Page 1 User Manual ASR-5300I Series Hardware...
Page 2 The documentation and the software included with this product are copyrighted 2016 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
Page 3: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information.
Page 4: Document Feedback
Technical Support and Assistance Visit the Advantech website at http://support.advantech.com to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support should you require additional assistance. Please have the following information ready before calling: –...
Page 5: Safety Precautions
The power cord or plug is damaged. – The enclosure has been exposed to moisture. – The system has been malfunctioning. – The enclosure was dropped against a hard surface. – The enclosure shows obvious signs of breakage. ASR-5300I Series Hardware User Manual...
Page 6: About This Manual
The use of Advantech-certified components is strongly recommended to ensure com- patibility, quality, and normal operation with your Advantech products. Please contact your distributor for a list of Advantech-certified components (e.g., SFP, SFP+, HBA cards, iSCSI cables, FC cables, memory modules, etc.).
Page 7: Table Of Contents
Flash Backup Module Installation ..........23 2.6.4 Battery Backup Unit Installation ..........24 2.6.5 Super Capacitor Battery and Flash Backup Module Installation. 26 2.6.6 Flash Backup Module Installation ..........27 2.6.7 Installing the Super Capacitor Battery ........29 ASR-5300I Series Hardware User Manual...
Page 8 Controller LED for RAID Models..........68 4.3.2 Controller LED for JBOD Models..........70 4.3.3 iSCSI/Ethernet Management Port LEDs........71 4.3.4 10Gb iSCSI Host Port LEDs (Fibre) ........... 72 4.3.5 10Gb iSCSI Host Port LEDs (RJ45) ........... 72 ASR-5300I Series Hardware User Manual viii...
Page 9 C.1.3 Unpacking the System .............. 104 C.1.4 Component Installation Procedure..........104 C.1.5 Tools Required................104 Rackmount Slide Rail Kits..............105 C.2.1 Rack Ear Mount Kit ..............105 C.2.2 Slide Rail Kit................108 After Mounting..................111 C.3.1 Safety Reminders ..............111 ASR-5300I Series Hardware User Manual...
Page 10 ASR-5300I Series Hardware User Manual...
Page 11: Chapter 1 Introduction
Chapter Introduction...
Page 12: Product Overview
RAID system and support storage expansion with the addition of extra hard drives. All systems are compatible with SAS-3 and SAS-6, or SATA-II and SATA-III hard drives. However, hard drive limitations may vary between models. ASR-5300I Series Hardware User Manual...
Page 13: Component Check
Regarding the 2U and 3U series, two cooling modules built into the power supply unit (PSU) protect the system from overheating, while two hot swappable PSUs provide constant power to the system. The system’s modular design and accessibility of all major components ensure easy maintenance. ASR-5300I Series Hardware User Manual...
Page 14: Rear Panel
When the RAID system is rebooted, all system configurations will revert back to the default state, and Controller B will return the primary role to Controller A. ASR-5300I Series Hardware User Manual...
Page 15: Single-Controller Systems
In single-controller system, the second controller slot is filled with a dummy cage (D). 1.4.3 Connection Between RAID and JBOD The following rules apply when connecting RAID and JBOD(s):  Dual-controller RAID connects to dual-controller JBOD.  Single-controller RAID connects to single-controller JBOD. ASR-5300I Series Hardware User Manual...
Page 16: Chassis
Power Supply Unit and Cooling Module (3): 2U and 3U: The hot swappable PSUs provide power to the system. Each PSU contains a cooling module. Refer to the information for your specific system in subsequent sections of this chapter. ASR-5300I Series Hardware User Manual...
Page 17: Internal Backplane
4.2.1, LED Panel LEDs. Warning! If critical faults are indicated on the LED panel, verify the cause of the problem as soon as possible and contact your system vendor to arrange for a replacement module. ASR-5300I Series Hardware User Manual...
Page 18: Chassis Ear
Warning! Be careful not to warp, twist, or contort the drive tray in any way (e.g., by dropping or resting heavy objects on it). If the drive bay superstructure is deformed or altered, drive trays may not fit into the drive bay. ASR-5300I Series Hardware User Manual...
