DODGER-EP
Requires: 3-channel radio w/ 2 mini servos, Outrunner
Motor KM0283010 w/ Propeller Adaptor
HW2340100 20A brushless ESC, 3 cells
11.1V 2100mAh Li-Po battery & charger.
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries.Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
Specifications
*Specifications are subject to change without notice.*
INSTRUCTION MANUAL
78 in /
1980
mm
665 sq in / 42.9sq dm
32 oz / 900 g
40 in / 1020mm
Advertisement
Related Manuals for HobbyKing DODGER-EP
Summary of Contents for HobbyKing DODGER-EP
- Page 1 INSTRUCTION MANUAL DODGER-EP Requires: 3-channel radio w/ 2 mini servos, Outrunner Motor KM0283010 w/ Propeller Adaptor HW2340100 20A brushless ESC, 3 cells 11.1V 2100mAh Li-Po battery & charger. Specifications 78 in / 1980 Wing Span 665 sq in / 42.9sq dm...
- Page 2 BEFORE YOU BEGIN ASSEMBLY P.2-8 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly.
- Page 3 Main Wing Completed Stabilizer & Elevator Apply instant type CA glue to both sides of each hinge. Bottom View Temporary install the main wing, adjust (Stabilizer) leveling of the stabilizer to make it as parallel to the main wing as possible. (Main Wing) A A' *Also refer to step 10 Wing Setting...
- Page 4 Vertical Fin & Rudder Apply instant type CA glue to both sides of each hinge. Peel off shaded Portion covering film. Completed...
-
Page 5: Elevator Pushrod
Elevator Pushrod O1mm pllot holes for tri-horn are pre-drilled. please look for lin-hole marks at under side Screw PB2x10mm of control surfaces PB2x10mm Clevis Fuel Tube d2xD4x4mm Pushrod Horn 1.4x618mm TWM PL8210010 CLEVIS WRENCH Rudder Pushrod Screw PB2x10mm TWM PL8210010 CLEVIS WRENCH Pushrod Ø1.4 x 563mm... - Page 6 Motor / Cowling Setting KP0011310 Solder Solder Optional Parts PM3x6mm Screw PM3x6mm PM2x12mm Screw PWA2x8mm Screw Outrunner Motor 28/ 30 d3xD7mm Washer KM0283010 d3xD7mm Washer Don't over-tighten the PM3 screws, too much Propeller Adaptor stress on the screws (d3xD5) HW2340100 could split the firewall.
-
Page 7: Radio Equipment
Radio Equipment Install and arrange the servo as shown in the diagram. Battery Elevator Servo Straper Battery Tie Elevator Pushrod Double-Side Tape Front Fuel Tube Ø4 x 4mm Speed 400 Motor Receiver Sponge Rudder Servo Rudder Pushrod Brushless ESC Main Wing Screw PM2.5 x 16mm Washer... - Page 8 Wing Setting A=A' B=B' C=C' Control Throws Rudder 30mm 30mm Elevator 15mm 15mm...
- Page 9 The ideal C.G. position is 75mm (2 95 in.) Behind the leading edge C.G. measured at where the wing meets the fuselage. In order to obtain the C.G.specified, add weight to the fuselage or move the battery position. Check the C.G. Before flying.
