- Page 1 For the operator / for the expert technician Operating and Installation Manual VRT 392f VRT 392 Room thermostat with radio transmission VRT 392f...
-
Page 3: Table Of Contents
For the owner Operating manual VRT 392f Room thermostat VRT 392f Contents Equipment properties ..........4 4.3.2 Changing parameters ..........9 Application ................4 4.3.3 Operation in the default display ......11 Product specifications ............4 Changing the target room temperature ...12 Operation level for the operator, operation Notes on the documentation ...... -
Page 4: Equipment Properties
"Turn and Click" – The radio receiver unit can be mounted directly on the The VRT 392f can be part of a new heating and hot operating panel of the appliance or separately on the water system or it can be incorporated into wall existing heating systems. -
Page 5: Notes On The Documentation
Storage of the documents Please store this operating manual and all related The VRT 392f may only be installed by a certified expert documents in such a way that they are available technician. This person is also responsible for the proper whenever required. -
Page 6: Instructions For Operation
– that the air in the room can circulate freely around the VRT 392f and the VRT 392f is not covered by furniture, curtains or other objects. – that all the radiators in the room where the VRT 392f is fitted are fully on. Care Clean the casing of the VRT 392f with a damp cloth. -
Page 7: Operation
Depending on the ambient conditions, it may take up to 15 minutes until the current data are called up by the radio receiver unit and are subsequently displayed. If dashes (--) are displayed continuously, consult your expert technician. Operating manual VRT 392f 0020044239_01... -
Page 8: Overview Of The Displays
Operating concept The display and input parameters (operating values) of The operator input in the default display is described in the VRT 392f are shown on the various screens. Section 4.3.3. The screens are sub-divided into: The operating concept described below applies to the –... -
Page 9: Show Various Screens
Time programme > Change target hot water 06 : 00 - 10 : 40 21.5 °C Fig. 4.5 Scroll to various different modifiable parameters > Select day of week Fig. 4.4 Display of the various screens Operating manual VRT 392f 0020044239_01... - Page 10 > Change room temperature Fig. 4.7 Changing the values of a parameter Click the right-hand dial. The value displayed is confirmed and adopted for control purposes. The value is saved and is no longer highlighted. Operating manual VRT 392f 0020044239_01...
-
Page 11: Operation In The Default Display
= 5 °C) is guaranteed. for each index turn of the dial. Table 4.3 Operating modes of the heating circuit Click the right-hand dial once the required value for the room target temperature has been reached. Operating manual VRT 392f 0020044239_01... -
Page 12: Changing The Target Room Temperature
Turn the right-hand dial further until the desired room temperature appears. The selected room target temperature is applied after a delay of two seconds. The representation once again changes from inverse to normal and shows the internal temperature. Operating manual VRT 392f 0020044239_01... -
Page 13: Operation Level For The Operator, Operation Level For The Expert Technician
Operation level for the operator, operation level for the expert technician 25 ° The VRT 392f is equipped with two operation levels. Each level contains several screens in which the various parameters can be displayed, adjusted or changed. 20 °... - Page 14 1 entered Hot water water Release code level Code number Access to the level for 1000 the installer only by entering the saved code number Table 4.4 Screens at the operation level for the operator Operating manual VRT 392f 0020044239_01...
-
Page 15: Editing Screens (Examples)
4.7.1 Entering time programmes (example for The VRT 392f provides heating in accordance with the heating) corresponding comfort temperature (e.g. 21.5 °C) within Using the time programmes you can allocate up to three a specific time window (e.g. -
Page 16: Programming Holiday Periods
For a longer period of time when you are not at home, Click the right-hand dial. you can define a lower room temperature. This will save heating energy. The VRT 392f ensures that the The field is highlighted. living spaces are only heated with reference to the specified temperature. -
Page 17: Entering The Parameters For Hot Water Generation
(numbers 0-9, spaces, capital/small letters). This is how to do it: Turn the left-hand dial until you reach screen "Change names". Turn the right-hand dial until the cursor is positioned in front of the character you wish to change. Operating manual VRT 392f 0020044239_01... -
Page 18: Status And Error Messages
The connection between the radio receiver unit and appliance is faulty. Contact your expert technician. No radio communication Radio communication between the VRT 392f and radio receiver unit is faulty. Contact your expert technician. Change battery The batteries at the controller are almost empty. - Page 19 LED on: everything OK red LED on: error (no communication with appliance or controller) red LED flashes briefly: radio transmission green LED flashes: the teach-in process was started via a button (only relevant for parts replacement) Operating manual VRT 392f 0020044239_01...
