Page 11: Initial Inspection
Initial Inspection Upon receipt of your shipment, immediately open the shipping carton and ensure that you have all of the 27106T’s components. If an item is not initially visible, remove the foam from the shipping carton and thoroughly inspect both sides of the foam for the item. -
Page 12: Quickstart
27106T Vertical Propeller Anemometer QuickStart Short Cut is an easy way to program your datalogger to measure the 27106T and assign datalogger wiring terminals. Short Cut is available as a download on and the ResourceDVD. It is included in installations of www.campbellsci.eu... - Page 13 27106T Vertical Propeller Anemometer Under the Available Sensors and Devices list, select the Sensors | Meteorological | Wind Speed & Direction folder. Select 27106T Wind Speed Sensor and click to move the selection to the selected device window. The units default to meters/second, which can be changed by clicking the Wind Speed box and selecting one of the other options.
-
Page 14: Specifications
27106T’s signal and converts the signal to engineering units (mph, m s , knots). The 27106T is manufactured by R.M. Young (Traverse City, MI) and cabled by Campbell Scientific for use with our dataloggers. The R.M. Young instruction manual includes additional information on the operating principles, installation, and maintenance of the sensor. -
Page 15: Assembly And Mounting
6-inch to 10-inch torpedo level • Mount the 27106T to a tripod or tower using the tools listed above: Mount a Campbell Scientific crossarm to a tripod or tower. Remove the nut that is on the top of the propeller shaft (FIGURE FIGURE 7-2). -
Page 16: T Mounted To A Crossarm Via The Cm220
Route the sensor cable along the underside of the crossarm to the tripod or tower, and to the instrument enclosure. Secure the cable to the crossarm and tripod or tower using cable ties. Propeller Shaft Propeller Mounting Pipe CM220 Crossarm Cable Tie FIGURE 7-1. 27106T Mounted to a Crossarm via the CM220... -
Page 17: Wiring
Mounting Pipe NU-RAIL Fitting Crossarm Cable Tie FIGURE 7-2. 27106T Mounted to a Crossarm via a NU-RAIL Fitting Wiring Connections to Campbell Scientific dataloggers are given in TABLE 7-1. TABLE 7-1. Wire Colour, Wire Function, and Datalogger Connection Wire Colour... -
Page 18: Multiplier And Offset
27106T Vertical Propeller Anemometer Programming Short Cut is the best source for up-to-date datalogger programming code. Programming code is needed when: • Creating a program for a new datalogger installation • Adding sensors to an existing datalogger program If your data acquisition requirements are simple, you can probably create and maintain a datalogger program exclusively with Short Cut. -
Page 19: Maintenance And Troubleshooting
Assistance information. Maintenance Given proper care, the 27106T should provide years of service. Components are conservatively rated and require little maintenance. The only parts likely to need replacement due to normal wear are the precision ball bearings and the tach-generator. -
Page 20: Tach-Generator Replacement
27106T Vertical Propeller Anemometer If the bearings need to be replaced, have either Campbell Scientific or a qualified technician replace them by using the following procedure: Remove old bearings: Remove propeller from anemometer. Unthread and separate shaft housing assembly from generator housing. -
Page 21: Troubleshooting
27106T Vertical Propeller Anemometer Unthread generator housing collar. Pull generator housing away from sensor connector and generator assembly. Note position of generator wires on sensor connector pins. Unsolder wires from pins and remove old generator assembly. Install new generator assembly: Solder wires from new generator assembly onto proper sensor connector pins. - Page 22 27106T Vertical Propeller Anemometer...
-
Page 23: A. Importing Short Cut Code Into Crbasic Editor
Appendix A. Importing Short Cut Code Into CRBasic Editor This tutorial shows: How to import a Short Cut program into a program editor for • additional refinement • How to import a wiring diagram from Short Cut into the comments of a custom program Short Cut creates files, which can be imported into CRBasic Editor. -
Page 25: B. Example Program
Appendix B. Example Program The following program measure the 27106T every second, and store the maximum, minimum, and average wind speed every 10 minutes. Wiring for the examples is given in TABLE B-1. TABLE B-1. Wiring for Example Program Colour... - Page 28 Santo Domingo, Heredia 40305 SOUTH AFRICA COSTA RICA • cleroux@csafrica.co.za • info@campbellsci.cc www.campbellsci.co.za www.campbellsci.cc Campbell Scientific Southeast Asia Co., Ltd. Campbell Scientific Ltd. 877/22 Nirvana@Work, Rama 9 Road Campbell Park Suan Luang Subdistrict, Suan Luang District 80 Hathern Road Bangkok 10250...
