- Page 2 Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S . D.T.S.
- Page 3 1- SYMBOLS Graphic symbols used on this manual: THIS SYMBOL INDICATES A HOT SURFACE THIS SYMBOL INDICATES ELECTRIC SHOCK RISK THIS SYMBOL INDICATES GENERAL RISK THIS SYMBOL INDICATES THE MAXIMUM OPERATING AMBIENT TEMPERATURE THIS SYMBOL MEANS “SUITABLE FOR MOUNTING ON NORMALLY FLAMMABLE SURFACES”...
- Page 4 3- GENERAL WARRANTY CONDITIONS The unit is guaranteed for 36 months from the date of purchase against manufacturing material defects. 4- TECHNICAL FEATURES DTS product codes: 03.LTB001H11FC10 TITAN HEAD HP FC Narrow lenses Black finishing 03.LTB001H11FC25 TITAN HEAD HP FC Medium flood lenses Black finishing 03.LTB001H11FC40...
- Page 5 DIMENSIONS 5- ACCESSORIES As standard 1 x M12 female cable connector (code 0508P050) 1 x User’s Manual Optional (on request) - Barndoor black finishing (code 03.LA.056.V1) - Aliscaf clamp for tube diameter 50 mm (Max load 100 Kg) (code 0521A008) (indicated for any kind of loads vertical / horizontal) - “C”...
- Page 6 6- IMPORTANT SAFETY INFORMATION 6.1 Fire prevention: -It is permissible to place the unit on normally flammable surfaces. Suitable for mounting on normally flammable materials surfaces greater than 200°C with some combustion time lag. -Minimum distance from the closest illuminable surface: 0,5 m. 6.2 Prevention of electric shock: -Class II LED product according to standard EN 60598-1.
- Page 7 7- INSTALLATION The unit is suitable for wet locations. For ceiling mounted installation, it is recommended the use of appropriate clamps to fix the unit to the mounting surface. The supporting structure from which the unit is hung should be capable of bearing the weight of the unit, as should any clamps used to hung it.
- Page 8 8- CONNECTIONS...
- Page 9 9- WIRING DIAGRAMS The maximum number of TITAN HEAD HP FC connectable to each output of the DRIVENET 832 PSU is 1 piece. NEVER CONNECT OR DISCONNECT THE UNIT WHEN THE PSU IS TURNED ON. The maximum distance between the DRIVENET 832 PSU and the unit should not exceed 100 meters.
- Page 10 NOTES...
- Page 11 NOTES...
- Page 12 *0517I315* ● D.T.S. Illuminazione s.r.l. Via Fagnano Selve 12-14 47843 Misano Adriatico (RN) Italy ● Tel.: +39 0541 611131 Fax +39 0541 611111 ● info@dts-lighting.it www.dts-lighting.it 0517I315...
