Zoom G2 FOUR Manual

Effects & amp emulator
Hide thumbs Also See for G2 FOUR:

Advertisement

Quick Links

Download this manual
Effect Types and Parameters
This document cannot be displayed properly on black-and-white displays.
© 2022 ZOOM CORPORATION
Manufacturer names and product names are trademarks or registered trademarks of their respective owners. The names are used only to illustrate sonic
characteristics and do not indicate any affiliation with the Zoom Corporation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the G2 FOUR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zoom G2 FOUR

Summary of Contents for Zoom G2 FOUR

  • Page 1 This document cannot be displayed properly on black-and-white displays. © 2022 ZOOM CORPORATION Manufacturer names and product names are trademarks or registered trademarks of their respective owners. The names are used only to illustrate sonic characteristics and do not indicate any affiliation with the Zoom Corporation.
  • Page 2 Effect explanation overview Tempo synchronization possible icon Effect type Effect explanation Parameter range DELAY This long delay has a maximum length of 4000 ms. TIME Sets the delay time. 1 – 4000 SHORT, Sets the delay time range. LONG, MODE When metronome is chosen, the delay time is synchronized to the tempo.
  • Page 3 This is a limiter that suppresses signal peaks above a certain reference level. 10 – 70 Adjusts the output level. 0 – 80 OUTPUT ZOOM NOISE ZOOM's unique noise reduction cuts noise during pauses in playing without affecting the REDUCTION tone. GTRIN, DETCT Sets control signal detection level.
  • Page 4 Effect Types and Parameters [ DYNAMICS ] SLOW This effect slows the attack of each note, resulting in a violin-like performance. ATTACK TIME Adjusts the attack time. 1 – 50 CURVE Set the curve of volume change during attack. 0 – 10 TONE Adjusts the tone.
  • Page 5 Effect Types and Parameters [ DRIVE ] EP DRIVE This models the Maestro Echoplex preamp. GAIN Adjusts the gain. 0 – 100 BASS Adjusts volume of low frequencies. -10 – 10 TREBLE Adjusts volume of high frequencies. -10 – 10 Adjusts the volume.
  • Page 6 Effect Types and Parameters [ DRIVE ] DISTORTION This models the sound of a BOSS DS-1 DISTORTION. GAIN Adjusts the gain. 0 – 100 TONE Adjusts the tone. 0 – 100 Adjusts the volume. 0 – 100 ORIGINAL, COMP Sets the clipping type of DIST 1. MODIFY SQUEAK This models a ProCo RAT.
  • Page 7 Effect Types and Parameters [ DRIVE ] WAVE This effect is another new kind of distortion effect that applies a new original algorithm to SHAPER shape the waveform and create a unique sound. DRIVE GAIN Adjusts the gain. 0 – 100 SHAPE Adjusts the distortion character.
  • Page 8 Effect Types and Parameters [ MODULATION ] CLONE This analog chorus sound models the Electro-Harmonix SmallClone. CHORUS DEPTH Sets the depth of the modulation. 1, 2 RATE Sets the speed of the modulation. 0 – 100 TONE Adjusts the tone. 0 –...
  • Page 9 Effect Types and Parameters [ MODULATION ] STONE This phaser sound models the Electro-Harmonix SmallStone. PHASER COLOR Sets the sound color. 1, 2 DEPTH Sets the depth of the modulation. 0 – 100 RATE Sets the speed of the modulation. 0 –...

  • Page 10: Ring Modulator

    Effect Types and Parameters [ MODULATION ] POLYPHONIC PITCH This pitch shifter supports chord playing. SHIFTER SHIFT Adjusts the pitch shift amount in semitones. -24 – 24 TONE Adjusts the tone. 0 – 100 Adjust the amount of the effect sound in the mix. 0 –...
  • Page 11 Effect Types and Parameters [ DELAY ] DELAY This long delay has a maximum length of 4000 ms. TIME Sets the delay time. 1 – 4000 SHORT, Sets the delay time range. LONG, MODE When metronome is chosen, the delay time is synchronized to the tempo. REPEAT Adjusts the feedback amount.
  • Page 12 Effect Types and Parameters [ DELAY ] SOFT ECHO This echo has a soft tone.This echo effect allows the use of modulation. Turns modulation ON or OFF. OFF, ON TIME Sets the delay time. 19 – 581 REPEAT Adjusts the feedback amount. 0 –...
  • Page 13 Effect Types and Parameters [ REVERB ] ROOM This reverb effect simulates the acoustics of a room. REVERB PRE DLY Adjusts the delay between input of the original sound and start of the reverb sound. 1 – 100 DECAY Sets the duration of the reverberations. 1 –...
  • Page 14 Effect Types and Parameters [ REVERB ] AIR REVERB This effect reproduces the ambience of a room, to create spatial depth. SIZE Sets the size of the space. 1 – 100 REFLECT Adjusts the amount of reflection from the wall. 0 –...
  • Page 15 Effect Types and Parameters [ AMP ] MS 45os This models the sound of the Marshall JTM 45 Offset. BASS Adjusts volume of low frequencies. 0 – 100 Adjusts volume of middle frequencies. 0 – 100 TREBLE Adjusts volume of high frequencies. 0 –...
  • Page 16 Effect Types and Parameters [ AMP ] FD DELUXE-R This models the sound of the Fender '65 Deluxe Reverb. NORMAL, INPUT Selects the input channel. VIBRATO BASS Adjusts volume of low frequencies. 10 – 100 TREBLE Adjusts volume of high frequencies. 10 –...
  • Page 17 Effect Types and Parameters [ AMP ] RECTI DUAL This models the sound of the Mesa Boogie Dual Rectifier Orange Channel. MODE Sets the tone of the character. VNTG, MDRN BASS Adjusts volume of low frequencies. 0 – 100 Adjusts volume of middle frequencies. 0 –...
  • Page 18 Effect Types and Parameters [ AMP ] MATCH30 This models the sound of the Matchless DC-30. GAIN1 Adjusts the gain of channel1. OFF, 0 – 100 BASS1 Adjusts volume of low frequencies in the channel1. 0 – 100 TRBL1 Adjusts volume of high frequencies in the channel1. 0 –...
  • Page 19 Effect Types and Parameters [ AMP ] Emphases on the sound for 7 and 8 string guitars by blending the dynamic response with a 7 HEAVEN very tight low end. Expect a very powerful metal sound. BASS Adjusts volume of low frequencies. 0 –...
  • Page 20 Effect Types and Parameters [ PEDAL ] OUTPUT This controls the product output level. This volume will be kept even when the patch VOLUME memory is changed. PEDAL PEDAL The volume curve of the volume pedal can be set. VOLUME Adjusts the volume.
  • Page 21 - 2 octave DOWN 0 cent -∞ -/+ OCT - 1 octave +original +1 octave +original -5/+4TH - 700 cent +original +500 cent +original DETUNE Doubling Detuned +original DWN/OCT -∞ (0 Hz) +original +1 octave +original ©2022 ZOOM CORPORATION Z2I-4814-01...

This manual is also suitable for:

G2x four
