TP- Series
Price Computing Scale
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP-15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CAS TP-15

Summary of Contents for CAS TP-15

  • Page 1 TP- Series Price Computing Scale OWNER’S MANUAL...
  • Page 2 CONTENTS PRECAUTIONS PREFACE NAMES AND FUNCTIONS INSTALLATIONS OPERATIONS 1. General Weighing 2. Weighing with Tare 3. Saving a PLU to Memory 4. How to Call up a PLU 5. Add up the Price 6. Add up Fixed Price Commodities 7. Multiplication Function 8.

  • Page 3: Precautions

    PRECAUTIONS Make sure that you plug your scale into the proper power outlet. Plug into a power outlet 30 minutes before operations. Place the scale on a flat and stable Do not subject the scale to sudden surface. temperature changes. Do not subject the platter to sudden This scale must be installed in a dry shocks.
  • Page 4 If the scale is not properly leveled, please adjust the 4 legs at the bottom of the scale(turn legs clockwise or counterclockwise) so as to center the bubble of the leveling gauge inside the indicated circle. Leveling gauge Keep the scale away from strong EMI noises may cause incorrect weight readings.

  • Page 5: Preface

    PREFACE Thank you for purchasing our CAS TP-II. These series have been designed with CAS reliability, under rigid quality control and with outstanding performance. Your specialty departments can enjoy these high quality reliable CAS products. We believe that your needs will be satisfied and you will have proper reliability.
  • Page 6 DISPLAY & KEYBOARD MODE CALL ZERO TARE FUNCTIONS KEYS DESCRIPTIONS Used to enter all the numerical data. Used to enter a double zero. Used to clear erroneous entries and error conditions. Used to display the daily total price. Used to call the added total price. Used to calculate a change.

  • Page 7: Installations

    KEYS DESCRIPTIONS Multiplication key. Used to correct the zero point. Used to enter a tare weight. Used to delete a tare weight. No function key. (option: PRINT key) Turns on and off the power. Used to turn on/off the back light. INSTALLATIONS Insert the post pipe into a post bracket as Fig.

  • Page 8: Operations

    OPERATIONS Turn on the display by pressing the ON/OFF key. When you turn on the display, the display will show all the segments and count up “0” to “9”. (If you want to stop it, press any key.) When you turn on the display, make sure that platter is empty. Otherwise, display will show the “OFL”.

  • Page 9: Weighing With Tare

    2. Weighing with Tare Tare is the weight of container being used for a commodity. The TARE key subtracts the weight of the container. Place the container on the platter. Press the TARE key. Make sure that ZERO and TARE lamps should be on.

  • Page 10: Saving A Plu To Memory

    Remove the container and the commodity, then the display will show the weight of container with “-”. Press the TARE key. TARE 3. Saving a PLU to Memory This function stores each PLU into a internal back up memory. PLU means Price Look Up which has a unit price. Direct PLU Enter a unit price by pressing the numeric keys.
  • Page 11 If you use tare for this PLU, enter the weight of container and press the MW key. (500g) If you don't use tare for this PLU, just press the MW key. Note: While saving a PLU, you have the option of programming tare. (Refer to 14.
  • Page 12 If you use tare for this PLU, enter the weight of container and press the MW key. (500g) If you don't use tare for this PLU, just press the MW key. Note: While saving a PLU, you have the option of programming tare. (Refer to 14.
  • Page 13 Place a commodity with container, then you will see the total price. Note: Before you call up a PLU, you should save it to the memory. Indirect PLU Enter the address of a PLU and press the MR key. (Address: 100) You will see the tare and the unit price.

  • Page 14: Add Up The Price

    5. Add up the Price When you need to weigh a commodity, you can use this method. Place the commodity on the platter. Enter a unit price or call up a PLU, then you will see the total price. After you hear a beep sound, press the + key. If you want to cancel the last transaction you just entered, press the - key.

  • Page 15: Add Up Fixed Price Commodities

    Remove the commodity from the platter, then you can go to normal mode. If you have other items to add up, go to step and then follow these steps again. Note: This function could be continued either up to 99 transactions or the total price reaches up to 99999999.

