GALLIUM PRO 210A: ASSEMBLY GUIDE
Revision 5.0 - 05-23-2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GALLIUM PRO 210A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argon 18 GALLIUM PRO 210A

Summary of Contents for Argon 18 GALLIUM PRO 210A

  • Page 1 GALLIUM PRO 210A: ASSEMBLY GUIDE Revision 5.0 - 05-23-2017...
  • Page 2 7. Parts’ SKUs and Descriptions ......17-18 For the warranty to be valid, the bicycle must be fully assembled by an authorized Argon 18 dealer. High-end components, particularly carbon parts, need extra care when assembled.

  • Page 3: Assembly Overview

    GALLIUM PRO 210A: Assembly overview 1. Frame inspection 2. Headset installation 3. Cable housing installation IMPORTANT NOTICE: It is easier to install the cable housings before the bottom bracket, crank & fork. 4. Electronic drive-train cable 5. Seatpost installation 6. Derailleur hanger adjustment...

  • Page 4: Assembly Overview

    GALLIUM PRO 210A: Assembly overview Images are for reference only. Proportions are not accurate. 7. Parts Listing...

  • Page 5: Frame Inspection

    GALLIUM PRO 210A: 1. Frame inspection When assembling a new frame, be sure to check if the following parts are assembled correctly. Parts installed on the frame Description Screw Torque Detail type Seatpost, Ø 27.2mm Seatpost Carbon paste Front derailleur hanger...

  • Page 6: Headset Installation

    GALLIUM PRO 210A: 2. Headset installation Install the 3D headset (9) according to the pressfit assembly guide. You can choose from 3 different heights: 25mm, 15mm or 0mm.

  • Page 7: Cables & Housing Installation

    GALLIUM PRO 210A: 3. Cables & housing installation 1. Install the front and rear derailleur cable starting at the head tube. 2. Install the rear brake cable starting the head tube. For the derailleur and brake housing, measure a sufficient length of housing to be able to turn the handlebar both ways correctly.

  • Page 8: Cables & Housing Installation

    GALLIUM PRO 210A: 3. Cables & housing installation Rear brake cable housing Remove the cable stopper (4) near the seat collar. Font section: Mesure the necessary cable housing to ensure a proper rotation of the handlebar. Insert the cable trough the shifter, then insert the cable and the housing with a ferrule in the head tube.
  • Page 9 GALLIUM PRO 210A: 3. Cable & housing installation Front and rear derailleur: Pass the two cables inside the frame starting from the top tube until they come out under the bottom bracket. Pass both cables into the cable guide (19). Make sure the 5mm screw is set to 1.5 Nm.
  • Page 10 GALLIUM PRO 210A: 4. Electronic drive-train specification The Di2 cable routing can be achieved easily using this simple trick: use a brake cable and a metal cable end to fix the Di2 cable. For more information on Shimano Di2 electronic system installation, go to: http://si.shimano.com.

  • Page 11: Electronic Drive-Train Specification

    GALLIUM PRO 210A: 4. Electronic drive-train specification Use the proper grommet on the headtube to fix the cable correctly (depending if you use a mechanical or electronic drive-train).
  • Page 12 GALLIUM PRO 210A: 4. Electronic drive-train specification Use the proper grommet / cable stopper for the rear derailleur (depending if you use mechanical or electronic drive-train). In a Di2 configuration, remove the cable stopper (3) and use the Di2 grommet (6) instead, but leave the 2 scews to avoid...
  • Page 13 GALLIUM PRO 210A: 4. Electronic drive-train specification In a mechanical configuration, use the provided cable guide pipe (12) for the front derailleur. For an electronic drive-train configuration, remove the cable guide pipe and use the proper grommet (23) to fix...

  • Page 14: Electronic Drive-Train Specification

    GALLIUM PRO 210A: 4. Electronic drive-train specification The Di2 battery is hidden in the seatpost; use the Di2 battery holder to fix the battery correctly. Apply a slight amount of grease on both parts. GREASE...

  • Page 15: Saddle Adjustment

    GALLIUM PRO 210A: 5. Saddle adjustment 5.1 Install the saddle on the rocker (8.4.1) and tighten the rail clamp (8.4.2) using the screw (8.1). 5.2 Adjust the angle of the saddle using a 8mm open wrench on the 8.3 bolt.

  • Page 16: Saddle Adjustment

    GALLIUM PRO 210A: 5. Saddle adjustment 8.4.2 8.4.2 Seat clamp offset (-15mm to -25mm) by flipping the rail clamp (8.4.2).

  • Page 17: Derailleur Hanger Adjustment

    GALLIUM PRO 210A: 6. Derailleur hanger adjustment The front derailleur hanger can be adjusted according to the front derailleur angle to get an equal curve between the derailleur and the big chain ring. Once at the right angle, use blue 242 Loctite and screw in at 6Nm.

  • Page 18: Parts' Skus And Descriptions

    GALLIUM PRO 210A: 77. Parts’ SKUs and Descriptions 38661 38257 38260 38446 SP.GALLPRO.210A 38258 38316 37830 36197 38756 36682 38256 38251 38252 38259 38891 38254 FK.GALLPRO.210A Images are for reference only. Proportions are not accurate.

  • Page 19: Parts' Skus And Descriptions

    GALLIUM PRO 210A: 7. Parts’ SKUs and Descriptions* Name Assembled on A18 SKU# Parts already assembled Chain Stay Cable Stopper (incl. screws) Frame 36682 Toptube Cable Stopper Frame 38756 Rear Derailleur Hanger (incl. screw) Frame 37830 Front derailleur hanger (incl. screw)
