3.3 Overview

The application will be installed in the
Windows program files section in the
folder "TECHKON GmbH / TECHKON
SpectroDens Connect".
After starting the program the main screen will appear. It is divided into four logical
segments: On the left side you see the memory content of the connected device, in
the center the active program module, on the right side the color library which is
stored on the PC and in the section at the bottom a bar which lists all available and
selectable program modules.
1.
5.
2.
3.
4.
1. The menu bar includes functions known
from standard Windows applications. They
comprise: New, Open, Save, Print and Quit.
2. The window "Samples" shows samples
which are stored in the device (see p. 56).
(Only in SpectroDens Advanced and Pre-
mium available.)
3. The window "References" shows stored
references. (Only in SpectroDens Advanced
and Premium available.)
4. The window "Color books" displays the
color books which are stored in the color
library of the device. Per Drag-and-Drop
Manual TECHKON SpectroDens Chapter 3 – Windows software
6.
Software symbol
SpectroDens Connect
7.
you can copy references and complete color
books from here.
5. The USB symbol indicates, that the device
is connected properly.
6. Window of the active program module
7. This bar shows the list of available pro-
gram modules. They can be selected from this
bar directly via mouse click and the applica-
tion will appear in the middle of the display.
After launching SpectroDens Connect it is
pre-set to display the module "Compare
colors".
Page 65