Page 19: Rear Panel Components
The BBU is an optional accessory for single-controller systems. Warning! The controller should only be removed to install/replace memory mod- ules, CBM, or a failed controller. The RAID controller features sensitive components; unnecessary tampering can damage the controller. ASR-5300I Series Hardware User Manual...
Page 20: Controller Module Of Jbod Models
The use of a CBM is highly recom- mended to safeguard data integrity. If you are using a single-controller model and would like to install a CBM, refer to CBM Installation. ASR-5300I Series Hardware User Manual...
Page 21: Super Capacity Battery And Flash Backup Module
In such cases, contact your system ven- dor immediately. Users can also check the status of the battery module via SANWatch or the firmware (please refer to respective manuals). ASR-5300I Series Hardware User Manual...
Page 22: Psu And Cooling Module
The preset-value for an event notification can be changed using the firmware-embedded configuration utility. However, the fan speed trigger threshold cannot be changed. Refer to the Firmware Operation Manual for further details. ASR-5300I Series Hardware User Manual...
Page 23: System Monitoring Features
JBOD Enclosure Status Monitoring A RAID system, when connected with expansion JBODs, acquires the component status within other enclosures via a proprietary enclosure monitoring service using the in-band connectivity. No additional management connection is required. ASR-5300I Series Hardware User Manual...
Page 24: I2C Bus
Therefore, a failed component should only be removed when a replacement is available. For instructions on how to replace the hot swappable components, please refer to System Maintenance. ASR-5300I Series Hardware User Manual...
Page 25: Chapter 2 Hardware Installation
Chapter Hardware Installation...
Page 26: Introduction
Users should familiarize themselves with the related positions of each plug-in module and interface connector. Cables must be handled with care and not bent. To prevent emission interference within a rack system and accidental cable disconnection, the routing paths should be carefully planned. ASR-5300I Series Hardware User Manual...
Page 27: Installation Procedures Overview
The components pre-installed in the system are as follows:  Controllers  LED front panels  Chassis ears with plastic caps  DIMM module for RAID models  CBM (dual-controller systems)  PSUs including cooling modules  Host board ASR-5300I Series Hardware User Manual...
Page 28: Components Requiring Installation
Please ensure that the correct hard drives are purchased. Note! If you use a dual-controller RAID system and prefer using SATA hard drives in the enclosure or in the attached JBODs, ensure you also pur- chase MUX kits. ASR-5300I Series Hardware User Manual...
Page 29: Sas Interface
SAS secondary links (3). The SATA drives have only one port that includes the SATA physical links (4) and the power link (5). In a redundant-controller system, the MUX-enabled drive trays must be separately purchased and applied. Single-controller JBODs do not require a MUX kit. ASR-5300I Series Hardware User Manual...
Page 30: Installing A Hard Drive In The Drive Tray
Place the hard drive into the drive tray, ensuring that the interface connector is facing the open side of the drive tray, with the label side facing upwards. If you have a MUX board and want to install a SAS drive, the MUX board should be removed. ASR-5300I Series Hardware User Manual...
Page 31: Installing The Hard Drive Tray Into The Enclosure
With the hard drive tray bezel opened, align and insert the tray into the enclosure. Once fully inserted, close the tray and use a small-size flat blade screwdriver to turn the bezel lock from unlock to the lock position. ASR-5300I Series Hardware User Manual...
Page 32: Installing Cbm For Raid Models
Please read the following sections on how to install the battery backup module and FBM into the controller module. Always place the controller on a clean, static-free surface and hold the controller only by its metal canister. Never touch the circuit board or connector pins. ASR-5300I Series Hardware User Manual...
Page 33: Flash Backup Module Installation
(shown in blue). Lower the PCB board onto the controller while matching the holes to the copper stands and secure the board in place using the supplied truss head screws. ASR-5300I Series Hardware User Manual...
