  • Page 1: Operating Instructions

    Operating instructions multiMATIC VRC 700/5 BE (fr), CH (fr), FR Publisher/manufacturer Vaillant GmbH Berghauser Str. 40 D-42859 Remscheid Tel. +49 21 91 18‑0 Fax +49 21 91 18‑2810 info@vaillant.de www.vaillant.de...
  • Page 2 Contents Contents Index ................... 27 Safety ..............3 Action-related warnings ......... 3 Intended use ............3 General safety information ........3 Recycling and disposal .......... 3 Notes on the documentation ......5 Observing other applicable documents ....5 Storing documents..........5 Validity of the instructions ........

  • Page 3: Safety

    Safety 1 use. Any direct commercial or industrial use Safety is also deemed to be improper. Action-related warnings Caution. Classification of action-related warnings Improper use of any kind is prohibited. The action-related warnings are classified in accordance with the severity of the possible General safety information danger using the following warning signs and 1.3.1 Danger caused by improper...
  • Page 4 1 Safety contain substances that are hazardous to human health and the environment. ▶ In this case, dispose of the batteries at a collection point for batteries. Operating instructions multiMATIC 0020255037_00...

  • Page 5: Notes On The Documentation

    Notes on the documentation 2 Notes on the documentation Product description Observing other applicable documents Design of the product ▶ You must observe all operating instructions enclosed with the system components. Storing documents ▶ Keep this manual and all other applicable documents safe for future use.

  • Page 6: Zones

    4 Operation 3.2.4 Hot water generation Preventing malfunctions ▶ A temperature sensor measures the temperature of the wa- Ensure that air can circulate freely around the controller, ter in the domestic hot water cylinder and forwards the val- and that the controller is not covered by furniture, cur- ues to the control.

  • Page 7: Basic Display

    Operation 4 4.1.3 Selection level Function of the right- Symbol for Auto operat- hand selection button ing mode Function of the left-hand Mode for the current selection button operating mode Desired setting Menu The basic display appears: Information Desired temperatures –...

  • Page 8: Operating Concept

    4 Operation 4.2.3.2 Basic display for the Cooling operating The setting that you change depends on the selected basic display, operating mode and the set mode for the operating mode mode. Mode Time Symbol Desired setting periods 4.3.1.1 Changing the desired setting in the Heating operating mode Auto Desired cooling temp.
  • Page 9 Operation 4 4.3.1.4 Changing the desired setting in the Manual Menu cooling advanced function Planning days away from home Planning days away from home Mode Time Effect periods Days at home scheduling Activated Direct permanent change to the Day Basic settings Basic settings temp.

  • Page 10: Operating And Display Functions

    5 Operating and display functions – You can use this function to read the water pressure of Display the heating installation. Display contrast Menu → Information → System status → System status Button lock – You can use this function to read the heating installa- tion's operating mode.
  • Page 11 Operating and display functions 5 5.1.1.2 ZONE1 The specifications for the energy consumption or energy yield are not suitable to be used to create or compare energy Menu → Information → System status → Day temp. heat- billing. – You can use this function to set the desired day temper- 5.1.2.1 Consumption ature for the zone.

  • Page 12: Settings

    5 Operating and display functions – 5.1.4 Reading the serial number and article You can use this function to read the total fuel consump- tion in kWh for hot water since start-up. number Menu → Information → Serial number 5.1.2.2 Diagram: Reading the solar yield –...
  • Page 13 Operating and display functions 5 5.2.3.4 Setting time programmes quickly ventilation level ensures the exchange of air that you want to have in the rooms at night or when you are not at home. The If, for example, you require different time periods for just operating instructions for the ventilation unit explain how the one working day in the week, first set the times for the entire ventilation unit works with the ventilation levels.
  • Page 14 5 Operating and display functions – 5.2.3.7 Setting the Cooling time programme The ventilation runs at the lowest ventilation stage. – The cooling is switched off. Menu → Time programmes → ZONE1: Cooling While the Days away from home scheduling function is –...
  • Page 15 Operating and display functions 5 5.2.7.1 Setting the date 5.2.12 Setting costs Menu → Basic settings → Date/time → Date You must specify all tariffs in the unit of currency per kWh for the calculation to be correct. – Select this function to set the current date. All controller functions that contain a date relate to the set date.

