Page 1: Instruction Manual
SCOUT III Infrared PTZ CAMERA Instruction Manual 1-866-301-2288 Please read this manual carefully before installation and use (This manual is subject to change without notice) - Page 2 IR Dome Camera Instruction Manual Precautions: 1. Non-technicians should not attempt to operate this dome device before reading this manual thoroughly. 2. Remove any power to the dome before attempting any operations or adjustments inside the dome cover to avoid potential damage to the mechanism. 3.
- Page 3 IR Dome Camera Instruction Manual Contents Chapter 1 Important Safeguards ........3 Chapter 2 Product Introduction ......... 4 2.1 Performance Characteristics ........... 4 2.2 Specific functions ..............4 2.3 Features ..................5 Chapter 3 Wiring and Setup ..........7 3.1 System Connection Diagram ..........7 3.2 Communication settings ............
-
Page 4: Chapter 1 Important Safeguards
IR Dome Camera Instruction Manual Chapter 1 Important Safeguards Read the instruction manual before attempting installation or operation of ● the dome device. Cautions during transportation ● Avoid any damage to the product caused by heavy pressure, shock or immersions during transportation and storage. -
Page 5: Chapter 2 Product Introduction
IR Dome Camera Instruction Manual Chapter 2 Product Introduction 2.1 Performance Characteristics 0-255 individually addressed units. The dome address is defined using a dip switch with 8 positions (Binary addressing scheme) Integrate multi-protocol and auto protocol differentiation. Note: The dome device auto differentiate the protocol of the controller only on the first communication. -
Page 6: Features
IR Dome Camera Instruction Manual 2.3 Features This section introduces the main features and performance of IR dome camera. This section does not relate to the operation guide. Operation may differ from different dome devices. User shall follow the instruction manual provided by the manufacturer. Specific operation may be required in certain circumstances. - Page 7 IR Dome Camera Instruction Manual changing light. 5） Day/night switch function(applicable to the camera module having the function of color and black-white switch) The function of color and black-white switch will be achieved automatically. 6） Menu operation Call No. 90 preset position to enter the dome menu.
-
Page 8: Chapter 3 Wiring And Setup
IR Dome Camera Instruction Manual Chapter 3 Wiring and Setup 3.1 System Connection Diagram AC24V+(Red) AC24V-(Black) Video Output GND(Yellow-Green) <<连续按 OPEN GND(Yellow-Green) 选择 P： 预置位, RS485+ Orange RS485- Yellow T： 花样轨迹， V： 矢量轨迹 Caution: This operation should be performed with the power OFF 3.2 Communication settings Before installation and use, the unique address for each dome and the communication protocol including transmission speed (baud rate) should be set to correspond with the chosen control system. - Page 9 IR Dome Camera Instruction Manual On/Off status Baud rate digit digit 2400 4800 This figure shows protocol of PELOC-D, baudrate of 2400 9600 19200 3.2.2 Address setting of each dome Setting address for dome device (This figure shows the address of dome device No.1) 2 3 4 5 6 7 On/Off switch and matching...
-
Page 10: Chapter 4 Quick Start Operation Guide
IR Dome Camera Instruction Manual Chapter 4 Quick Start Operation Guide 4.1 Wiring Instruction Caution: Do not turn the power ON until you have finished all connections and settings. AC24V+(Red) AC24V-(Black) Video Output GND(Yellow-Green) <<连续按 OPEN GND(Yellow-Green) 选择 P： 预置位, RS485+ Orange RS485- Yellow T：... -
Page 11: Start Testing
IR Dome Camera Instruction Manual Attention: If the protocol setting of the dome is set to auto detection, the protocol of keyboard controller can be set arbitrarily. But its baud rate should be set identical with that of the dome device. 4.6 Start testing When all of the above settings are completed you can start testing the dome functionality Zooming of the camera can be controlled by... -
Page 12: Chapter 5 English Menu Operation Instruction
IR Dome Camera Instruction Manual Chapter 5 English Menu Operation Instruction 5.1 Main menu 1. Call No.90 preset position on the keyboard to enter the main menu of dome device . 2. Select options joystick only between up and down, the arrow points to the current selected option. - Page 13 IR Dome Camera Instruction Manual 1～165 Press OPEN 1～165 0123456789 Press CLOSE 0123456789 IRIS CLOSE When Done IRIS CLOSE When Done ②.Set Preshot Move the cursor to select preset position. Move the joystick left/right or press OPEN to enter the setting (ensure the preset position data you desire to save) . Press CLOSE to finalize your selection and the screen will display Stored as illustrated below.
- Page 14 IR Dome Camera Instruction Manual Sector Setup 1 Number Display Options Press OPEN or joystick left/right 2 Name _ _ _ _ _ _ 1.PreShot Setup 3 Pan Start POS 2.Sector Setup 4 Pan End POS 3.Coordinates 5 Tilt Start POS 4.Crosshairs Press CLOSE 6 Tilt End POS...
