Eq Module; Cabinet Module; Mod/Efx2 Module - Zoom Guitar Effects Console G9.2tt2q Operation Manual

Effect Types and Parameters
Guv'nor
Simulation of the Guv'nor distortion effect from Marshall.
DS-1
Simulation of the Boss distortion DS-1, a long-time
favorite.
HotBox
Simulation of the compact Matchless HotBox preamp
with built-in tubes.
BigMuff
Simulation of the Electro-Harmonix BigMuff preferred by
famous artists for its fat, sweet fuzz sound.
TS+F_Cmb
Combination of Fender combo amp and Ibanez TS-9
sound.
FZ+M_Stk
Combination of Fuzz Face and Marshall stack amp sound. Zoom original overdrive with natural distortion.
ExtremeDS
High gain sound with the most powerful gain of any
distortion effect in the world.
Z Clean
Zoom original straight clean sound.
The above 43 effect types have the same parameters.
GAIN LEVEL
Gain 0 – 100 Level 1 – 100
Adjusts the preamp gain Adjusts the signal level after
(distortion depth). passing the module.
PARM1 PARM2
Tone Chain
0 – 30 Pre, Post
Selects the connection
position of the pre-amp
Adjusts the tonal quality of the section. Available settings are
sound. "Pre" (before MOD/EFX2
module) or "Post" (after
DELAY module).
Aco. Sim
This effect makes an electric guitar sound like an
acoustic guitar.
GAIN LEVEL
Top Level
0 – 10 1 – 100
Adjusts the characteristic
Adjusts the signal level after
strings sound of an acoustic
passing the module.
guitar.
PARM1 PARM2
Body Chain
0 – 10 Pre, Post
Selects the connection
position of the pre-amp
Adjusts the characteristic body section. Available settings are
sound of an acoustic guitar. "Pre" (before MOD/EFX2
module) or "Post" (after
DELAY module).
66
RAT
Simulation of the PROCO Rat famous for its edgy
distortion sound.
dist +
Simulation of MXR distortion+ that made distortion
popular worldwide.
FuzzFace
Simulation of the Fuzz Face that made rock history with
its zany look and smashing sound.
MetalZone
Simulation of the Boss METALZONE with long sustain
and dynamic lower midrange.
SD+M_Stk
Combination of Marshall stack amp and Boss SD-1
sound.
Z OD
DigiFuzz
High gain fuzz sound with strong character.
ZOOM G9.2tt

EQ module

This is a 6-band equalizer. In edit mode, the module is adjusted using the [BASS], [MIDDLE],
[TREBLE], and [PRESENCE] knobs of the pre-amp section and the parameter knobs 3 and 4.
BASS MIDDLE
±12
Bass Middle
160Hz 800Hz
Adjusts boost/cut in the low Adjusts boost/cut in the
frequency range. middle frequency range.

CABINET module

This effect simulates the sound obtained when recording an amp cabinet with a
microphone. The simulated mic type and position can be selected. The on/off status of this
module controls the automatic algorithm selection in the PRE-AMP module (→ p. 65).
PARM1 PARM2
Dyna,
MicType MicPosi
0 – 2
Cond
Lets you select different
characteristics according to the
mic position. The following
Selects the microphone type.
settings are available.
"Dyna" simulates the
0: Mic pointed at speaker
frequency response of a
center
dynamic mic and "Cond" that
1: Mic pointed halfway
of a condenser mic.
between speaker edge and
center
2: Mic pointed at speaker edge

MOD/EFX2 module

This module comprises modulation effects such as chorus and flanger, delay effects, and
pitch shifter effects.
Chorus
This effect mixes a variable pitch-shifted component to the original signal, resulting in full-bodied resonating sound.
PARM1 PARM2
Depth
0 – 100 Rate 1 – 50
Adjusts the effect depth. Adjusts the modulation rate.
ST-Chorus
This is a clear sounding stereo chorus.
PARM1 PARM2
Depth Rate
0 – 100 1 – 50
Adjusts the effect depth. Adjusts the modulation rate.
ZOOM G9.2tt
Effect Types and Parameters
TREBLE PRESENCE
±12 ±12
Treble Presence
3.2kHz
Adjusts boost/cut in the high Adjusts boost/cut in the very
frequency range. high frequency range.
PARM3 PARM4
±12
Low-Mid Harmonics
400Hz
Adjusts boost/cut in the lower- Adjusts boost/cut in the
middle frequency range. harmonics frequency range.
PARM3
Depth
0 – 2
Adjusts the effect depth.
Effect Depth 0 also includes
some Cabinet sound.
PARM3 PARM4
Tone
0 – 10 Mix
Adjusts the level of the effect
Adjusts the tonal quality of the
sound mixed to the original
sound.
sound.
PARM3 PARM4
Tone
Mix
0 – 10
Adjusts the level of the effect
Adjusts the tonal quality of the
sound mixed to the original
sound.
sound.
±12
6.4kHz
±12
12kHz
0 – 100
0 – 100
67