Page 34: Battery Backup Unit Installation
SSD gold fingers into the slot, and lower the other end of the SSD until the edges are clipped-on. 2.6.4 Battery Backup Unit Installation With the controller removed, remove the cover by removing the two screws highlighted in the illustration below. ASR-5300I Series Hardware User Manual...
Page 35 Hold the battery cage at a 45-degree angle, and ensure the cage meets the screw holes. Secure the cage in place using the supplied flathead screws. Secure the other end of the cage with flathead screws from underneath the controller. Using one screw on each side. ASR-5300I Series Hardware User Manual...
Page 36: Super Capacitor Battery And Flash Backup Module Installation
Please read the following sections on how to install the super capacitor battery and FBM in the controller. Always place the controller on a clean, static-free surface and hold the controller only by its metal canister. Never touch the circuit board or connec- tor pins. ASR-5300I Series Hardware User Manual...
Page 37: Flash Backup Module Installation
2.6.6 Flash Backup Module Installation With the controller removed, remove the screw highlighted in the illustration below. Install copper stands at the three designated locations highlighted below. ASR-5300I Series Hardware User Manual...
Page 38 Secure the PCB in place with the screws provided. Insert the SSD at a 45-degree angle, and ensure the notch meets (indicated by the blue circle). Gently lower the other end of the SSD and secure it in place with a screw. ASR-5300I Series Hardware User Manual...
Page 39: Installing The Super Capacitor Battery
With the controller removed, insert the super capacitor battery at a 45-degree angle. Ensure the protrusion is inserted into the slot (indicated by the blue circle/ arrow). Secure the super capacitor battery using one of the supplied screws (location indicated by the blue circle). ASR-5300I Series Hardware User Manual...
Page 40 Connect the four-pin molex connector to the SSD PCB board. Reinstall the controller. ASR-5300I Series Hardware User Manual...
Page 41: Installing The Raid Controller
(as indicated with the blue arrows below) to secure the controller in the chassis. Secure the controller by fastening the two retention screws (1) under the ejection levers (2). Note! A new or replaced BBU requires at least 12 hours to charge to full capacity. ASR-5300I Series Hardware User Manual...
Page 42 ASR-5300I Series Hardware User Manual...
Page 43: Chapter 3 System Connection
Chapter System Connection...
Page 44: Introduction
76 mm (3 inches).  Route the cables away from areas with a high likelihood for damage (e.g., from foot traffic or fan exhaust).  Do not over-tighten or bend the cables. ASR-5300I Series Hardware User Manual...
Page 45: Host-Side Topologies
(for example, Host A accesses ID 3), the controller will return a busy message. This occurs with all concurrent active nexus. If the cache is cleared, four nexus can be accepted again. Many I/O operations can be accessed via the same nexus. ASR-5300I Series Hardware User Manual...
Page 46: Maximum Queued I/O Count
64-bit/133MHz PCI-X or PCI-E interface. Please contact your vendor for the latest certified items. Warning! All Fibre cables are sensitive and must be handled with care. To avoid interference, the cable routing path must be carefully planned and the cables not bent. ASR-5300I Series Hardware User Manual...
Page 47: Fibre-Host Components (Including 10 Gb Iscsi)
However, a Fibre switch is required to implement this topology. Note! If a logical drive can be accessed via different servers, file locking, FC switch zoning, port binding, and multipath access control will be necessary. ASR-5300I Series Hardware User Manual...
Page 48: Fibre Cabling
Remove the protective caps on the other end of the cable, and connect this end to an SFP transceiver module on a Fibre Channel switch port or a Fibre Chan- nel host bus adapter (HBA) port. ASR-5300I Series Hardware User Manual...
Page 49: Simple End-To-End Connection
Note! If a logical drive can be accessed by different servers, file locking, FC switch zoning, port binding, and multipath access control will be necessary in order to avoid access contention. ASR-5300I Series Hardware User Manual...
