Acrosser Technology AR-B1893 User Manual

Celeron m inside, on board vga, with so dimm, 4 port built in lan, 1 mini pci, 1 cf
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AR-B1893 User's Guide
AR-B1893A
Celeron M inside, On Board VGA,
with SO DIMM, 4 Port built in LAN, 1 Mini PCI, 1 CF
Edition: 1.1
Book Number: AR-B1893A-06.02.07
AR-B1893A Celeron M inside
1
with DDR SO DIMM, 4 Port built in LAN, 1 Mini PCI, 1 CF

Advertisement

Table of Contents
loading

Related Manuals for Acrosser Technology AR-B1893

Summary of Contents for Acrosser Technology AR-B1893

  • Page 1 AR-B1893 User’s Guide AR-B1893A Celeron M inside, On Board VGA, with SO DIMM, 4 Port built in LAN, 1 Mini PCI, 1 CF Edition: 1.1 Book Number: AR-B1893A-06.02.07 AR-B1893A Celeron M inside with DDR SO DIMM, 4 Port built in LAN, 1 Mini PCI, 1 CF...
  • Page 2 AR-B1893 User’s Guide @Copyright 2005 All Rights Reserved. Manual first edition July 8, 2005 The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.

  • Page 3: Table Of Contents

    AR-B1893 User’s Guide Contents Contents..............3 Introduction ............5 1.1 Specifications: ................5 1.2 What You Have................. 6 Installation .............. 7 2.1 AR-B1893A’s Layout ..............7 2.2 Power Button Setting ..............9 2.3 CMOS Reset ................9 2.4 Jumper description..............9 Connection ............
  • Page 4 AR-B1893 User’s Guide 3.9 Mini PCI Slot ................18 3.10 DDR SODIMM Socket ............18 3.11 GPIO ..................19 3.12 Internal Buzzer ..............19 3.13 Power / HD / Watchdog LED ..........19 3.14 Reset Button ................. 19 Award BIOS Setup ..........20 4.1 Introduction ................

  • Page 5: Introduction

    AR-B1893 User’s Guide Introduction 1.1 Specifications: • CPU : Celeron M • Chipset : GMCH 852GM and ICH4 82810DB • RAM memory : DDR SDRAM SO-DIMM Socket up to 1 GB/266MHz. • Ultra DMA 133 IDE Interface : Two PCI Enhance IDE channel.

  • Page 6: What You Have

    AR-B1893 User’s Guide 1.2 What You Have In addition to this User's Manual, the AR-B1893A package includes the following items: • AR-B1893A board • One IDE Cable • VGA cable • Keyboard / Mouse Adapter Y Cable • One RS-232 serial ports Cable with bracket •...

  • Page 7: Installation

    AR-B1893 User’s Guide Installation This chapter describes how to install the AR-B1893A. At first, the layout of AR-B1893A is shown, and the unpacking information that you should be careful is described. The jumpers and switches setting for the AR-B1893A’s configuration 2.1 AR-B1893A’s Layout...
  • Page 8 AR-B1893 User’s Guide Bottom Placement AR-B11893 Pentium M inside (With VGA) with On Board DDR, 4 Port built in LAN, 1 Mini PCI, 1 CF...

  • Page 9: Power Button Setting

    AR-B1893 User’s Guide 2.2 Power Button Setting • • • • DCIN1 : Power JACK Place power button cable on CN3 pin 1-2 & use Mechanical Power Button. • CN3 : Power Button Connector DESCRIPTION 1 – 2 Power Button 12 V Button LED 2.3 CMOS Reset...
  • Page 10 AR-B1893 User’s Guide • JP1 : CPU Power start setting Description open Normal start CPU Power (default) close Soft start CPU Power • • • • JRS2 : COM2 for RS-232 / RS-422 / RS-485 JRS2 Description JRS2 1 - 2...

  • Page 11: Connection

    AR-B1893 User’s Guide Connection This chapter describes how to connect peripherals, switches and indicators to the AR-B1893A board. Ultra ATA33/66/100 IDE Disk Drive Connector You can attach two IDE( Integrated Device Electronics) hard disk drives to the AR-B1893A IDE controller.

  • Page 12: Serial Ports

    AR-B1893 User’s Guide IDE 2 : Secondary IDE Connector (44 Pins) PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2...
  • Page 13 AR-B1893 User’s Guide • COM1 : DB-9 Male PIN NO. DESCRIPTION DATA CARRIER DETECT (DCD) RECEIVE DATA (RXD) TRANSMIT DATA (TXD) DATA TERMINAL READY (DTR) GROUND DATA SET READY (DSR) REQUEST TO SEND (RTS) CLEAR TO SEND (CTS) RING INDICATOR (RI) •...

