AR-B1666A MANUAL
Version 1.0
1. SETTING UP THE SYSTEM
TOP PLACEMENT
BOTTOM PLACEMENT
Page 1 of 3
1.1 PACKING LIST
n
The quick setup manual
n
1 AR-B1666A CPU board
n
1 Software utility CD
n
1 Mini Din power adapter
1.2 KEYBOARD & MOUSE CONNECTOR (KB1)
Pin #
1
1
2
3
4
5
6
KB
6
1.3 SDRAM SOCKET 144 PIN (DIMM1)
11144
144 pin SO-DIMM
1.4 HARD DISK (IDE) CONNECTOR (IDE1)
※ 44 Pin Hard Disk Connector (IDE1)
2
1
Pin
Signal Name
MOUSE DATA
KB DATA
GND
VCC
MOUSE CLOCK
KB CLOCK
Signal Pin
1 -RESET 2
3 DATA 7 4
5 DATA 6 6
7 DATA 5 8
9 DATA 4 10
11 DATA 3 12
13 DATA 2 14
15 DATA 1 16
17 DATA 0 18
19 GROUND 20
21 IDEDREQ 22
23 -IOW A 24
25 -IOR A 26
27 IDEIORDYA 28
29 -DACKA 30
31 AINT 32
33 SA 1 34
35 SA 0 36
37 CS 0 38
39 HD LED A 40
41 VCC 42
43 GROUND 44
AR-B1666AManual
44
43
Signal
GROUND
DATA 8
DATA 9
DATA 10
DATA 11
DATA 12
DATA 13
DATA 14
DATA 15
NOT USED
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
Not Used
SA 2
CS 1
GROUND
VCC
Not Used