Page 50: Das (Direct-Attached) Connection
If a server has multiple data paths to a RAID system, multi-path software, such as the EonPath driver, is necessary. The two logical drives in the above drawing cannot leverage the full computing power of the system. Users may attach 1 or 2 more JBODs to acquire more end-to-end performance. ASR-5300I Series Hardware User Manual...
Page 51: Switched Fabric Connection (Dual-Controller)
A channel link bypass is provided on external FC switches. Every application server shown in the diagram is equipped with two HBAs with FC links via two FC switches connected to the SFP ports on individual RAID controllers. ASR-5300I Series Hardware User Manual...
Page 52: Switched Fabric Connection (Single-Controller)
I/Os across preferred paths (active IDs on data paths). TPGS (Target Port Group Service) is supported to ensure that I/Os are routed to the preferred paths. 3.3.7 Switched Fabric Connection (Single-Controller) ASR-5300I Series Hardware User Manual...
Page 53: Sas-Host Raid Connections
Warning! All SAS cables are sensitive and must be handled with care. To prevent interference within a rack system, the cable routing path must be care- fully planned and the cables not bent. ASR-5300I Series Hardware User Manual...
Page 54: Das (Direct-Attached Storage) Connection With Redundant Host Path
3.4.1 DAS (Direct-Attached Storage) Connection with Redundant Host Path ASR-5300I Series Hardware User Manual...
Page 55 LUN numbers. Note! EonPath multipath software or Linux Device Mapper is necessary for controlling and optimizing access to logical drives via multiple data paths. ASR-5300I Series Hardware User Manual...
Page 56: Das (Direct-Attached Storage) Connection To Two Servers
3.4.2 DAS (Direct-Attached Storage) Connection to Two Servers Note! To access a LUN (a logical partition) by multiple hosts, file locking or multipath access control is necessary. ASR-5300I Series Hardware User Manual...
Page 57: Iscsi-Host Raid Connections
Multiple arrays or logical partitions can be created and made available  separately through different IDs or LUN numbers on the host ports. A RAID5 logical drive of eight members typically offers optimal array performance. ASR-5300I Series Hardware User Manual...
Page 58 Note! If using Microsoft’s software initiator, de-select the embedded MPIO function when installing the software because MPIO selection creates conflicts with the EonPath driver. ASR-5300I Series Hardware User Manual...
Page 59: High Availability Ip San With Redundant Raid Controller
LD1 mapped to CH1 AID and CH1 BID; LD assigned to controller A LD2 mapped to CH2 AID and CH2 BID; LD assigned to controller B LD3 mapped to CH3 AID and CH3 BID; LD assigned to controller B LD assignment ASR-5300I Series Hardware User Manual...
Page 60: Single-Controller With Fault-Tolerant Path
2 logical drives RAID configuration * Each logical partition appears on two different host links for fault tolerance. Use EonPath multipath software to ensure the operating system can identify alternate paths to the same logical drive. ASR-5300I Series Hardware User Manual...
Page 61: High-Availability Ip San (Recommended Cabling Method For Remote Replication)
A and B to enable remote RAID configuration replication. LD1 mapped to CH1 BID, CH0 AID CH3 BID and CH2 AID; LD has to be assigned to both controllers A and B to enable remote replication. ASR-5300I Series Hardware User Manual...
Page 62: High-Availability Ip San With Port Trunk (Remote Replication Enabled)
IDs managed by the alternate RAID controller. Host IDs and port IPs do not failover to the surviving controller. Therefore, the EonPath multipath driver is necessary for path redundancy and controller failover. 3.5.5 High-Availability IP SAN with Port Trunk (Remote Replication Enabled) ASR-5300I Series Hardware User Manual...
Page 63: Hybrid Host Connections
A and B to enable remote replication Hybrid Host Connections For hybrid systems that feature two additional iSCSI ports, these ports can be used for remote replication or host LUN mapping. 3.6.1 Single Hybrid Unit Connected to FC/iSCSI Hosts ASR-5300I Series Hardware User Manual...