  • Page 14: Keyboard / Mouse Connector

    AR-B1893 User’s Guide 3.3 Keyboard / Mouse Connector The AR-B1893A provides PS/2 Mouse & Keyboard Connector. • PS1 : 6-pin Mini-DIN Keyboard/Mouse Connector PIN NO. DESCRIPTION MOUSE DATA KEYBOARD DATA GROUND MOUSE CLOCK KEYBOARD CLOCK 3.4 USB Port Connector The AR-B1893A provides four USB port, port 0, port 1, port 3 and port 4 .

  • Page 15: Fan Connector

    AR-B1893 User’s Guide 3.5 Fan Connector The AR-B1893A provides 3 connectors for CPU cooling fan & system fan & they can be controlled by Super I/O Chip. • CPUF1, CPUF2 & CPUF3: Fan Connector for CPU & System PIN NO.

  • Page 16: Compact Flash Storage Card Socket

    AR-B1893 User’s Guide • LED1, LED2 LED3 and LED4 : LAN LED COLOR DESCRIPTION 100MBps Green 1000MBps Yellow Action DESCRIPTION For LAN 1 For LAN 2 For LAN 3 For LAN 4 • VGA1 : 10-pin Connector PIN NO. DESCRIPTION...
  • Page 17 AR-B1893 User’s Guide • CFD1 : Compact Flash Storage Card Socket pin assignment PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND CARD DETECT1 CS1# CS3# GROUND IOR# IOW# PULL HIGH IRQ15 MASTER/SLAVE RESET# IORDY PULL HIGH ACTIVE# PDIAG# CARD DETECT2 GROUND Note: If IDE2 &...

  • Page 18: Pci Slot

    AR-B1893 User’s Guide 3.8 PCI Slot • PCI1 3.9 Mini PCI Slot • • • • MPCI1 3.10 DDR SODIMM Socket • • • • SODIMM1 AR-B11893 Pentium M inside (With VGA) with On Board DDR, 4 Port built in LAN, 1 Mini PCI, 1 CF...

  • Page 19: Gpio

    AR-B1893 User’s Guide 3.11 GPIO • PIN NO. DESCRIPTION PIN NO. DESCRIPTION GPIO1 GPIO7 GPIO5 GPIO4 GPIO2 GPIO8 GPIO6 GROUND GPIO3 3.12 Internal Buzzer • 3.13 Power / HD / Watchdog LED • LED5 COLOR DESCRIPTION Hard Disk Active Green...

  • Page 20: Award Bios Setup

    AR-B1893 User’s Guide Award BIOS Setup 4.1 Introduction This chapter discusses the Setup program built into the BIOS. The Setup program allows users to configure the system. This configuration is then stored in battery-backed CMOS RAM so that it retains the Setup information while the power is off.

  • Page 21: Using Setup

    AR-B1893 User’s Guide 4.3 Using Setup In general, you can use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more details about how to navigate in the Setup program using the keyboard.

  • Page 22: Main Menu

    AR-B1893 User’s Guide 4.4 Main Menu The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn>...
  • Page 23 AR-B1893 User’s Guide Options are in its sub Press <Enter> to enter Primary Slave menu the sub menu of detailed (described in Table 3) options Options are in its sub Press <Enter> to enter Secondary Master menu the sub menu of detailed...
  • Page 24 AR-B1893 User’s Guide IDE HDD Auto-Detection [Press Enter] IDE Primary Master [Auto] Access Mode [Auto] Capacity 0MB Cylinder 0 Head 0 Precomp 0 Landing Zone 0 Sector 0 Figure 2 IDE Primary Master sub menu Use the legend keys to navigate through this menu and exit to the main menu.

  • Page 25: Advanced Bios Features

    AR-B1893 User’s Guide disk checking program. Access Mode Choose the access mode for this hard disk Large Auto Table 2 Hard disk selections 4.5 Advanced BIOS Features This section allows you to configure your system for basic operation. Quick Power On Self Test [Enabled]...
  • Page 26 AR-B1893 User’s Guide Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power up the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST. Enabled...
  • Page 27 AR-B1893 User’s Guide The Choice: PCI Slot, On Board / AGP. Boot Display This item allows you to choose display interface The Choice: Vbios default, CRT, EFP, TV, CRT + EFP, CRT + TV. On-Chip Frame Buffer Size This item allows you to Choose the Frame Buffer size for Display.

  • Page 28: Pnp/Pci Configuration Setup

    AR-B1893 User’s Guide 4.6 PnP/PCI Configuration Setup Reset Configuration Data [Disabled] Resources Controlled By [Auto(ESCD)] x IRQ Resources Figure 4 PnP/PCI menu Resource controlled by The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as Windows®95.

