14. Full Power Switch – The generator is provided with a
full power switch. Figure 6 and Figure 7 show simplified
wiring diagrams of the dual voltage system.
When the full power switch is in the 120 volt (up)
position, you can access the full rated power of the
generator at 120 volts from the GFCI duplex receptacle
and the120V twist-lockreceptacle, or a combination
of both receptacles as long as the total load does not
exceed the generating set capacity.
V
H
U1
W
V1
U2
SW 120V
V2
9 8 7
6 5 4
3 2 1
Figure 6. 120V Full Power Switch
Simplified Diagram (Up Position)
NOTICE
When the full power switch is in the 120V position, the
240V twist-lock receptacle cannot be used.
PAGE 20 — GAC6HR/HRS 60 HZ GENERATOR• OPERATION AND PARTS MANUAL — REV. #1 (12/13/17)
GAC-6HR
120 120
V V
120 120
MARCHE ON MARCHE
AC VOLTMETER
VOLTOMETRE CA
ARRET OFF ARRET
120V 120V
IDLE OPERATION
CONTROL SWITCH
MAIN AC CIRCUIT BREAKER
CONTROL INTERRUPTEUR
DISJONCTEUR PRINCIPALE DE COURANT CA
DE RALENTI DU OPERARION
QUARTZ QUARTZ
240/120V 240/120V
FULL POWER
SWITCH
HOUR METER
120V 20A 120V 20A 120V 30A 120/240V 20A
INTERRUPTEUR
COMPTEUR
PLEINE
D' HEURE
PUISSANCE
NEUTRAL BONDED TO FRAME. PRISE DE
TOTAL LOAD WITHIN 5kW
NEUTRE MIS A LA MASSE A TERRE
CHARGE TOTALE MAX. 5kW
LA CARCASSE DU MOTEUR.
Figure 5. Generator Components (Full Power Switch)
CON1 CON3
CB
22 CON2
CON4
COMPONENTS (GENERATOR)
GAC6HRS
ON
OFF
14
GR
When the switch is in the 240 volt (down) position, you can
access half of the rated power of the generating set at 120
volts from the GFCI duplex receptacle and up to half of the
rated power of the set at 120 volts from 120V twist-lock
receptacle; or full rated power of the set at 240 volts from
the 240V twist-lock receptacle.
U1
W
V1
U2
V2
CON5
Figure 7. 240/120V Full Power Switch
Simplified Diagram (Down Position)
NOTICE
When using a combination of receptacles, total load
should not exceed the rated capacity of the generator.