Page 64: Utilizing Hybrid Iscsi Ports For Data Replication
LAN connection, as well as a robust link for data protection (volume copy/mirror). The SANWatch software suite, on which the volume copy/mirror settings are config- ured, automatically detects the iSCSI data connection and uses it for data replication. ASR-5300I Series Hardware User Manual...
Page 65: Jbod Connections
Routing through two different connections can avoid loss of data links if one in-between enclosure fails. The rotary ID switch on every expansion enclosure can be manually configured using a flat blade screwdriver. ASR-5300I Series Hardware User Manual...
Page 66: Configuration Rules
SAS JBOD controller failure. Designation Description Designation Description RAID controller A Dual-ported SAS drives RAID controller B Expander JBOD controller A To another JBOD JBOD controller B ASR-5300I Series Hardware User Manual...
Page 67: Dual-Controller Expansion Connection
RAID system top SAS exp. -> 1st JBOD top SAS-IN  1st JBOD top SAS-OUT -> 2nd JBOD top SAS-IN  1st JBOD bottom SAS-IN port –> 2nd JBOD bottom SAS-OUT  RAID system bottom SAS exp. –> last JBOD bottom SAS-IN ASR-5300I Series Hardware User Manual...
Page 68: Single-Controller Expansion Connections
JBODs (e.g., the first and last JBODs). 3.7.5 Single-Controller Expansion Connections  RAID system SAS exp. –> 1st JBOD SAS-IN  1st JBOD SAS-OUT –> 2nd JBOD SAS-IN ASR-5300I Series Hardware User Manual...
Page 69: Management Console Connections
Management Console Connections Designation Description Designation Description Serial port (for Telnet access) Local area network Single controller: DB9 male to female serial dual controller: SANWatch/ telnet console Y-cable CAT5e LAN cable ASR-5300I Series Hardware User Manual...
Page 70: Power Connections
Ensure that the power cables used are at least 1.2 meters in length. Do not use extension cables because the power cables are designed to connect ONLY and DIRECTLY to relocatable power taps (RPTs) on server cabinets. ASR-5300I Series Hardware User Manual...
Page 71: Connecting Power Cords
Power on the networking devices (e.g., switches). Power on the host computers. The host computers should be the last devices turned on. Please refer to the documentation provided with the host computers to understand the power on procedures. ASR-5300I Series Hardware User Manual...
Page 72: Power On Status Check
Ctrl Status LED: On (green) or Off (if not installed) C_Dirty LED: Off Hst Bsy LED: On (green) Temp LED: Off Drv Bsy LED: On (green) PSU and Cooling Module LEDs PSU LED: On (green) ASR-5300I Series Hardware User Manual...
Page 73: Power Off Procedure
SANWatch manual). Once the cache is flushed, the system can be powered down. Note! Before powering off the system, ensure that no time-consuming processes, such as “Regenerate Logical Drive Parity” or “Media Scan,” are occurring. ASR-5300I Series Hardware User Manual...
Page 74 ASR-5300I Series Hardware User Manual...
Page 75: Chapter 4 System Monitoring
Chapter System Monitoring...
Page 76: Introduction
Introduction The ASR-5300I series is equipped with various self-monitoring features that enable system managers to maintain awareness of the system operation status. Monitoring Features Users can monitor the system using the following features:  Firmware: The RAID controller in the system is managed by pre-installed firmware, which is accessible from a terminal program via the serial port.
Page 77: Led Panel Leds
6. Rotary ID Switch N/A the JBOD expansion enclosure(s). Pressing for less than one second mutes the audible 7. Mute/Service alarm. Button Pressing for more than two seconds sends a service notification to the host computer. ASR-5300I Series Hardware User Manual...
Page 78: Drive Tray Led
Green indicates that the drive bay is populated and working normally. 2. Power Status Green Off indicates that the drive bay is not populated or that the drive cannot be detected. Controller LED 4.3.1 Controller LED for RAID Models ASR-5300I Series Hardware User Manual...
Page 79 6. Drv Bsy Green Blinking green indicates traffic on the drive channels. Green indicates the RAID configuration default has 7. Restore Default Green been successfully restored. The LED state will be invalidated after a few seconds. ASR-5300I Series Hardware User Manual...
