OperatiOn and parts Manual
MOdel gac2.2h
pOrtable generatOr
(hOnda gX160 gasOline engine)
Revision #1 (03/31/10)
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading

Related Manuals for MULTIQUIP GAC2.2H

Summary of Contents for MULTIQUIP GAC2.2H

  • Page 1 OperatiOn and parts Manual MOdel gac2.2h pOrtable generatOr (hOnda gX160 gasOline engine) Revision #1 (03/31/10) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

  • Page 2: Table Of Contents

    NOTICE Generator Assembly ......... 34-35 Specifications and part numbers are subject to change Control Box Assembly ........36-37 without notice. Pipe Frame Assembly ........38-39 page 2 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 3: Parts Ordering Procedures

    All orders are treated as Standard Orders and will ship the same day if received prior to 3PM PST. We accepT all maJOR cRediT caRds! gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 3...

  • Page 4: Safety Information

    Indicates a hazardous situation which, if not avoided, cOuld result in miNOR or mOdeRaTe iNJuRY. NOTICE Addresses practices not related to personal injury. page 4 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 5: Safety Information

    „ alWaYs store equipment properly when it is not being used. Equipment should be stored in a clean, dry location out of the reach of children and unauthorized personnel gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 5...

  • Page 6: Engine Safety

    A spark arrester is a device designed „ Store fuel in appropriate containers, in well-ventilated areas and away from sparks and fl ames. page 6 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 7: Electrical Safety

    „ alWaYs recharge the battery in a well-ventilated environment to avoid the risk of a dangerous concentration of combustible gasses. gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 7...
  • Page 8 „ Use one point suspension hook and lift straight upwards. „ dO NOT lift machine to unnecessary heights. „ alWaYs tie down equipment during transport by securing the equipment with rope. page 8 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 9 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 9...

  • Page 10: Specifications (Generator)

    106 lbs. (48 kg.) NOTICE In keeping with Multiquip's policy of constantly improving its products, the specifications quoted herein are subject to change without prior notice. page 10 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 11: Specifications (Engine)

    Generally, the engine's output power will decrease 3-1/2% for each 1000 feet (305 meters) of altitude above sea level, and 1% for each 10° F (-12.2° C) above the standard temperature of 60° F (15.5° C). gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 11...

  • Page 12: Dimensions

    211052 INTERRUPTEUR DE COURANT PRINCIPAL GR PRISE DE TERRE A21210011 18.30 IN. (465 MM) 19.7 IN. (500 MM) 16.1 IN. (410 MM) Figure 1. Dimensions page 12 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 13 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 13...

  • Page 14: Installation

    FOR EARTH GROUND GROUND CABLE GENERATOR #8 MINIMUM GROUND LUG CONNECT TO BUILDING GROUND IF REQUIRED 8 FT. MINIMUM REFERENCE NEC 250-52(C) Figure 2. Generator Grounding page 14 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 15: Installation

    Pay close attention to handling when operating vibrators and always use rubber boots and gloves to insulate the body from a short circuit. gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 15...

  • Page 16: General Information

    Box The control box is provided with the following: „ 120V GFCI receptacle. „ 15 Amp Main Circuit Breaker. „ AC Voltmeter „ Ground Terminal page 16 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 17: Components (Generator)

    4. engine Oil Filler cap – Remove cap/dipstick when the adding of engine oil is required. See Table 4 for recommended type engine oil. gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 17...

  • Page 18: Components (Generator)

    The choke enriches the fuel mixture. Open the choke lever if starting a warm engine or in warm weather conditions. page 18 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 19: Inspection/Setup

    1800 3600 150 ft. 100 ft. 65 ft. 2400 4800 125 ft. 75 ft. 50 ft. cauTiON: Equipment damage can result from low voltage. gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 19...
  • Page 20 Wipe up any spilled fuel immediately! oil filler hole with the recommended oil type (Table 4). Maximum oil capacity is .63 quarts (0.6 liters). page 20 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 21: Operation

    NOT pull the starter rope all the way to the end. dO NOT release the starter rope after pulling. Allow it to rewind as soon as possible. Figure 11. Choke Lever gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 21...
  • Page 22 (Normal shutdown) 1. Place the main circuit breaker (Figure 16) in the OFF position. Figure 16. Main Circuit Breaker (OFF page 22 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 23: Preparation For Long Term Storage

    „ Clean all external parts of the generating set with a cloth. „ Cover the generating set and store in a clean, dry place. gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 23...

