Effect Types and Parameters
Ensemble
This is a chorus ensemble with three-dimensional movement.
PARM1 PARM2
Depth Rate
0 – 100 1 – 50
Adjusts the effect depth. Adjusts the modulation rate.
ModDelay
This is a delay that allows use of modulation.
PARM1 PARM2
1 –
Time
2000 FeedBack 0 – 100
mS
Adjusts the amount of
feedback. Higher setting values
Sets the delay time.
result in a higher number of
delay sound repetitions.
Flanger
This effect produces a resonating and strongly undulating sound.
PARM1 PARM2
Depth 0 – 100 Rate
0 – 50
Adjusts the effect depth. Adjusts the modulation rate.
PitchShift
This effect shifts the pitch up or down.
PARM1 PARM2
-12 – -1, 0,
Shift Tone
0 – 10
1 – 12, 24
Sets the pitch shift amount in Adjusts the tonal quality of the
semitones. sound.
PedalPitch
This effect allows using a pedal to shift the pitch in real time.
PARM1 PARM2
Color Mode Up, Down Tone
1 – 8
Selects the type of pitch
Sets the direction of the pitch
change caused by the pedal
change to Up or Down.
(see Table 1).
[Table 1]
Color Mode Pedal minimum value Pedal maximum value
Up -100 cent Original sound only
1
Down Original sound only -100 cent
Up DOUBLING Detune + DRY
2
Down Detune + DRY DOUBLING
Up
0 cent +1 octave
3
Down
+1 octave 0 cent
Up
0 cent -2 octaves
4
Down -2 octaves 0 cent
68
PARM3 PARM4
Tone
0 – 10 Mix 0 – 100
Adjusts the level of the effect
Adjusts the tonal quality of the
sound mixed to the original
sound.
sound.
PARM3 PARM4
Rate 1 – 50 Mix 0 – 100
Adjusts the level of the effect
Adjusts the modulation rate. sound mixed to the original
sound.
PARM3 PARM4
Resonance -10 – -1, 0,
Manual 0 – 100
1 – 10
Adjusts the resonance Adjusts the frequency range
intensity. on which the effect operates.
PARM3 PARM4
Fine
-25 – 25 Balance 0 – 100
Allows fine adjustment of Adjusts the balance between
pitch shift amount in Cent (1/ original sound and effect
100 semitone) steps. sound.
PARM3 PARM4
PdlPosi
0 – 10 0 – 100
Sets the pitch shift amount.
Depending on the "Color"
Adjusts the tonal quality of the setting, the balance between
sound. original sound and effect
sound also changes
accordingly.
Color Mode Pedal minimum value Pedal maximum value
Up -1 octave + DRY +1 octave + DRY
5
Down +1 octave + DRY -1 octave + DRY
Up -700 cent + DRY +500 cent + DRY
6
Down +500 cent + DRY -700 cent + DRY
Up
-∞ (0 Hz) + DRY +1 octave
7
Down
+1 octave -∞ (0 Hz) + DRY
Up
-∞ (0 Hz) + DRY +1 octave + DRY
8
Down +1 octave + DRY -∞ (0 Hz) + DRY
ZOOM G9.2tt
Vibe
This is an effect with automatic vibrato.
PARM1 PARM2
Depth Rate
0 – 100 0 – 50
Adjusts the effect depth. Adjusts the modulation rate.
Step
Special effect that changes the sound in a staircase pattern.
PARM1 PARM2
Depth 0 – 100 Rate
0 – 50
Adjusts the modulation depth. Adjusts the modulation rate.
Delay
This is a delay with a maximum setting of 2000 ms.
See TapeEcho (next effect) for effect parameters.
TapeEcho
This effect simulates a tape echo.
PARM1 PARM2
1 –
Time
FeedBack
2000 0 – 100
mS
Adjusts the amount of feedback.
Higher setting values result in a
Sets the delay time.
higher number of delay sound
repetitions.
DynamicDelay
This is a dynamic delay where the effect volume varies according to the input signal level.
PARM1 PARM2
1 –
Time
Amount
2000 0 – 100
mS
Adjusts the level of the effect
Sets the delay time. sound mixed to the original
sound.
ZOOM G9.2tt
Effect Types and Parameters
PARM3 PARM4
Tone
Balance
0 – 10 0 – 100
Adjusts the balance between
Adjusts the tonal quality of the
original sound and effect
sound.
sound.
PARM3 PARM4
Resonance 0 – 10 Shape 0 – 10
Adjusts the resonance Adjusts the effect sound
intensity. envelope.
PARM3 PARM4
HiDamp
Mix
0 – 10 0 – 100
Adjusts the treble attenuation
Adjusts the level of the effect
of the delay sound. Lower
sound mixed to the original
setting values result in softer
sound.
delay sound.
PARM3 PARM4
-10 – -1,
FeedBack Sense
0 – 100
1 – 10
Adjusts the effect sensitivity.
With positive setting values, the
effect sound level increases at
Adjusts the amount of
higher input signal levels. With
feedback.
negative setting values, the
effect sound level decreases at
higher input signal levels.