  • Page 29: Peripheral

    AR-B1893 User’s Guide 4.7 Peripheral Onboard Serial Port 1 [3F8/IRQ4] Onboard Serial Port 2 [2F8/IRQ3] UART Mode Select [Normal] On Board Parallel Port [3BC/IRQ7] Parallel Port Mode USB Controller [Enabled] USB 2.0 Controller [Enable] Figure 5 Peripheral menu Onboard Serial Port 1/Port 2 Select an address and corresponding interrupt for the first and second serial ports.

  • Page 30: Pc Health

    AR-B1893 User’s Guide USB Controller Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have USB peripherals. The Choice: Enabled, Disabled. USB 2.0 Controller This Entry is for disable / enable EHCI controller only. The Bios itself may / may not have high speed USB support.

  • Page 31: Boot

    AR-B1893 User’s Guide CPU Warning Temp This item allows you to enable or disable the agent after boot. The Choice: Enabled, Disabled. Shutdown Temperature This item allows the system to reset when temperature reach the trigger level. The Choice: Disabled, 60 – C/140 – F, 65 – C/149 – F, 70 – C/158 – F, 75 – C/167 –...

  • Page 32: Exit Selecting

    AR-B1893 User’s Guide ZIP100 ………. [ ] USB-FDD .. …...[ ] USB-ZIP .. …...[ ] USB-CDROM .. [ ] On Board LAN …[ ] Disabled ….. ……[ ] On Board LAN Boot Select Select through which LAN Channel should the system boot.
  • Page 33 AR-B1893 User’s Guide Use this menu to load the BIOS default values that are factory settings for optimal performance system operations. While Award has designed the custom BIOS to maximize performance, the factory has the right to change these defaults to meet their needs.

  • Page 34: Watchdog Timer

    AR-B1893 User’s Guide Watchdog Timer The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMI or a software bug. When the CPU stops working correctly, hardware on the board will either perform a hardware reset (cold boot) or a Non-Maskable Interrupt (NMI) to bring the system back to a known state.
  • Page 35 AR-B1893 User’s Guide 5.1 Watch Dog Test program source codes : gotoxy(x,y); /* Watchdog test program for AR-M9942 */ printf(" "); //clear the line :) gotoxy(x,y); #include <stdio.h> printf(" %ld\tseconds",waiting_sec); #include <string.h> waiting_sec = waiting_sec - 1; #include <stdlib.h> delay(1000);...
  • Page 36 AR-B1893 User’s Guide outportb(config_data,0x00); outportb(config_port,0x07); //Choose LD8 void close_superio() - Watchdog outportb(config_data,0x08); outportb(config_port,0xAA); outportb(config_port,0x30); //Activate void print_help_message() outportb(config_data,0x01); printf(" AR-M9942 Watchdog Test if(time_unit ==1) program\n"); tmp=0x08; printf("Usage: wdog [-h] else [<number>s|m]\n"); tmp=0x00; printf("Example:\n"); printf("\twdog -h\t\t: printf this help outportb(config_port,0xF5); //Choose message\n");...

  • Page 37: Gpio

    AR-B1893 User’s Guide GPIO AR-M9942 GPIO are controlled by Register F1h and F0h of Super I/O IC (W83627HF). For details please refer the datasheet of W83627HF. GPIO can be only set as all inputs or all outputs. To test GPIO of AR-M9942, we have developed Test program “9936_GPIO.EXE”...
  • Page 38 AR-B1893 User’s Guide AR-B11893 Pentium M inside (With VGA) with On Board DDR, 4 Port built in LAN, 1 Mini PCI, 1 CF...
  • Page 39 AR-B1893A User’s Guide 6.1 GPIO Test program source codes : Watchdog test program for AR-M9942 */ printf(" "); //clear the line :) gotoxy(x,y); #include <stdio.h> printf(" %ld\tseconds",waiting_sec); #include <string.h> waiting_sec = waiting_sec - 1; #include <stdlib.h> delay(1000); #include <conio.h> #include <dos.h> printf("Error!! Watchdog not function!\n");...
  • Page 40 AR-B1893A User’s Guide LD8 - Watchdog outportb(config_data,0x08); outportb(config_port,0x30); //Activate outportb(config_data,0x01); if(time_unit ==1) tmp=0x08; else tmp=0x00; outportb(config_port,0xF5); //Choose watchdog time unit outportb(config_data,tmp); outportb(config_port,0xF6); //Set watchdog time-out outportb(config_data,time_out); void close_superio() outportb(config_port,0xAA); void print_help_message() printf("AR-M9942 Watchdog Test program\n"); printf("Usage: wdog [-h] [<number>s|m]\n"); printf("Example:\n"); printf("\twdog -h\t\t: printf this help message\n");...