  • Page 24: Maintenance

    (2) These items should be serviced by your service dealer, unless you have the proper tools and are mechanically proficient. Refer to the HONDA Shop Manual for service procedures. (3) For commercial use, log hours of operation to determine proper maintenance intervals. page 24 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 25: Maintenance

    Table 4. For engine oil capacity, see Table 2 (engine specifications). dO NOT overfill. 4. Install drain bolt with sealing washer and tighten securely. Figure 21. Engine Air Cleaner gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 25...

  • Page 26: Generator Wiring Diagram

    AC Voltmeter (120/240) BROWN YELLOW Rectifier GREEN LIGHT BLUE GRAY LIGHT GREEN Receptacle 5-15R VIOLET ORANGE UPM-1 15A PINK CP-31E/15N 15A Figure 22. Generator Wiring Diagram page 26 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 27: Troubleshooting (Engine)

    Compression is proper Improper level in carburetor? Check float adjustment. Rebuild carburetor. and does not misfire. Defective spark plug? Clean or replace spark plug. gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 27...

  • Page 28: Troubleshooting (Generator)

    Check entire fuel system for leaks or clogs. Recoil mechanism clogged with dust and Clean recoil assembly with soap and water. Recoil starter dirt? malfunction. Spiral spring loose? Replace spiral spring. page 28 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 29 Does not decelerate but has "VOLTAGE OUTPUT". Defective solenoid? Check or replace solenoid. Idle control device malfunction? Check or replace idle control device. gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 29...

  • Page 30: Explanation Of Code In Remarks Column

    Multiquip. Other entries will for sale through Multiquip. be clarifi ed in the “Remarks” Column. page 30 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 31: Suggested Spare Parts

    ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 31...

  • Page 32: Nameplate And Decals Assembly

    A91110020 exigences de prévention –incendie A90400020 Do not use in rain or snow. ATTENTION Ne pas utiliser en cas de pluie ou neige. A3520000A page 32 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 33 DECAL; DANGER, GROUND ROD ....1....A91110020 .....................S/N 5560984~5582067 A9504000104 DECAL; DANGER, DANGEROUS GASES ..1....A90400010 .....................S/N 5582068~5623308 A9504000204 DECAL; WARNING, SPARK ARRESTOR ..1....A90400020 .....................S/N 5623309 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 33...

  • Page 34: Generator Assembly

    34 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 35 WASHER, FLAT 7871329514 GROMMET 0601851760 0017408020 HEX. HEAD BOLT 7935420104 STAY, MUFFLER 0021806010 MACHINE SCREW 7935420004 STAY, MUFFLER 0207206000 HEX. NUT 0017108020 HEX. HEAD BOLT gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 35...

  • Page 36: Control Box Assembly

    36 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 37 HEX. NUT 0017105010 HEX HEAD BOLT 0040505000 TOOTHED WASHER 0601812590 RECEPTACLE, 515R GF5252 0027104016 MACHINE SCREW 0038304000 HEX NUT A2225200004 CB COVER 0027103010 MACHINE SCREW gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 37...

  • Page 38: Pipe Frame Assembly

    38 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 39 HEX HEAD BOLT 0017106016 HEX HEAD BOLT 0017106016 HEX HEAD BOLT 0040506000 TOOTHED WASHER 0031308000 HEX NUT 0011308020 HEX HEAD BOLT 0040008000 WASHER, LOCK gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 39...

  • Page 40: Cylinder Head Assembly

    — cyl. hd assy. page 40 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 41 PLUG, SPARK (BPR6ES NGK) 9807956855 PLUB, SPARK (W20EPR-U ND) ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 41...

  • Page 42: Cylinder Barrel Assembly

    — cyl. barrel assy. page 42 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 43 PIN, LOCK, 8MM 957010601200 BOLT, FLANGE, 6X12 06111ZH8405 GASKET KIT ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 43...

  • Page 44: Crankcase Cover Assembly

    — cranKcase cvr. assy . page 44 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 45 CAP, OIL FILLER 15625ZE1003 GASKET, OIL FILLER CAP 91201Z0T801 OIL SEAL, 25X41X6 9430108140 PIN, DOWEL 8X14 957010803200 BOLT, LANGE 8X32 961006205000 BEARING, RADIAL BALL, 6205 gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 45...

