Okamura 865XTW Assembly And Instruction Manual

3-drawer Wagon
865XTW

Assembly/Instruction Manual

Important Document
Thank you for purchasing an Okamura 3-
drawer Wagon. Carefully read and
understand the contents of this Assembly/
Instruction Manual to ensure proper
assembly and use.
Caution label
(Attached to wagon
top panel)
Product serial number sticker
(Attached to bottom plate)
(Do not remove the caution label.)

Parts list

(Make sure to check the information below before you start assembling.)
Caster
(with stopper)
Single-end connection bolt
Divider
(These are already installed
in the file drawer.)
Use a cross-head screwdriver for assembly.
Do not use an electric screwdriver or power tools,
as they may damage the product. Use a manual
screwdriver instead.
Diagram of assembled wagon
Drawer unit
Upper drawer
Middle drawer
File drawer
Caster
(without stopper)
Nut cap Key
Wagon
A cross-head screwdriver is required for
assembly. Have one ready before you begin.
* Do not use an electric screwdriver for
assembly, as it could damage the product
Lock
Caster
For safety reasons, the length that the upper drawer
can be pulled out is slightly less than that for the
middle drawer and file drawer.
Note about screw-type connectors
Screw-type connector
(Embedded in various parts)
Turn clockwise to tighten.
Turn counter-clockwise to loosen.
When the arrow is aligned with the
connecting bolt, it can be inserted
(or removed).
(names of parts)
Wagon
Ti g hten
Screw-type
connector
Loosen
Arrow
Single-end connection bolt
Drawer unit
