormal condition or malfunction is observed, stop using the product immediately and then contact your local dealer. ...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Introduction Model Code Features Package Components Main Part Description Installation DIP Switch Setup Installation with Ceiling Mount Bracket Installation with Wall Mount Bracket Wiring and Cabling Operation Check Point before Operation Check Points for Preset and Pattern Function before Operation OSD Menu Reserved Preset (Hot Keys) Preset...

  • Page 6: Model Code

    INTRODUCTION Model Code Night Scout TVI...

  • Page 7: Features

    INTRODUCTION Features  Powerful Zoom Camera & Setup Options  Image Sensor 1/3" Panasonic CMOS Sensor, 2 Mega pixels 30 Optical Zoom, 12 Digital Zoom  Zoom  Day & Night, Privacy Mask  BLC, WDR, HLC function  NR (Noise Reduction) Function ...
  • Page 8 INTRODUCTION  Preset, Pattern, Swing, Group, Schedule, Privacy Mask and More…  MAX. 209 Presets are programmable and each preset can have its own paramete values independently from the other presets. For an example, refer to the below table. Preset No. White Balance Auto Exposure Label...
  • Page 9 INTRODUCTION  Alarm In/Out Function  3 alarm sensor inputs and 2 alarm sensor outputs are available.  Alarm sensor input is decoupled with photo-couplers to avoid external electric noise and shock perfectly.  Both of N.O.(Normal Open) sensors and N.C.(Normal Close) sensors can be used and the signal range of the sensor input is from DC 5.0V to 12.0V for various applications.

  • Page 10: Package Components

    INTRODUCTION Package Component  Product & Accessories Power Cable BNC Cable Wrench / Screw Manual Manual  Main Body & Accessories  Brackets (Optional)  Wall Mount Bracket & Screws  Ceiling Mount Bracket & Screws...

  • Page 11: Main Part Description

    INTRODUCTION Main Part Description Terminal Block Mount Adapter Wiper (Option) DIP Switch CDS Sensor IR LED  DIP Switch Used to set up camera IDs and protocols.  Mount Adapter Used to assemble the camera body and bracket.  Wiper Wipe out water drops on front glass.

  • Page 12: Dip Switch Setup

    INSTALLATION DIP Switch Setup Before installing the camera, set up the DIP switch to configure the camera ID and the communication protocol.  Camera ID Setup  ID numbers of cameras are set up with binary numbers. See the examples shown below. Binary Value ex) ID=5 ex) ID=10...
  • Page 13 INSTALLATION  Communication Protocol Setup  Select an appropriate Protocol with the DIP switch combination. Switch Mode Protocol (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps HIKVISION-C Coaxitron (TVI model only) Others Reserved ...

  • Page 14: Installation With Ceiling Mount Bracket

    INSTALLATION Installation with Ceiling Mount Bracket ① Prepare the ceiling mount bracket, and ② Hook up “Drop Prevention Spring” on assemble the bracket and mount adapter main body to prevent camera from as below. (Anchor Bolt 3/8"70) unexpected drop and connect the wires as below.

  • Page 15: Installation With Wall Mount Bracket

    INSTALLATION Installation with Wall Mount Bracket ① Prepare the wall mount bracket, and ② Hook up “Drop Prevention Spring” on assemble the bracket and mount adapter main body to prevent camera from as below. (Anchor Bolt 3/8"70) unexpected drop and connect the wires as below.

  • Page 16: Wiring And Cabling

    INSTALLATION Wiring and Cabling  Power Input  Carefully check the voltage and current capacity of the rated power. Input Voltage Range Current Consumption AC 17V ~ 29V 3.0 A  RS-485 Communication  For PTZ control, connect the cable(s) to your keyboard or DVR. To connect multiple cameras to a single controller, RS-485 communication should be connected in parallel as shown below.
  • Page 17 INSTALLATION  Alarm Input Internal +5V~12V IN COM+ IN 1- Sensor 1 IN 3- Sensor 3 Before connecting sensors, check driving voltages and output signal types of the sensors Since output signal types of the sensors are divided into Open Collector type and Voltage Output type in general, the wiring must be done properly after considering those types.