  • Page 46: Crankshaft Assembly

    — cranKshaft assy. page 46 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 47 — cranKshaft assy. paRT NO. paRT Name QTY. RemaRKs 13310ZB2000 CRANKSHAFT COMP. gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 47...

  • Page 48: Piston Assembly

    — pistOn assy. page 48 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 49 90001ZE1000 BOLT, CONNECTING ROD 90551ZE1000 CLIP, PISTON PIN, 18MM ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 49...

  • Page 50: Camshaft Assembly

    — caMshaft assy. page 50 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 51 BOLT, PIVOT (8MM) 90206ZE1000 NUT, PIVOT ADJUSTING 18♦ 12209ZH8003 VALVE STEM ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 51...

  • Page 52: Recoil Starter Assembly

    — recOil starter assy . page 52 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 53 SCREW, SETTING 12◊ 90003ZH8801 SCREW, SETTING 90008ZE2003 BOLT, FLANGE 6X10 ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 53...

  • Page 54: Fan Cover Assembly

    — fan cOver assy . page 54 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 55 BOLT, FLANGE 6X8 ...........1....USE FROM S/N 5372719 24◊ 957010600800 BOLT, FLANGE 6X8 ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 55...

  • Page 56: Carburetor Assembly

    — carburetOr assy. page 56 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 57 JET, MAIN, #75, 99204ZE00350 JET SET, PILOT, #35 .........1....INCLUDES ITEMS W/# ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 57...

  • Page 58: Air Cleaner Assembly

    — air cleaner assy. page 58 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 59 957010601000 BOLT, FLANGE, 6X10 10◊ 17232898000 GROMMET, AIR CLEANER ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 59...

  • Page 60: Muffler Assembly

    — Muffler assy. page 60 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 61 PROTECTOR, MUFFLER OUTER 18325ZH8T90 PROTECTOR, MUFFLER INNER 18329ZB2000 SEAL, MUFFLER PROTECTOR 18330ZH8T90 PIPE COMP., EX 18355898630 ARRESTER, SPARK 18381ZE1800 GASKET, MUFFLER 18381ZH8800 GASKET, MUFFLER gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 61...
  • Page 62 — flywheel assy. page 62 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 63: Flywheel Assembly

    NO. paRT Name QTY. RemaRKs 13331357000 KEY, SPECIAL WOOD RUFF, 25X18 19511ZE1000 FAN, COOLING 28451ZH8003 PULLEY, STARTER 31100ZE1811 FLYWHEEL (LAMP) 90201878003 NUT, SPECIAL, 14MM gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 63...

  • Page 64: Ignition Coil Assembly

    — ignitiOn cOil assy. page 64 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 65 BOLT, FLANGE, 5X10 90015883000 BOLT, FLANGE, 6X28 90121952000 BOLT, FLANGE, 6X25 ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 65...

  • Page 66: Governor Control Assembly

    — gOv . cOntrOl assy. page 66 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 67 SPRING, THROTTLE RETURN 90015ZE5010 BOLT, GOVERNOR ARM 9405006000 NUT, FLANGE, 6MM ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 67...

  • Page 68: Engine Decals Assembly

    — decal assy. page 68 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 69 MARK OPERATOR CAUTION (ENGLISH) ..1....USE FROM S/N 1253962 4◊ 87516ZH7010 MARK OPERATOR CAUTION (PICTOGRAPH) 1 ♦GX160K1EMA2: Model GAC2.2H, JUNE 2006 AND BELOW ◊ GX160U1EMAN: Model GAC2.2H, FEBUARY 2007 AND ABOVE gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 69...
  • Page 70 — tOOl Kit page 70 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)

  • Page 71: Tool Kit

    89000ZE1000 TOOL KIT ............1....INCLUDES ITEMS W/# 89218ZE1000 WRENCH COMP. (SPARK PLUG) 89219805000 HANDLE, BOX WRENCH 9900110120 SAPNNER, 10X12 9900114170 SAPNNER, 14X17 9900802300 BAG TOOL gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 71...

  • Page 72: Terms And Conditions Of Sale - Parts

    Multiquip’s designated receiving point. page 72 — gac2.2H 60 Hz geNeRaTOR• OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10)
  • Page 73 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 73...
  • Page 74 © COPYRIGHT 2010, MULTIQUIP INC. Multiquip Inc and the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their respective owners and used with permission.
