Installation
This section will guide you through the installation of your PCI card and the related
software. Please read through the instructions carefully and complete each step in the
order listed.
Installing the Card
1. Make sure that your system is unplugged and you are grounded.
2. Remove the cover of your system (see your computer's user manual for details, if
necessary) and gently turn your computer onto its side.
3. Locate an empty PCI slot (usually white in color) and remove the metal plate that
covers the rear bracket. You may need a Phillips screwdriver to perform this step.
Retain the screw! You will need it to secure the card later.
PCI
Slots
4. Gently insert the card into the empty slot, making sure it is firmly seated.
5. Secure the card in place using the screw you removed in Step 3.
6. Connect the ribbon cable with the parallel port to the card with the red stripe facing
Pin 1 as indicated on the connector. Remove the metal plate from an available PCI
slot bracket. Secure the port in the empty bracket using the screw you removed.
7. Put the computer case back on.
Installing the Drivers
If you lose your installation CD, these drivers are available as a free download from our
website. Visit www.startech.com and click on the Downloads link for more information.
Instruction Manual
2