- Page 15 IR Dome Camera Instruction Manual communication setting of this dome device. 3. Control Options Move the joystick up/down to Control Options. Joystick left/right or press OPEN to enter its submenu. Control Options 1 Set Pan and Tilt 1.Language English Press OPEN or 2 Set Default Function 2.Display Options joystick left/right...
-
Page 16: Auto Focus
IR Dome Camera Instruction Manual ①. Default Function P/V/T Move the joystick up/down to select Default Function. Move the joystick left/right to select preset/tour/PTZ Home position. Select one preset position randomly or execute one vertical scan action. ②. Number Move the joystick up/down to select Number. Joystick left/right to confirm the selection. PS: Program the number of preset position. -
Page 17: Clear Memory
IR Dome Camera Instruction Manual PTZ: Auto AE on when pan, tilt, zoom action operated through joystick. OFF: Auto AE off when pan, tilt, zoom action operated through joystick. Z: Auto focus when zoom Press CLOSE to exit and return to upper menu. ⑰.VectorScan AF Move the joystick up/down to select VectorScan AF. - Page 18 IR Dome Camera Instruction Manual Diagnostic Options Press OPEN or 1 Clear Memory Camera: XXXXX joystick left/right 2 Restore Def Setting Protocol: XXXXX 3 Color System Baudrate: XXXX 4 Scan & Camera Reset（NA） Dome NO.: XXXX Press CLOSE 5 Dome Information Version: XXXXX IRIS CLOSE to Exit IRIS CLOSE to Exit...
- Page 19 IR Dome Camera Instruction Manual Camera Exposure 1 AE Mode AUTO Camera Options Press OPEN or 2 Slow Shutter joystick left/right 1Zoom and Focus 3 Shutter Speed Auto 2 Camera Exposure 4 Iris Level Auto 3 Mask Zone 5 AGC Level Auto 4 Mask Color Press CLOSE...
-
Page 20: Mask Color
IR Dome Camera Instruction Manual ⑭.Mask Color Move the joystick up/down to select Mask Color. Move the joystick left/right or press OPEN to confirm the selection Camera Options Press OPEN or joystick left/right 1 Zoom and Focus Mask Color 2 Camera Exposure 1 Mask Color Gray5 3 Mask Zone... - Page 21 IR Dome Camera Instruction Manual ⑨. Stabilization Move the joystick up/down to select Stabilization. Joystick left/right to select OFF/ ON. ⑩. Function OSD Move the joystick up/down to select Function OSD. Joystick left/right to select ON/OFF. 11 WDR (Need camera support) Move the joystick up/down to select WDR.
- Page 22 IR Dome Camera Instruction Manual ⑤. Delete a Tour Move the joystick up/down to select Delete a Tour. Move Are you sure to do this? the joystick left/right or press OPEN to confirm. User will IRIS OPEN to Confirm use this function to delete the Vectorscan. IRIS CLOSE to Cancel ⑥.
- Page 23 IR Dome Camera Instruction Manual ③.Run a VectorScan Move the joystick up/down to select Run a VectorScan. Move the joystick left/right or press OPEN to confirm and enter the menu. ④. Delete a VectorScan Move the joystick up/down to select Delete a VectorScan. Are you sure to do this? Move the joystick left/right or press OPEN to confirm and IRIS OPEN to Confirm...
- Page 24 IR Dome Camera Instruction Manual Chapter 6 Short-cut Operations and Specification of IR Dome Camera 6.1 Short-cut operation table System Preset Operation Table Preset 80 (Call 80) Run PTZ Tour 1 Preset 81(Call 81) Run PTZ Tour 2 Preset 82 (Call 82) Run PTZ Tour 3 Preset 83 (Call 83) Start VectorScan 1...
- Page 25 IR Dome Camera Instruction Manual Baudrate 2400, 4800, 9600, 19200bps (user adjustable) Compatible cameras SONY,LG,CNB,SAMSUNG Auto flip 180° Tour 6 groups，each group can set 16 presets IR distance Auto IR flashlight Not support Horizontal scan 84° /S Two point scan 200°...
- Page 26 IR Dome Camera Instruction Manual Trouble Shooting of IR Dome Camera： Problem S.N. Possible Reason Troubleshooting Remarks Description Check if the power Power cable is connected cable is connected to improperly. power of AC 24V Fault of power PCB of dome Change the power After power on, Please follow the...
- Page 27 IR Dome Camera Instruction Manual Fault occurs when the dome Vertical range is device is in tilt movement. It Check and adjust the not within 90 may be caused by obstacle mechanical degree with of camera of other object, installation large deviation which lead to early tilt movement...
