Robe ColorStrobe IP User Manual page 23

Version: 1.1
Mode 1 –RGBW mode , Mode 2 –full RGBW , Mode 3 –Zone effect mode , Mode 4 – 3-zone mode, Mode 5 – 6-zone mode
Mode/channel
1 2 3 4
1 1 1 *
* 2 * *
2 3 2 *
* 4 * *
3 5 3 *
* 6 * *
4 7 4 *
* 8 * *
5 9 5 *
6 10 6 *
7 11 7 *
ColorStrobe IP - DMX protocol
DMX
5
value
Red/Cyan foreground (8 bit)- all zones
*
0 - 255 Red orCyan colour saturation control - coarse (0-100%)
Red/Cyan foreground (16bit)- all zones
*
0 - 255 Red or Cyan colour saturation control - fine
Green/Magenta foreground (8-bit) - all zones
*
0 - 255 Green or Magenta colour saturation control - coarse (0-100%)
Green/Magenta foreground (16bit) - all zones
*
0 - 255 Green or Magenta colour saturation control - fine
Blue/Yellow foreground (8 bit) - all zones
*
0 - 255 Blue or Yellow colour saturation control - coarse (0-100%)
Blue/Yellow foreground (16bit) -all zones
*
0 - 255 Blue or Yellow colour saturation control - fine
White foreground (8 bit) - all zones
*
0-255
White colour saturation control - coarse (0-100%) -RGBW mode only
White foreground (16 bit) - all zones
*
0 - 255 White colour saturation control - fine (RGBW mode only)
CTC
*
0 No function
1-255 Col. temperature correction
Virtual colour wheel
*
0 No function
1-2 White 2700 K
3 White 2700 K (Halogen lamp mode)*
4-5 White 3200 K
6 White 3200 K (Halogen lamp mode)*
7-9 White 4200 K
10-12 White 5600 K
13-15 White 8000 K
16 Blue (Blue=full, Red+Green+White=0)
17-55 Red=0, Green->up,Blue =full, White=0
56 Light Blue (Red=0, Green=full, Blue =full, White=0)
57 - 95 Red=0, Green=full, Blue->down, White=0
96 Green (Red=0, Green=full, Blue =0, White=0)
97 – 134 Red->up, Green=full, Blue=0, White=0
135 Yellow (Red=full, Green=full, Blue=0, White=0)
136 - 174 Red=full, Green->down, Blue=0, White=0
175 Red(Red=full, Green=0, Blue=0, White=0)
176 -214 Red=full, Green=0, Blue->up, White=0
215 Magenta (Red=full, Green=0, Blue=full, White=0)
216 - 246 Red -> down, Green=0, Blue=full, White=0
247 Blue (Red=0, Green=0, Blue=full, White=0)
248-251 Rainbow effect (with fade time)from slow-> fast
252-255 Rainbow effect(without fade time) from slow-> fast
Intensity foreground (8bit)-all zones
*
DMX protocol
Function
Page 1
Type of
control
proportional
proportional
proportional
proportional
proportional
proportional
proportional
proportional
step
proportional
step
step
step
step
step
step
step
step
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
proportional
