DVC6200p Digital Valve Controller
November 2014
7. Right click on the device in the right pane and select Open Object, as shown in figure 16.
Figure 16. Open Device in SIMATIC PDM
8. In the resulting Offline menu screen (shown in figure 17), select the Upload icon, as indicated below, to upload the
device to the database. Click Start. The upload is complete when the tag name appears. Close the Upload PG/PC
dialog screen.
Note
The device must be uploaded to the database using the Upload icon only; do not upload from the drop down menu.
Figure 17. Upload Device to Database
UPLOAD
The project is now setup, and you are able to communicate with the DVC6200p. Proceed to Going Online with the
DVC6200p on the next page.
16
OFFLINE
START UPLOAD
Instruction Manual Supplement
TAG NAME
UPLOAD COMPLETE
D103560X012
