FOLDING MECHANISM ADJUSTMENT

For more rigid feel:
Use Allen Key number 2.5 to release tension on both sides of M4 screws
as shown on Figure 1.
Then use Allen Key number 2 and gently tighten both screws as shown
on Figure 2.
Test the function and only then, tighten back both sides of M4 screws
(Figure 3)
For easier folding:
Use Allen Key number 2.5 tor release tension on both sides of M4 screws
as shown on Figure 1.
Then use Allen Key number 2 and gently release tension on both screws
as shown on Figure 2.
Be aware that the distance is only a few millimetres. Be careful that the
screws will not fall out of their place.
Test the function and only then, tighten back both sides of M4 screws
(Figure 3)
SUMMARY
TIGHT = RIGID MECHANISM
LOOSE = EASY FOLDING
LOOSE
TIGHT
2 8