Page 80: Controller Led For Jbod Models
Amber indicates 3Gbps link speed. Off indicates no connection. Green indicates the controller is operating normally. 3. Ctrl Status Green/Amber Amber indicates a component failure has occurred. This LED is also lit during the initialization process. ASR-5300I Series Hardware User Manual...
Page 81: Iscsi/Ethernet Management Port Leds
Steady amber indicates a connection has been established. 2. Link/Activity Amber Flashing amber indicates data I/O. Off indicates connection not established. Note! The Ethernet management port supports only 100Mbs and 1000Mbs (1Gbs) speeds. ASR-5300I Series Hardware User Manual...
Page 82: 10Gb Iscsi Host Port Leds (Fibre)
Status Green indicates 10Gb connection established Speed LED Amber indicates 1Gb connection established Off indicates 10/100 connection established Green indicates connection established Link Status LED Flashing green indicates data activity Off indicates connection not established ASR-5300I Series Hardware User Manual...
Page 83: 8Gb Fibre-Host Port Leds
Green indicates connection established Link Status LED Flashing green indicates data activity Off indicates connection not established Green indicates 16Gb connection established Speed LED Yellow indicates 8Gb connection established Off indicates 4Gb or slower connection established ASR-5300I Series Hardware User Manual...
Page 84: Sas-Host Port Leds
Off indicates all 4 PHYs links are offline. Green indicates a 12Gbps link connection. 2. SAS Speed Amber indicates a 6Gbps link connection. Green/Amber Status Off indicates a 3Gbps link connection or that no connec- tion exists. ASR-5300I Series Hardware User Manual...
Page 85: Psu/Cooling Module Leds
If the temperature exceeds a preset threshold, the controller’s charger circuits will stop charging. Users will then receive a message saying “Thermal Shutdown/Enter Sleep Mode.” When the temperature falls back within normal range, the battery will resume charging. ASR-5300I Series Hardware User Manual...
Page 86: I2C
Controller A). Leaving the Controller B slot empty and with Controller B in slot A, perform Steps 1 to 8 again to restore the default settings for Controller B. Put both Controller A and Controller B into their original positions and power on the system. ASR-5300I Series Hardware User Manual...
Page 87: Chapter 5 System Maintenance
Chapter System Maintenance...
Page 88: Introduction
Storage Manager > Information > Enclosure View in SANWatch (please refer to the SANWatch Manual for details). To update the firmware, please refer to the following: a. Advantech SANWatch User Manual on Upgrading the Firmware b. Firmware Manual on System Functions: Upgrading Firmware ASR-5300I Series Hardware User Manual...
Page 89 Disconnect all cables connected to the controller module. Loosen the screw securing the control module ejection levers. Push the ejection levers downwards (indicated by the blue arrows). The controller module will automatically ease out of the controller module bay. ASR-5300I Series Hardware User Manual...
Page 90 For single-controller models or when replacing both controllers simultaneously, restor NVRAM data. To restore previous ID/LUN mapping settings, users may use the “Restore NVRAM from Disks” or “Restore NVRAM from Files” functions in the firmware. ID/LUN mapping will be restored. ASR-5300I Series Hardware User Manual...
Page 91: Replacing The Controller Host Board
Holding onto the edges of the PCB, carefully remove the host board from its antistatic package. Install the new host board in the same position as the previous host board and secure it in place using the three screws. ASR-5300I Series Hardware User Manual...
Page 92: Replacing The Memory Module On Raid Systems
Wait one minute for the remaining electricity on the main board to disperse. Push down the clips on the sides of the DIMM socket (indicated by the blue circle). The DIMM will automatically eject from the socket. DRAM location Removing the module ASR-5300I Series Hardware User Manual...
Page 93: Replacing The Cbm For Raid Models
The CBM consists of a BBU and FBM. The CBM can sustain and transfer cached data to a FBM in the event of a power outage, or in the unlikely event of both PSUs failing. The CBM (BBU and FBM) is an optional item for single-controller systems by default. ASR-5300I Series Hardware User Manual...