  • Page 18: Operation

    OPERATION Check Points before Operation  Before turning on the system, check if the wire(s) and cable(s) are connected properly.  Check if the camera ID on the controller is properly selected. The camera ID must be identical to that of the target camera. The camera ID can be checked by reading the DIP switch of the camera or on OSD.

  • Page 19: Osd Menu

    OPERATION OSD Menu  Function With OSD menu, the system can be properly configured for each application.  Entering into OSD Go Preset [95] Reserved Presets (Hot Keys)  Description Some Preset numbers are reserved to change some parameters without entering into OSD menu.

  • Page 20: Preset

    OPERATION Preset  Function MAX. 209 presets can be configured except the Reserved Presets (Hot Camera parameters such as White Balance, Auto Exposure and Keys). others can be set up independently and each preset can have its own parameter values independently from the other persets. When setting up presets with a controller, Label should be blank and Video settings should be set to "GLOBAL"...

  • Page 21: Pattern

    OPERATION Pattern  Function This function is that the camera memorizes the path (mostly curve path) by the joystick of the controller and revives the trajectory operated by joystick as closely as possible. MAX. Patterns programmable Maximum communication commands can be programmed in a pattern. ...

  • Page 22: Group

    OPERATION Group  Function This function is that the camera memorizes the combination of Presets, Pattern and/or Swings sequently and runs Presets, Pattern and/or Swings repetitively. MAX. 8 sets of Group are programmable. Each group can have MAX. 40 actions which are the combination of Preset, Pattern and Swing.
  • Page 23 OPERATION  Alarm Input 3 Alarm Inputs are available. When external sensors activate, the camera runs pre-defined actions such as Preset, Pattern, Swing and Group. After the pre-defined time period passed, “Post Alarm” activates, which is pre-defined. Note that only the latest alarm input is effective when multiple sensors are activated at the same time.

  • Page 24: Osd Display

    OPERATION OSD Display Action Title Camera ID LABEL12345 PRESET1 Alarm Information I:-2- O:1- Preset Label CAM 1 15/40/x1/N P/T/Z Information  P/T/Z Information Displays the pan/tilt positions and zoom magnification.  Camera ID Displays the selected Camera ID (Address).  Action Title Identfies Actions "PRESET xxx"...

  • Page 25: Osd Menu

    OSD MENU Quick Programming Guide  The menu items with < > always have sub-menus.  To go to submenus or make the cursor move to the right, press NEAR key.  To go to the previous-upper level menus, press FAR key. ...

  • Page 26: Display Setup

    OSD MENU Display Setup Display setup allows you to program how labels are DISPLAY SETUP displayed on the monitor. In case of AUTO, the labels are ------------------------ displayed on the monitor when there are any changes in CAMERA ID parameters. PTZ INFORMATION AUTO ACTION TITLE...

  • Page 27: Privacy Zone Mask Setup

    OSD MENU  Compass Direction Setup Move the camera to a target position and press NEAR SET NORTH DIRECTION button to save the direction as North. The direction is the ------------------------ reference direction to assign other compass directions. MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL Privacy Zone Mask Setup...
  • Page 28 OSD MENU  Privacy Zone Mask Area Setup Move your camera to an area to mask. Then a mask and the EDIT MASK 1 menu to adjust the mask size will be displayed. ------------------------ MOVE TO TARGET POSITION [NEAR:SELECT/FAR:CANCEL]  Privacy Zone Mask Size Setup Adjusts the mask size.

  • Page 29: Colock Setup

    OSD MENU Clock Setup Configures current time and how to display in OSD CLOCK SETUP ------------------------ [ON/OFF]  Display Date DISPLAY DATE Configures whether Date will be displayed DISPLAY TIME in OSD or not SET CLOCK 01/JAN/2013 TUE [ON/OFF]  Display Time 00:01:02 [hh:mm:ss] Configures whether Time will be displayed...

