USB-1208HS-4AO User's Guide
Note 2: Output voltage range assumes input power is within specified limits.

USB specifications

USB device type
USB device compatibility
USB cable length
USB cable type
Environmental
Operating temperature range
Storage temperature range
Humidity
Mechanical
Dimensions
Main connector and pin out
Connector type
Wire gauge range
Table 13. USB specifications
USB 2.0 (high-speed)
USB 1.1, 2.0
5 meters maximum.
A-B cable, UL type AWM 2527 or equivalent (minimum 24 AWG VBUS/GND,
minimum 28 AWG D+/D-).
Table 14. Environmental specifications
0 to 50 °C
-40 to 85 °C
0 to 90% non-condensing
Table 15. Mechanical specifications
127 mm (L) x 88.9 mm (W) x 35.56 (H))
Table 16. Main connector specifications
Screw terminal
16 AWG to 30 AWG
24
Specifications
