► Menu installation

Satellite installation
Please observe the following notes before configuring in the menu:
HDTV Sat TV requires a minimum size satellite dish of 80 cm. A specialist should calibrate the system
with a digital TV level measuring set. Depending on the setting selection, the intensity level and quality
of the signal is shown in the lower area.
Functions and settings in the menu:
Satellite: Select with the left/right arrow buttons the satellite to be installed.
LNB type:
TP index:
DiSEqC:
Position:
22K:
Polarity:
Toneburst:
LNB strength:
Use the red button to call up the menu for the search of channels of the set satellites.
The following settings can be found in this menu:
Search mode:
Program type:
Select search mode:
NIT search:
Navigate with the up/down arrow buttons to the 'OK' button for search and then press the OK button
to start the search process. The menu window can be exited at any time with the EXIT button.
Set here the LNB type used.
Set the transponder here.
Set the value here for the DiSEqC.
When motor control is used, you can set it's actuation here.
This point can only be reached if the 'Universal' value was not set at 'LNB
type' item. The 22 kHz circuit can then be switched on or off. The 22 kHz
circuit is used to switch the lower and upper frequency band in the LNB.
Polarity can be set here.
Toneburst is an additional trigger value provided by receivers. This signal
does not contain digital commands, however, most switches can evaluate
this signal for position switching. Set the value to 'On' or 'Off'.
Set this parameter to 'On' or 'Off'.
Select here between the values All (channels) or Available (channels). With
the value All, encrypted and free-to-air channels are sought.
Specify here whether the TV, Radio or TV and Radio channels are sought.
Set here a 'Manual Search' or 'Blind Scan'.
Set here whether the NIT (Network Information Table) should be used during
the search.