  • Page 30: Camera Setup

    OSD MENU Camera Setup Sets the general functions of zoom camera module. CAMERA SETUP ------------------------  HD Video [1080p30/720p60/720p30] or HD VIDEO OUT 1080p30 [1080p25/720p50/720p25] FOCUS MODE SEMIAUTO DIGITAL ZOOM Sets the video resolution of TVI. Match the FLICKERLESS resolution with the setting of DVR. If there IMAGE FLIP is no confirmation within 10 seconds by <WHITE BALANCE SETUP>...
  • Page 31 OSD MENU  Flickerless [ON/OFF] If NTSC camera is used in 50Hz frequency circumstance or if PAL camera is used in 60Hz frequency circumstance, there should be flicker on monitor since power frequency different from sync frequency of camera. In this case, set it to ON to prevent flicker ...
  • Page 32 OSD MENU  Auto Exposure Setup  Day/Night [AUTO/DAY/NIGHT] AE SETUP-GLOBAL Sets Day&Night mode. ------------------------ DAY/NIGHT AUTO  Backlight [ON/OFF] BACKLIGHT Sets Backlight Compensation. If a bright AE MODE AUTO backlight is present, the subjects in the IRIS picture may appear dark or as a silhouette. Backlight compensation enhances objects SHUTTER in the center of the picture.
  • Page 33 OSD MENU  Special Setup  Auto DSS [ON/OFF] SPECIAL When set to ON, ensure that the ------------------------ slow shutter is set to automatically AUTO DSS NIGHT>DAY LEVEL when the brightness drops. APERTURE  Night > Day Level [0 ~ 28] STABILIZATION Adjust the sensitivity to change Night mode to Day mode.

  • Page 34: Motion Setup

    OSD MENU Motion Setup Sets the general functions of Pan/Tilt motions. MOTION SETUP ------------------------  Motion [ON/OFF] MOTION LOCK Lock If Motion Lock is set to ON, it is impossible to PWR UP ACTION set up and delete Preset, Swing, Pattern and AUTO FLIP Group.
  • Page 35 OSD MENU  Parking Action Setup This feature allows the camera to begin a specified action PARKING ACTION SETUP after a programmed time of inactivity. ------------------------ PARK ENABLE  Park Enable [ON/OFF] WAIT TIME 00:10:00 If Park Enable is set to ON, the camera PARK ACTION HOME runs an assigned function automatically if...
  • Page 36 OSD MENU  Alarm Input Setup Defines Alarm Function. When an alarm is receive, an ALARM INPUT SETUP input signal to the camera triggers the user-defined action ------------------------ programmed for the alarm. ALARM NO.  Alarm No [1~3] TYPE N.OPEN ACTION NOT USED Selects a sensor number to set up.

  • Page 37: Preset Setup

    OSD MENU Preset Setup  Preset [1~255] MAX. Presets except PRESET SETUP Reserved Presets (Hot Keys) Number ------------------------ Selects a preset number to set up. If a PRESET NO. selected preset is already defined, the CLR PRESET CANCEL camera moves to the pre-defined position <EDIT SCENE>...
  • Page 38 OSD MENU  Preset Scene Setup ○ 1 Use the Joystick to move the camera to a desired EDIT SCENE - PRESET 1 position. ------------------------ ○ 2 Save the preset position by pressing NEAR key. ○ 3 Press FAR key to cancel targeting the preset position. MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL]...

  • Page 39: Swing Setup

    OSD MENU Swing Setup  Swing [1~10] SWING SETUP Number Selects a Swing number to edit. If the ------------------------ selected Swing is not defined, "NOT USED" SWING NO. is displayed in the 1st Position and the 2nd 1ST POS. NOT USED 2ND POS.

  • Page 40: Pattern Setup

    OSD MENU Pattern Setup  Pattern Number [1~8] PATTERN SETUP Selects a Pattern number to edit. If the ------------------------ selected pattern number is not PATTERN NO. defined, "UNDEFINED" will UNDEFINED CLR PATTERN CANCEL displayed under the selected pattern RUN PATTERN number.