Page 94: Bbu Fault Conditions And Precautions
A replacement BBU requires approximately 12 hours to charge to full capacity. The life expectancy of a BBU is three years. If the cause of a failure cannot be determined even after a BBU module is replaced, contact your system vendor. ASR-5300I Series Hardware User Manual...
Page 95: Replacing The Flash Backup Module
Flick the clips securing the FBM in the direction of the arrow to release the FBM. While holding it at a 45-degree angle, remove the FBM. Insert the new FBM on a 45-degree angle. Ensure the notches match and gently push the end downwards until the clips clamp on. ASR-5300I Series Hardware User Manual...
Page 96: Replacing The Super Capacitor Battery And Flash Backup Module
Do not immerse the supercapacitor battery in water or expose it to liquids.  Do not disassemble or modify the supercapacitor battery.  Do not pierce with a sharp object, strike with a hammer, exert pressure on, or throw the supercapacitor battery. ASR-5300I Series Hardware User Manual...
Page 97: Replacing The Supercapacitor Battery
Lift the supercapacitor battery from the screw end at a 45-degree angle. Insert the replacement supercapacitor battery at a 45-degree angle. Ensure the protrusion meets at the front and secure the supercapacitor battery with the screw supplied. ASR-5300I Series Hardware User Manual...
Page 98: Replacing The Flash Backup Module (Coupled With Supercap)
Loosen the screw at the end of FBM and remove the FBM. Insert the replacement FBM at a 45-degree angle, gently lower the other end of the SSD and secure it in place using the original screw. ASR-5300I Series Hardware User Manual...
Page 99: Replacing The Power Supply/Cooling Module
PSU for an extended period of time is not recommended. The failed spare redundant PSU should be replaced as soon as possible! To replace a PSU, follow the steps outlined below. Power off the system, turn off the PSU, and unplug the power cord. ASR-5300I Series Hardware User Manual...
Page 100 Push the replacement PSU into the chassis. When contact resistance is felt, push the extraction handle towards the PSU module, where it should engage the back-end connectors. Fasten the thumb screw. Reconnect the power cord. Power on the PSU module. ASR-5300I Series Hardware User Manual...
Page 101: Replacing A Hard Drive
Unlock the drive tray bezel (indicated by the blue arrow) by using a small flat blade screwdriver to change the bezel lock position from locked to unlocked. Open the drive tray. Press the button. The spring handle will pop out. ASR-5300I Series Hardware User Manual...
Page 102 Remove the four retention screws (two on each side). The screws secure the hard drive to the drive tray. 3.5-inch tray 2.5-inch tray 2.5” SAS HDD (without MUX) 2.5-inch SAS hard drive 2.5” SATA HDD (with MUX) 2.5-inch SATA hard drive MUX board screw locations ASR-5300I Series Hardware User Manual...
Page 103 Do not push the bezel lock while turning it, otherwise the spring handle will pop out again. Note! Never leave the bezel lock unlocked – the RAID controller may consider it a faulty drive. Check for drive errors. Ensure that no further errors are reported. ASR-5300I Series Hardware User Manual...
Page 104 ASR-5300I Series Hardware User Manual...
Page 105: Appendix A Technical Specifications
Appendix Technical Specifications...
Page 106: Host/Drive Interface
Supports 12/16 channels of 3/6 Gbps SAS, SATA-II/ Drive Interface/Channel SATA-III, Nearline series JBOD Models Eight SMP PHYs interfaced through two SAS 4x wide SAS Interface ports Supports up to 12/16 channels of 3/6 Gbps SAS, Drive Interface/Channel SATA-II/SATA-III, Nearline series ASR-5300I Series Hardware User Manual...
Page 107: Raid Configurations For Raid Models
Ethernet or RS-232C Configuration data stored on disks so that logical drive Configuration on Disk assemblies exist after controller replacement. Faults are indicated via alarm, module LED indicators, Failure Indicator LCD panel, SANWatch Manager, or terminal emulation. ASR-5300I Series Hardware User Manual...
