Using The Expression Pedals; About The Expression Pedals - Zoom Guitar Effects Console G9.2tt2q Operation Manual

Storing Patches and Banks (Store Mode)
1.
Turn power to the G9.2tt on while
holding down the [STORE/SWAP] key.
The indication "All Initialize?" appears on the
display.
All Initialize? All Initialize?
Y:STORE N:EXIT Y:STORE N:EXIT
2.
Press the [STORE/SWAP] key once
more.
All patches are returned to the factory default
condition, and the G9.2tt switches to play mode.
By pressing the [EXIT] key before performing
step 2, you can cancel the process.
30
This section explains how to use the two built-in expression pedals of the G9.2tt.
About the expression
pedals
The G9.2tt comes standard with two expression
pedals that can be used to control specific effect
parameters in real time.
Expression pedal 1 on the left side has four
control targets (P1-1 to P1-4), and a parameter
can be assigned for each control target. This
makes it possible to adjust up to four parameters
of different modules simultaneously. A setting
example is shown below, to give you an idea of
how the pedal can be used.
Expression
pedal-1
Expression pedal 2 on the right side the Z-Pedal
that senses not only vertical but also horizontal
movement. It has four control targets in the
vertical direction (P2V1 to P2V4) and four
control targets in the horizontal direction (P2H1
to P2H4). A parameter can be assigned for each
control target.
With a setting such as shown in the example at
right, the pedal adjusts the Gain parameter of the
ZOOM G9.2tt ZOOM G9.2tt

Using the Expression Pedals

PRE-AMP module when moved in the vertical
direction and the Rate parameter of the MOD/
EFX2 module when moved in the horizontal
direction. It is also possible to control both at the
same time with one pedal.
Expression
Control target parameters
● P1-1
PRE-AMP module
Gain
● P1-2
MOD/EFX2 module
HINT
Rate
• The parameter adjustment range covered by
● P1-3
expression pedals 1 and 2 can be set for each
DELAY module
control target separately.
• In bypass mode, both expression pedals
Feed Back
function as a volume pedal when moved in the
● P1-4
vertical direction. (Moving expression pedal 2 in
REVERB module
the horizontal direction has no effect.)
Mix • In mute mode, both expression pedals have no
effect.
NOTE
Expression pedal 2 of the G9.2tt is designed for
operation with one foot. When the pedal is fully
turned to the right, pushing it strongly down, hitting
it, or otherwise exerting strong force on it will
damage the pedal. Be sure to operate the pedal
only within its designated range.
pedal 2
Control target parameters
● P2V1
PRE-AMP module
Gain
● P2H1
MOD/EFX2 module
Rate
31