-
Page 21: Installation Instructions
For the expert technician Installation instructions VRT 392f Room thermostat VRT 392f Contents Notes on the documentation ......2 Installation ............7 Storage of the documents ........2 Electrical installation for the wall-mounted Symbols used ............2 wireless receiver unit ..........7 Validity of the instructions ........2 Initial commissioning ........8... -
Page 22: Notes On The Documentation
The part number of your appliance can be taken from Other applicable documents the identification plate. – Operating manual for the Vaillant room thermostat VRT 392f – The operating and installation instructions for your heating system –... -
Page 23: Description Of The Device
– Directive on Electromagnetic compatibility and Radio (Alkaline AA/LR6 1.5V). spectrum Matters (ERM) (Directive ETSI EN 300220-2) With the VRT 392f data is exchanged via a radio link to the radio receiver unit. Intended use The room thermostats VRT 392f are built using state-of-... -
Page 24: Safety Instructions And Regulations
Safety instructions and regulations Install the flue system as detailed in the separate flue installation instructions supplied with this boiler. The VRT 392f must be installed by a recognised expert technician company that is responsible for ensuring that 3.3.2 Related documents existing standards and regulations are observed. -
Page 25: Assembly
Assembly 4 Assembly Installing the radio receiver unit in the appliance The VRT 392f must be installed in the living area against a wall. The connection with the appliance is made using Danger! a radio link. Voltage carrying connections! When working in the control cabinet of the... -
Page 26: Mounting The Radio Receiver Unit On The Wall
Fig. 4.2 Installation of the VRT 392f Room thermostat VRT 392f 2 Wall socket Fig. 4.1 Installation of the radio receiver unit... -
Page 27: Installation
Install the strain relief (4, Fig. 4.1). appliance. Connect the eBUS cable to the terminal strip of the appliance (2). Installation instructions VRT 392f 0020044239_01... -
Page 28: Initial Commissioning
The quality of the wireless data communication for outdoor sensors and controllers is represented by a Initial condition: number between 0 and 10. The controller VRT 392f and the radio receiver unit are no reception installed correctly. poor quality The appliance is switched on and ready for operation. -
Page 29: Operation Level For Expert Technician
This means that an optimum match can setting be found between the controller and the heating system. The works as-delivered condition of the VRT 392f can be restored as follows: The level for the expert technician consists of the display screens C1 to C26 and the display screens A1, A2 Push both dials simultaneously for 10 seconds. - Page 30 Maintenance date Day/Month/Year adjustable Tools Room temperature Adjustment of room correction temperature sensor Display contrast Software versions Software version Display of version per module (A) number Table 6.2 Screens in the expert technician operation level Installation instructions VRT 392f 0020044239_01...
-
Page 31: Handover To The Operator
Special features Battery economy mode Appliance The VRT 392f and its accessories must not be disposed of in the household waste. Make sure the old device and Note The display is normally switched off to save any existing accessories are disposed of properly. -
Page 32: Technical Data
Range: in free field > 100 m in building approx. 25 m Height mm Width mm Depth mm Table 9.1 Technical data VRT 392f Parameter Radio receiver unit Operating voltage Umax max. 24 V Current consumption < 60 mA Level of protection... -
Page 33: Glossary
A circulation pump circulates hot water via your hot water pipe. This means that hot water is available instantly when the water cock is opened. Time windows can be programmed for the circulation pump. Installation instructions VRT 392f 0020044239_01...