  • Page 16: Multiplication Function

    7. Multiplication Function Make sure that display should be zero. Enter a unit price by pressing numeric keys or call up a PLU. Press the key. Enter the number of items by pressing numeric keys, then you will see the price. (EXAMPLE : 10 pieces, Unit Price : 2.00) Note: You can enter the number of commodities up to 99.

  • Page 17: How To Display The Added Total Price

    Press the + key again, then you can go to normal mode automatically. 8. How to Display the Added Total Price To confirm the added total price Press the TTP CALL key. CALL Press the TTP CALL key again, then you can go to normal mode automatically.

  • Page 18: Change Calculation

    Press the C key. 9. Change Calculation Press the TTP CALL key, then you will see the added total price. CALL Press the PAY key. Enter the customer's payment. Press the PAY key, then you will see the change.

  • Page 19: Daily Total Price

    Press the PAY key, then the added total price will be cleared. Note: A customer's payment should be always bigger than the total price. Otherwise, you will see the error message and error beep sound may be generated. (Refer to ERROR MESSAGE) 10.

  • Page 20: How To Call The Daily Total Price

    Remove the commodity from the platter then you can go to normal mode. 11. How to Call the Daily Total Price To confirm the daily total price. Make sure that platter is empty. Press the MODE key. (For example, the number of transactions : 253 times, MODE daily total price : 12,357,600.00$) Press the MODE key, then you can go to normal mode.

  • Page 21: Auto-Power Off

    Press the C key, then you can go to normal mode. 12. Auto-Power Off Auto-power off function makes the battery’s life longer. When you don’t operate the scale, this function makes the power OFF automatically. Make sure that power is off. Press the ZERO and ON/OFF key at the same time.

  • Page 22: How To Set The Back Light Function

    Press the ZERO key. Then the scale saves what you programmed and shows the End , then count up 0 to ZERO 9 . You can go to normal mode. 13. How to Set the Back Light Function After setting the auto power off, press the ZERO key then you can set the back light function.

  • Page 23: Tare Option

    14. Tare Option While saving a PLU, you have the option of programming tare. After setting the back light function, press the ZERO key. Press the TARE key until the display shows ON or OFF. TARE ON means that you can program tare while saving a PLU and OFF means that you can’t program tare while saving a PLU.
  • Page 24 TABLE 3. ASCII Code HIGH ORDER LOW ORDER & < > Key functions for ASCII code SAVE Note: Date, telephone number and store name can be up to 24 characters long and a monetary unit can be up to 3 characters long. Once you have entered the data, enter 00 and press the SAVE key.
  • Page 25 Programming a date Make sure that the power is off. While pressing the key, press the ON/OFF key. Then the display shows ‘print set’. Enter the date by using the ASCII code. (Refer to Table 3) A date can be up to 24 characters long. You can edit the date by pressing the [ ],[ ] keys.
  • Page 26 Programming a monetary unit You can program a monetary unit in the same way. (Refer to Programming a date.) A monetary unit can be up to 3 characters long. Once you have entered the monetary unit, enter 00 and press the SAVE key. The display show End and go to normal mode.
  • Page 27 Fixed Item KOREAN SHOPPING CENTER 1. Enter the amount of an item TEL. (02) 2225-3500 and press the + key. 200-09-01 2. Enter the amount of another item and press the + key. fixed item 1000 3. To print this transaction, fixed item 1800 ========================...

  • Page 28: How To Charge The Battery

    16. How to Charge the Battery If you have the low battery, the scale shows . At this time, charge the battery by using the adapter. Note that only rechargeable battery is available. When the red lamp is on, it means that the battery is charging. It takes for 4 hours to charge the battery.

  • Page 29: Error Message

    ERROR MESSAGE This is an overload. Before turn on the power, make sure that there is nothing on the platter. Remove the commodity from the platter. TOTAL OFL If the number of counts is more than 99 times or the added total price is bigger than 99999999, then you will see the error message as below.

  • Page 30: Specifications

    SPECIFICATIONS TP-6 TP-15 TP-30 MODEL 15kg 30kg CAPACITY (0.001 3.000kg) (0.002 6.000kg) (0.001 3.000kg) READABILITY (3.002 6.000kg) (6.005 15.000kg) (3.002 6.000kg) (6.005 15.000kg) (15.01 30.00kg) WEIGHT : 5 DIGIT UNIT PRICE : 7 DIGIT DISPLAYS TOTAL PRICE : 8 DIGIT...
