- Page 1 USER AND INSTALLATION MANUAL ENGLISH COMM4NDER. ® PART01338 PART01174 CO2 FX CONTROL GEAR rev 01-00 rev 01-00...
-
Page 2: Disclaimer
Any brand names mentioned in this manual are registered trademarks of their respective owners. LIABILITY MAGIC FX accepts no liability for claims from third parties arising from unauthorised use, use other than that stated in this manual, and use other than in accordance with the General Conditions registered at the Chamber of Commerce. -
Page 3: Table Of Contents
TABLE OF CONTENTS Disclaimer Trademarks Liability Foreword Language Revision table Meet the MAGICFX FX-COMM4NDER! ® Main parts Technical data Product identification Accessories Fire safely! General safety rules Connecting FX-machines Precautions for operation Let’s fire! Connect the MAGICFX FX-COMM4NDER ® Fire Clean up Maintenance Troubleshooting... -
Page 4: Foreword
FOREWORD Congratulations! You have bought a great new product from MAGIC FX. This manual contains all information required for the intended use of the equipment. Deviation from the described intended use can result in a hazardous situation and/or property damage. -
Page 5: Meet The Magicfx ® Fx-Comm4Nder
MEET THE MAGICFX FX-COMM4NDER! ® The MAGICFX FX-COMM4NDER is a 4 channel controller for 100-250Vac ON/OFF special effects ® machines. You can fire multiple machines one at a time or simultaneously. MAIN PARTS FX LED INDICATOR MASTER FIRE BUTTON 4 FIRE BUTTONS KEYSWITCH (ON/OFF) SAFETY BUTTON POWER INPUT... -
Page 6: Technical Data
TECHNICAL DATA Product Product Name MAGICFX FX-COMM4NDER ® Product Code MFX3203 Product Type Control Gear Main Length (mm/in.) 205 / 8.1 Dimensions Width (mm/in.) 250 / 9.8 Height (mm/in.) 102 / 4.0 Weight Empty weight (kg/lb.) 2.8 / 6.2 Package Length (mm/in.) -
Page 7: Accessories
ACCESSORIES Code Product MFX0311 Neutrik powerCON TRUE1 - Male to Female - Link cable 10m ® MFX0312 Neutrik powerCON TRUE1 - Male to Female - Link cable 20m ® MFX0322 Neutrik powerCON TRUE1 - Male to Female - Link cable 0,5m ®... -
Page 8: Fire Safely
FIRE SAFELY! The MAGICFX FX-COMM4NDER has been designed and constructed in such a manner that it can ® be used safely. This applies to the use, the circumstances and the regulations as described in this documentation. Reading this documentation and following the instructions are therefore necessary for everyone who is authorised to work with the MAGICFX FX-COMM4NDER. -
Page 9: Let's Fire
LET’S FIRE! CONNECT THE MAGICFX FX-COMM4NDER ® Do not connect FX-machines to the switchable power output(s) when the output CAUTION cannot deliver sufficient power to the FX-machine. See Chapter 2. Place the FX-COMM4NDER on a stable surface in a suitable area. Make sure the keyswitch is in the ‘OFF’... -
Page 10: Fire
FIRE Place the key in the keyswitch and set the keyswitch in the ‘ON’ position. All buttons light up white. Press the safety button. The FX LED indicator and the safety button light up red. NOTICE You cannot press the safety button when other buttons are pressed. -
Page 11: Clean Up
When you are done with firing, press the safety button to deactivate the fire buttons. The FX LED indicator turns off. CLEAN UP Make sure the FX LED indicator is turned off. Set the keyswitch to the ‘OFF’ position. First disconnect the power cable from the FX-COMM4NDER. Then disconnect the link cables. Remove the machine. -
Page 12: Maintenance
Do not replace parts yourself; always consult MAGIC FX if necessary. DANGER TROUBLESHOOTING Always contact MAGIC FX if any malfunctions or errors occur that cannot be solved with the instructions as described in this manual. CORRECT DISPOSAL This symbol on the product and / or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. -
Page 13: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY According to Annex III A Low Voltage Directive 2014/35/EU MAGIC FX B.V. declares as manufacturer and composer of the technical construction file that the product with the following specifications: Name machine : FX-COMM4NDER Type : MFX3203... - Page 14 WWW.MAGICFX.EU...