  • Page 41: Group Setup

    OSD MENU Group Setup  Group Number [1~8] GROUP SETUP Selects a Group number to edit. ------------------------ If the selected Group number is not GROUP NO. UNDEFINED defined, "UNDEFINED" will CLEAR GROUP CANCEL displayed under the selected Group RUN GROUP number.
  • Page 42 OSD MENU ③ Define Action, Dwell time and Option. Note that the dark EDIT GROUP 1 rectangular is the cursor. Move the cursor LEFT/RIGHT ------------------------ to select an item and move cursor UP/DOWN to change NO ACTION ### DWELL OPT each parameter.
  • Page 43 OSD MENU ⑥ After finishing setting up, press FAR key to exit. Then the EDIT GROUP 1 cursor will move to “SAVE”. Press NEAR key to save the ------------------------ data. NO ACTION ### DWELL OPT ------------------------ 1 PRESET 1 00:03 360 2 NONE 3 NONE 4 NONE...

  • Page 44: Schedule Setup

    OSD MENU Schedule Setup  Schedule No [1~8] SCHEDULE SETUP Selects a Schedule to be configured. ------------------------ SCHEDULE NO  Action [NOT USED/PRESET/PATTERN/SWING ACTION NOT USED /GROUP] HOLD TIME ENDLESS POST ACTION HOME Consigures a function to be run for a CYCLE ONCE configured time period.

  • Page 45: Ir Led Setup

    OSD MENU IR LED Setup  CDS Value [0(Dark)~255(Bright)] IR LED SETUP Display current value of Illuminance ------------------------ CDS sensor. CDS VALUE DAY>NIGHT LEVEL  Day->Night Level [0(Dark)~255(Bright)] NIGHT>DAY LEVEL Set the level to switch from Day to DWELL TIME 10SEC FAR IR VALUE AUTO...

  • Page 46: Password Setup

    OSD MENU Password Setup  Password Setup [ON/OFF] PASSWORD SETUP Configures whether OSD menu will be ------------------------ protected with a password. A password CHECK PASSWORD configured [EDIT <EDIT PASSWORD> PASSWORD]. BACK EXIT [Caution] It is mandatorily recommended that a user must take a memo for a password before a user applies a password to a system.
  • Page 47 OSD MENU  Edit Password A password should be made up with a 4 Alphanumeric EDIT PASSWORD combination ------------------------ ---------- 1234567890 ABCDEFGHIJ CANCEL KLMNOPQRST Current Cursor Position UVWXYZabcd efghijklmn opqrstuvwx ① With Left/Right/Up/Down of the joystick, move to a yz<>-/:. desired Alphabet or a desired number in the ---------- Alphanumeric set.

  • Page 48: System Initialization

    OSD MENU System Initialization  Clear All Data Deletes all configuration data and the system SYSTEM INITIALIZE is set to the factory default. ------------------------  Clear Display Set Initializes all the configuration data for Display. CLEAR ALL DATA CLR DISPLAY SET ...
  • Page 49 OSD MENU  Camera Parameters HD Video Out 1080p30(p25) AE Mode AUTO Focus Mode SemiAuto Auto DSS Digital Zoom Night > Day Level Flickerless Aperture Image Flip White Balance AUTO Stabilization Day&Night AUTO Backlight Defog...

  • Page 50: Specifications

    SPECIFICATIONS Specifications [Note] 1) Specification and features are subject to change without prior notice. 2) Specification and features are different by models. 3) Check the voltage and current capacity of rated power carefully. CAMERA PART Image Sensor 1/3'' Panasonic CMOS Sensor Total Pixels 2,000K pixels 30 Optical Zoom, 12 Digital Zoom...
  • Page 51 SPECIFICATIONS MECHANISM PART 360(Endless) Movement Range Tilt -20 ~ 90 Preset 240/sec. Speed 0.1 ~ 240/sec. (Proportional to Zoom) Swing 1~ 90/sec. Preset 209 Presets (Label, Independent Camera Parameter Setting) Pattern 8 Patterns [768 Commands(Approx. 5 Minute) / Pattern] Swing 10 Swings 8 Groups (MAX.

  • Page 52: Dimension

    SPECIFICATIONS Dimension  Main Body  Ceiling Mount Type 161.5  Wall Mount Type 410.5 280.5 [Unit : mm]...