  • Page 16: Operating Modes

    5 Operating and display functions 5.2.15 Changing a zone name Operating modes Menu → Basic settings → Enter zone name The operating modes can be activated directly from any operating mode using the right-hand selection button Op. – You can now modify the factory-specified zone names as mode.

  • Page 17: Advanced Functions

    Operating and display functions 5 Advanced functions Day: The operating mode brings the zone to the desired temperature set for Day temp. cooling, regardless of the The advanced functions can be activated directly from any time periods that you have set in the time programme. operating mode using the right-hand selection button Op.

  • Page 18: Messages

    6 Troubleshooting 5.4.4 Ventilation boost Messages Op. mode → Ventilation boost 5.5.1 Maintenance message Menu → Basic settings → Operating mode → ZONE1 → Overview of maintenance messages (→ Appendix C) Ventilation boost If maintenance is required, the control displays a mainten- –...

  • Page 19: Care

    Back and the basic display appears on the display. After five minutes of no operation, the fault message appears again in La période de garantie des produits Vaillant s’élève à 2 ans the display. minimum contre tous les défauts de matériaux et les défauts de construction à...

  • Page 20: Customer Service

    Vaillant Sàrl Rte du Bugnon 43 CH-1752 Villars-sur-Glâne Schweiz, Svizzera, Suisse Service après-vente tél.: 026 40972‑17 Service après-vente fax: 026 40972‑19 Applicability: France Les coordonnées de notre service après-vente sont indiquées au verso ou sur le site www.vaillant.fr. Operating instructions multiMATIC 0020255037_00...

  • Page 21: A Overview Of The Operating And Display Functions

    Appendix Appendix Overview of the operating and display functions Note The functions and operating modes listed are not available for all system configurations. Operating modes Operating mode Setting Default setting Operating mode Heating off, Auto, Day, Set-back Auto Cooling off, Auto, Day Auto Ventilation Auto, Day, Set-back...
  • Page 22 Appendix Setting level Values Unit Increment, select Default setting Min. Max. Air quality sensor 2 Current value Exhaust air humidity Current value %rel Information → Consumption → Current month → Heating ---- Electricity Total value for the current month Fuel Total value for the current month Hot water ----...
  • Page 23 Appendix Setting level Values Unit Increment, select Default setting Min. Max. Information → Heat recovery → Bar chart Previous year to cur- kWh/month rent year comparison Information → Contact details → Installer Phone number Current values Information → Serial number Product number Permanent value Desired temperatures →...
  • Page 24 Appendix Setting level Values Unit Increment, select Default setting Min. Max. Period 1: Start – End 00:00 24:00 h:min 00:10 Mo - Su: 11:00- 13:00 Period 2: Start – End Period 3: Start – End Days away from home scheduling → Start 01.01.01 31.12.99...

  • Page 25: B Troubleshooting

    Appendix Setting level Values Unit Increment, select Default setting Min. Max. Basic settings → Max. room air humidity → Max. room air hum. %rel Basic settings → Default setting → Time programmes Yes, No Everything Yes, No Installer level → Enter code Troubleshooting Symptom...
  • Page 26 Appendix Message Description Maintenance work Interval Service ventila- The ventilation unit requires Refer to the operating instruc- See the operating instructions tion unit maintenance work. tions of the ventilation unit for for the ventilation unit information on the maintenance work required Low water pres- The water pressure in the heat- Refer to the operating instruc-...
  • Page 27 Index Index Main function ................. 5 Maintenance message ............18 1 day at home ..............17 Manual cooling ..............17 1 day away from home............17 Nomenclature ................ 5 Activating Button lock ............15 Activating Heat recovery ............ 16 Operating concept ..............8 Operating level ..............
  • Page 28 Index Time period, deviating times in the block ......13 Time programme quick setting..............13 Setting................13 Time programme after switching off the voltage ....13 Ventilation................5 Ventilation boost ............... 18 Ventilation level ..............12 Zone ................6, 12 Zone in the basic display............
  • Page 32 0020255037_00 0020255037_00 30.06.2017 Supplier VAILLANT GROUP FRANCE "Le Technipole" 8, Avenue Pablo Picasso F-94132 Fontenay-sous-Bois Cedex Téléphone 01 49741111 Fax 01 48768932 Assistance technique 08 26 270303 (0,15 EUR TTC/min) Ligne Particuliers 09 74757475 (0,022 EUR TTC/min + 0,09 EUR TTC de mise en relation) www.vaillant.fr...