Page 108: Fault Tolerance For Raid Models
Auto shutdown when lost cooling or exceeded ambient Over-Temperature Protection temperature; over-voltage protection is also available. *The PSU specifications described above are general measurements and may not represent all models. For details, please refer to specific model specifications. ASR-5300I Series Hardware User Manual...
Page 109: Dimensions
Operating: 5 to 500Hz, 0.25Grms, X/Y/Z, 30 min Non-operating: 5 to 500Hz, 1.0Grms, X/Y/Z, 30 min Vibration (Sine) Operating: 5 to 500Hz, 0.2Grms, X/Y/Z Sine, 1hr/sweep Non-operating: 5 to 500Hz, 1.0Grms, X/Y/Z Sine, 1hr/sweep Acoustic Noise 65dBA boundary, 60dBA normal ASR-5300I Series Hardware User Manual...
Page 110 ASR-5300I Series Hardware User Manual...
Page 111: Appendix B Certifications
Appendix Certifications...
Page 112: Summary
IEC 61000-4-5:2005 IEC 61000-4-6:2003/A1:2004/A2:2006 IEC 61000-4-8:1993/A1:2000, IEC 61000-4-11: 2004 IEC 61000-3-2, IEC61000-3-3 BSMI (CNS 13438) FCC (FCC Part 15, Subpart B) IEC 60068-2 MIL-STD-810E/883E Environment ISTA ASTM-D3332 IPC-TM-650 ISO7779/3744 Others RoHS Microsoft WHQL-Windows Server 2003 ASR-5300I Series Hardware User Manual...
Page 113: Appendix C Slide Rail Kit Installation Guide
Appendix Slide Rail Kit Installation Guide...
Page 114: Slide Rail Kit
C.1.5 Tools Required For all slide rail installation procedures, the following tools will be required:  One medium-size Phillips screwdriver  One small-size Phillips screwdriver  One medium-size flat-blade screwdriver ASR-5300I Series Hardware User Manual...
Page 115: Rackmount Slide Rail Kits
Mounting bracket assembly, left side Mounting bracket assembly, right side Hexagon washer screws #6-32 mm Truss head screws M5 x 9.0 mm M5 cage nuts M5 x 25 mm M6 x 25 mm #10-32 x 25.4 mm ASR-5300I Series Hardware User Manual...
Page 116 Installation Procedure Begin by determining the installation position and M5 cage nut (5) insertion loca- tion. Install the fixed rack ear mount on the rear posts and secure them in place using truss head screws (4). ASR-5300I Series Hardware User Manual...
Page 117 With another person holding the enclosure at the installation height, use four M5 x 25 mm screws (6) at the front of the enclosure and eight #6-32 screws (3) on both sides (four per side) to secure the enclosure in the rack. ASR-5300I Series Hardware User Manual...
Page 118: Slide Rail Kit
Mounting bracket assembly, left side Mounting bracket assembly, right side Inner glides Flat-head screws #6-32 L4 Truss head screws M5 x9.0 mm M5 cage nuts M5 x 25 mm M6 x 25 mm #10-32 x 25.4 mm ASR-5300I Series Hardware User Manual...
Page 119 Adjust the length by loosening the four screws on the slide rail. Secure the slide rails to front and rear posts using truss head screws. Tighten the four screws on the slide to fix the length. ASR-5300I Series Hardware User Manual...
Page 120 With the assistance of another person, lift and affix the enclosure onto the slide rail. Ensure the inner glides on both sides of the enclosure meet the inner glide rail. Secure the enclosure with M5 or M6 screws from the front. ASR-5300I Series Hardware User Manual...
Page 121: After Mounting
 Reserve at least 18 ~ 20 cm of free space at the rear of the enclosure to ensure adequate ventilation.  Avoid touching the PCB and gold-finger connections. ASR-5300I Series Hardware User Manual...
Page 122 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without the prior written permission of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2016...
