Summary of Contents for MAGIC FX CO2JET II
- Page 1 USER AND INSTALLATION MANUAL ENGLISH CO2JET II. PART01184 CO2 FX rev 01-00...
-
Page 2: Disclaimer
LIABILITY MAGIC FX accepts no liability for claims from third parties arising from unauthorised use, use other than that stated in this manual, and use other than in accordance with the General Conditions registered at the Chamber of Commerce. -
Page 3: Table Of Contents
Indoor use Rigging Noise level Safety symbols 2.7 Precautions for operation Let’s shoot! Mount on a stage Mount on a truss Connect power Connect CO Let’s blast! 3.7 Clean up Maintenance Troubleshooting Correct disposal EC Declaration of Conformity MAGICFX® CO2JET II — User and Installation Manual... -
Page 4: Foreword
FOREWORD Congratulations! You have bought a great new product from MAGIC FX. This manual contains all information required for the intended use of the equipment. Deviation from the described intended use can result in a hazardous situation and/or property damage. -
Page 5: Meet The Magicfx ® Co2Jet Ii
The MAGICFX CO2JET II is equipped with several holes for mounting of the unit to a ® stage or to a truss with a truss clamp and for attaching safety cables. Furthermore the... -
Page 6: Technical Data
20 W Power Connector (Vac) Neutrik® powerCON TRUE1 (in & out) Controlling Control Options Direct output Usage Propellant Liquid CO₂ Propellant Connector CO₂ Quick Connector 3/8” Propellant Consumption 0,5 L/s Technical data MAGICFX® CO2JET II — User and Installation Manual... -
Page 7: Product Identification
CO₂ Bottle to Hose Connector 90 Degrees MFX3103 Twenty Clamp (20kg) M10 SPR00119 Safety Steel SPR00972 Standard Nozzle SPR01236 Low Noise Spray Nozzle CO₂ Accessories Please contact MAGIC FX for additional possibilities. MAGICFX® CO2JET II — User and Installation Manual 7... -
Page 8: Shoot Safely
Always consult your CO supplier for regulations and instructions on safe installation and use. MAGIC FX is not liable for unsafe situations, accidents and damage that are the result of incorrect working with CO and CO cylinders. -
Page 9: Indoor Use
INDOOR USE The MAGICFX CO2JET II is designed for outdoor use and use in well-ventilated indoor ® spaces. When used indoors, make sure you take the necessary preparations. These preparations could include, but are not limited to: •... -
Page 10: Safety Symbols
Missing or obscured safety symbols on the machine can lead to WARNING death or serious injury. Make sure all safety symbols are correctly in place, see section 2.6. MAGICFX® CO2JET II — User and Installation Manual... -
Page 11: Let's Shoot
Pull the angle knob and set the output pipe to the desired shooting angle. Release the angle knob to fasten the output pipe. Check if you hear a clicking sound and whether the output pipe is fastened correctly. MAGICFX® CO2JET II — User and Installation Manual... -
Page 12: Mount On A Truss
CO2JET II within the output ® distance. MOUNT ON A TRUSS Flip the MAGICFX CO2JET II ® upside down. Screw a M10 twenty clamp for truss mounting (product code MFX3103) into both threaded holes. MAGICFX® CO2JET II — User and Installation Manual... - Page 13 Mount the clamp firmly on a truss. Secure the MAGICFX CO2JET II onto the truss. ® MAGICFX® CO2JET II — User and Installation Manual...
-
Page 14: Connect Power
Inspect if the MAGICFX CO2JET II is mounted firmly and secured correctly. ® Pull the angle knob and set the output pipe to the desired shooting angle. Make sure that the direct output will be free from persons and CAUTION animals. - Page 15 POWER OUT Do not connect more units to a single electrical circuit than the CAUTION installed fuse is able to handle. (Calculate the summed load with the electrical data from Chapter 1) MAGICFX® CO2JET II — User and Installation Manual...
-
Page 16: Connect Co
Switch off the power. CONNECT CO Make sure that the power is switched off (LED power indicator is off). Connect the CO hose to the CO quick connector. MAGICFX® CO2JET II — User and Installation Manual... - Page 17 Connect a CO₂ bottle-to- hose connector to a CO cylinder. Connect the CO hose to the CO₂ bottle-to-hose connector on the CO cylinder. Open the CO cylinder. MAGICFX® CO2JET II — User and Installation Manual 17...
-
Page 18: Let's Blast
Make sure that the direct output is free from persons, animals and objects. When it’s time to shoot, switch the power on. Do not use the machine if the CO valve is not opening and CAUTION closing correctly. Enjoy the view! MAGICFX® CO2JET II — User and Installation Manual... -
Page 19: Clean Up
Switch off the power. 3.7 CLEAN UP Close the CO cylinder. Switch the power on to release the remaining pressure. Switch the power off and disconnect the power cable(s). MAGICFX® CO2JET II — User and Installation Manual... - Page 20 Disconnect the CO hose from the CO quick connector. Disconnect the CO hose from the CO₂ bottle-to-hose connector on the CO cylinder. MAGICFX® CO2JET II — User and Installation Manual...
- Page 21 Remove the CO₂ bottle-to- hose connector from the cylinder. Dismount the machine. MAGICFX® CO2JET II — User and Installation Manual...
-
Page 22: Maintenance
Do not replace parts yourself; always consult MAGIC FX if DANGER necessary. TROUBLESHOOTING Always contact MAGIC FX if any malfunctions or errors occur that cannot be solved with the instructions as described in this manual. CORRECT DISPOSAL This symbol on the product and / or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. -
Page 23: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY DECLARATION OF CONFORMITY According to Annex III A Low Voltage Directive 2014/35/EU MAGIC FX B.V. declares as manufacturer and composer of the technical construction file that the product with the following specifications: Name machine : MAGICFX® CO2JET II... - Page 24 MAGICFX® CO2JET II — User and Installation Manual...
- Page 25 WWW.MAGICFX.EU...
