About This Guide
Begin by exploring the controls and display of the
TBS2000 Series. Then move on to a series of hands-on
exercises. Acquire waveforms, learn about triggering,
take measurements, and learn how to save data. Get an
introduction to the TBS2000's connectivity and remote
control capabilities, and tools for education.
28 JULY 2016

Required Equipment

◦ TBS2000 Series Oscilloscope
◦ Power Cord for your region (included with
instrument)
◦ Two TPP0100 passive probes with hook tips
attached (included with instrument)
◦ A USB flash drive (to demonstrate screen image
capture)
◦ TEKUSBWIFI USB Wi-Fi dongle (to demonstrate
wireless communications)
◦ PC with Ethernet connection (to demonstrate LXI)
◦ Ethernet cable (to demonstrate LXI)
