PART IDENTIFICATION CHART

See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST on page 18. Note: Some small parts may have been pre-
assembled. If a part is not in the parts bag, check to see if it has been preassembled.
M4 x 16mm
Screw (47)
M6 Washer (21)
M10 Nylon
Locknut (49)
M10 Washer (52)
M6 x 75mm Screw (48)
M10 x 75mm Button Screw (55)
M6 x 25mm
M10 x 85mm Button Screw (57)
Screw (50)
M10 x 16mm
Bolt (51)
M10 x 70mm Bolt Set (54)
M10 x 55mm Button Bolt (53)
M10 x 98mm Button Bolt (56)
5
