Technical specifications

Measurement technology
Spectral remission measurement and
color density determination to ISO 5-3/4
Measurement geometry
0/45° optics to DIN 5033
Spectral range
400 to 700 nm in 10 nm steps
Measurement aperture
3 mm round standard
optional (easily exchangeable):
1,5 x 1,5 mm,
3 mm round with UV-Cut filter
Light source
Gas-filled lamp, type A illumination
Polarization filter
Twice linear crossed,
Switched on and off per button release
Measurement time
Approximately 1 second per measurement
White reference
Absolute and relative
Absolute white standard integrated and
protected in charging console
Illumination types / Standard Observer
A, C, D50, D65 / 2°, 10°
Density filter
DIN 16536, DIN 16536 NB,
ISO/ANSI T, ISO/ANSI I, ISO E,
D max (Advanced and Premium
models only)
Density measurement range
0,00 D – 2,50 D
Repeatability
0,01 D
0,03 CIE ∆E* a*b*
Inter-instrument agreement
0,01 D
0,3 CIE ∆E* a*b*
Display
High-contrast, backlit LCD-graphic display,
240 x 160 pixels,16 gray levels,
contrast adjustable
Power supply
Rechargeable Ni-MH battery,
regulated recharge via charging console
with A/C adapter,
100 – 240 V, 47– 63 Hz,
Up to 10,000 measurements
per battery charge,
Battery level control
Communication interface
USB
Weight
520 grams
Available Accessories
Small apertures, UV-Cut filter
Print control strip TCS Digital
Software modules "PhotoLab" and Ugra/Fogra
"Media Wedge" evaluation for SpectroDens
Connect:
Delivery contents: see page 8
Configurations: see page 7
Specifications can be subject to change without notice.
Specifications valid for standard device with 3 mm aperture.
